TP-Link TD-VG3511 Manuale utente

If you currently use a modem, disconnect it now - the Modem Router will

replace your current modem.

Connect your computer to the port labeled “LAN 1~4” on the Modem Router

with an Ethernet cable.

Connet the LINE port on the splitter to the wall jack using a telephone line.

Then use the other telephone line to connect the MODEM port on the

Note Please use only wired network connections to configure the Modem Route

Installation

Note Please run the CD first, and the CD will guide you step by step to connect and

configure the device. If there are troubles in running CD, please follow the

instructions below.

splitter to the ADSL port on the Modem Router, also have the PHONE port

on the splitter connected to a telephone.

Connect your telephone to the port labeled “PHONE 1~2” on the Modem

Router with a telephone line.

Connect your USB device to the USB port labeled “USB” on the Modem

Router.

Plug the provided Power Adapter into the Power jack on the back of the

Modem Router and the other end to a standard electrical wall socket.

Switch on the ON/OFF button and power on all your other network devices.

Then check to see if the LEDs of the Modem Router display normally as the

diagram below describes.

If the LEDs display abnormally, please check to see if all the cable

connectors (power adapter, phone line Ethernet cable and USB device)

are well connected to your device. With the phone line well connected, i

the ADSL LED turns off after flashing, please contact your ISP to ensure

that your Internet connection is active.

Note

WLAN: Solid

light or flashing

Note 1. If you want to share files or use the USB Voice Mail function, please plug

an external USB hard drive/USB flash disk into the USB port. To use the

printer function, please connect a USB printer to the USB port.

USB: Solid

light or flashing

LAN: Solid light

or flashing

ADSL: Solid

light or flashing

Power: Solid

2. To use USB Voice Mail function, please make sure the free space of the

plugged external USB hard drive/USB flash disk is more than 4MB.

Insert the provided Resource

CD into your CD-ROM drive.

The Setup Wizard will

automatically pop up on

your computer’s screen.

To configure the device, TP-LINK strongly recommends that Windows users

run the setup CD, but if you can not run the mini CD or your operating

system is Mac OS\Linux\Android\iOS, please refer to Appendix to run the

web-based Quick Setup Wizard.

Note

Please select your product

model and click Start Setu

Then the configuration wizard

will pop up and show you

how to connect your devices.

After that, the Easy Setup

Assistant will start.

When it comes to Setup the

SIP Account for VoIP, you

need to enter the SIP

account information provided

by your ISP.

Click NEXT, and then follow

the step-by-step instructions

Please make sure an external

USB hard drive/USB flash disk

has been plugged into the USB

port on the Modem Router

before running Setup Wizard.

Otherwise, you may be unable

to configure USB Voice Mail

function on this page.

Please enter a Profile Name

to identify this account and

other parameters provided

by your ISP

Click NEXT

Check Configure USB

Voice Mail and Send Files

to USB Disk, enable USB

Mail for Line 1 or Line 2

Click NEXT

After the configuration has been completed, please skip to Step 3 “Testing the

Internet Connection”.

The basic settings for your Modem Router are completed. Please open the web

browser and try to log on to some popular website to test your Internet

connection, for example:

http://www.tp-link.com

http://www.google.com

If the above websites can be accessed, it indicates that your Modem Router has

been configured successfully and you can start to enjoy the Internet. If the

websites cannot be accessed, please refer to “T4. What can I do if I cannot

access the Internet?” in the Troubleshooting guide.

For the advanced configurations, please refer to the User Guide on the

Resource CD provided.

Note

Note The above configurations only need to be set once. If you want other

computers in your LAN to access the Internet, please connect the

desired computer to the Modem Router directly. If the additional

computer can not access the Internet, please set that computer referring

to “T3. What can I do if I cannot access the web-based configuration

page?” in the Troubleshooting guide.

The USB device can only be configured through the Easy Setup

Assistant. After that, configure files necessary for USB Voice Mail

function can be found in your USB disk. For advanced settngs, please

refer to 4.7.8 USB Voice Mail on User Guide.

Note

Local Storage Sharing

Local Storage Sharing allows you to share

your USB drive or HDD with other computers,

tablets or smart phones that are connected to

the Modem Router. You can create multiple

shares and control the permission by setting

different accounts.

Please refer to 4.8.3 Storage Sharing on User

Guide.

Remote Storage Sharing

Remote Storage Sharing turns your USB drive

or HDD into a FTP server, which enables your

access anywhere you have an Internet

connection.

Please refer to 4.8.4 FTP Server on User

Guide.

Media Server

Media Server let you play videos, photos and

music stored on your USB drive or HDD on

any DLNA supported TVs, Game Consoles or

Media Players.

Please refer to 4.8.5 Media Server on User

Guide.

Print Server

Print Server shares your printer to multiple

computers which are connected to the Modem

Router. No worry for the printer sharing any

more.

Please refer to 4.8.6 Print Server on User

Guide.

Application

Guide for USB Features

You can get the User Guide on Resource CD. Or log on to www.tp-link.com

Śselect your regionŚsearch for the product ŚUser Guide can be found

under the “Download” tab on the product page.

Note

T1. How do I restore my Modem Router’s configuration to its factory default

settings?

T2. What can I do if I don’t know or forget my password?

1) Restore the Modem Router’s configuration to its factory default settings. If

you don’t know how to do that, please refer to T1.

2) Use the default user name and password: admin, admin.

3) Try to configure your Modem Router once again by following the instructions

in the previous steps of the QIG.

T3. What can I do if I cannot access the web-based configuration page?

1) Configure your computer’s IP Address.

Once the Modem Router is reset, the current configuration settings will be

lost and you will need to re-configure the router.

With the Modem Router powered

on, use a pin to press and hold the

RESET button on the back panel

for 8 to 10 seconds before

releasing it.

Troubleshooting

Press it for 8 to 10 seconds

For Windows 7 OS

Go to Start > Settings > Control

Panel, and then you will see the

following page.

Click Change adapter settings

Click View network

status and tasks

Right-click Local

Area Connection

Click Properties

Double-click Internet Protocol

Version 4 (TCP/IPv4)

Click OK

Select Obtain an IP

address automaticall

Select Obtain DNS server

address automatically

For Windows Vista OS

Go to Start > Settings > Control

Panel, and then you will see the

following page.

Click Properties

Click View status

Click View network

status and tasks
