TL-WPA4220T KIT

Features：

Description

：

Wi-Fi Clone Button simplies your Wi-Fi conguration

and helps build a seamless unied home network

HomePlug AV standard providing up to 500Mbps high

speed data transmission over a home’s existing electrical

wiring, ideal for lag-free HD or 3D video streaming and

online gaming

Extend 300Mbps Wireless connections to previously

hard-to-reach areas of your home and oce

Two Ethernet ports allow your TVs, game consoles, or PCs

connect to the Internet

Up to 300-meter range over the household power circuit

Easy-to-install, just plug in, pair and play

128-bit AES encryption easily at a push of "Pair" Button

Supports IGMP managed multicast IP transmission,

optimizing IPTV streaming

TP-LINK 300Mbps AV500 Powerline Universal WiFi Range Extender, 2 Ethernet Ports, Network Kit TL-WPA4220T KIT extends your

Internet connection to every room of the house through your home’s existing electrical circuitry. The TL-WPA4220 features a

Wi-Fi Clone Button enabling Super Range Extension, which means it can automatically copy the SSID and Password of your

router. In this way, TL-WPA4220T KIT simplies your Wi-Fi conguration and allows for seamless roaming within your home

network.

HomePlug AV standard providing up to 500Mbps high

speed data transmission over a home’s existing electrical

wiring, ideal for lag-free HD or 3D video streaming and

Extend 300Mbps Wireless connections to previously

Two Ethernet ports allow your TVs, game consoles, or PCs

Up to 300-meter range over the household power circuit

128-bit AES encryption easily at a push of "Pair" Button

Supports IGMP managed multicast IP transmission,

AV500 Powerline

Universal WiFi Range Extender

2 Ethernet Ports, Network Kit

Package:

300Mbps AV500 WiFi Powerline Extender Starter Kit

TL-WPA4220 *2 & TL-PA4010 *1

2-meter RJ-45 Ethernet Cable * 2

Quick Installation Guide

Resource CD

www.tp-link.com

Specifications：

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any

Diagram:

Hardware Features

Standards and Protocols

Interface

Plug Type

Button

LED Indicator

Dimensions ( W x D x H )

Power Consumption

Range

Software Features

Modulation Technology

Encryption

Others

Certications

System Requirements

Environment

HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n

10/100Mbps Ethernet Ports

EU, UK

Pair, Reset, Wi-Fi/Wi-Fi Clone

PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone

3.7 x 2.1 x 1.6 in. (94 × 54 × 40mm)

<6W

300 Meters over electrical circuit

OFDM (PLC)

Powerline Security:

128-bit AES

Wireless Security:

WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption

CE, FCC, RoHS

Windows 8/7/Vista/XP/2000, Mac OS, Linux*

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

* Utility supports Windows 8/7/Vista/XP/2000 operating system for the present.

PLUG & PLAY WITH TP-LINK WI-FI CLONE!

> Plug in TL-WPA4220 near your router.

> Press the Wi-Fi Clone button on TL-WPA4220.

> Press the WPS button on the router.

That’s it! Now TL-WPA4220 has copied your router’s SSID and

Password and you can enjoy a unied home network!

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

PASSWORD

SSID

> Plug in TL-WPA4220 near your router.

PASSWORD

WPS

TL-WPA4220T KIT

AV500 Powerline Universal WiFi Range Extender

2 Ethernet Ports, Network Kit
