TP-Link TL-WR841N Manuale utente
7106504693 REV1.0.0
Specifications are subject to change without notice. TP-LINK is a registered
trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product
names are trademarks or registered trademarks of their respective
holders.
No part of the specifications may be reproduced in any form or by any
means or used to make any derivative such as translation, transformation,
or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
Copyright © 2014 TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
www.tp-link.com
300M Wireless N Router
Model No.TL-WR841N
Quick Installation Guide
TP-LINK TECHNOLOGIES CO., LTD.
English
Français
CONTENTS
English...................................................................... 1
Français.................................................................. 13
English Français
1
Quick Installation Guide
Note Please select your preferred conguration method:
Method 1 >> Conguration via CD Setup Wizard
For Windows users only
Method 2 >> Conguration via Web-based Quick
Setup Wizard
For Mac OS/Linux users or Windows
users who cannot run mini CD
Package Contents
TL-WR841N Power Adapter
Ethernet Cable Resource CD
QIG
3
4
English
Français
2
Hardware Connection
Power off your modem.
Connect the WAN port on your Router to the modem’s LAN
port with an Ethernet cable.
Connect your computer to one of the LAN ports labeled 1~4
on the Router with an Ethernet cable.
Power on the modem and wait for one minute.
Plug the provided POWER Adapter into the POWER jack
on the back of the Router and the other end to a standard
electrical wall socket.
Press the ON/OFF button to power on the Router.
1
2
3
4
5
Note Please conrm that the WLAN light is ON so that client
devices can connect to the router wirelessly. Press the
WIFI button for more than 2 seconds to turn on or turn
off the wireless function.
3
WIFI
ON/OFF
WPS/
RESET
5
2
4
Wall Socket
Cable/DSL Modem
Internet
Wireless N Router
To WAN port
To the modem’s LAN port
Line
Cable Cable
To LAN port
Wall Socket
English Français
3
Method One:
Conguration via CD Setup Wizard
Note This method is only for Windows users who can run the
mini CD.
1. Insert the TP-LINK Resource CD into the CD-ROM drive.
2. Select TL-WR841N and click Easy Setup Assistant.
English
Français
4
3. Select your language from the drop-down menu. Click START
and the Easy Setup Assistant will guide you step by step to
set up the Router.
4. Follow the instructions until you see the screen below. Click
FINISH to complete the setup.
Note You can click WEB management interface for more
advanced settings.
English Français
5
Method Two:
Conguration via Web-based Quick Setup Wizard
Note This method is for Mac OS/Linux users or Windows
users who cannot run the mini CD.
1. Open your browser and type http://tplinklogin.net in the
address eld, then use the user name admin and password
admin to log in.
2. Click Next in the pop up Quick Setup page.
Note If the login window fails to pop up or you cannot access
the management page after the login window, please
refer to Troubleshooting-2.
Note The Router will automatically detect the Internet
connection. If the Internet is available, the Router will
direct you to Step 5; otherwise, you need to continue
with Step 3.
English
Français
6
3. Select Auto-Detect to detect the Internet connection type and
click Next. (The Dynamic IP is the suitable connection type for
most cases, so we take it as an example in the following.)
4. If Dynamic IP is detected, there will appear the MAC Clone
page. In most cases, there is no need to clone the MAC
address. You can select “No, I do NOT need to clone MAC
address” and then click Next to continue.
English Français
7
5. You can rename your wireless network and create your own
password on this page. The default wireless network name
is TP-LINK_XXXXXX; and the default wireless password, the
same as the PIN code, is printed on the bottom label. Click
Next to continue.
6. Click Finish to make your settings take effect.
English
Français
8
Appendix: Additional Features
You can set up additional features by referring to the Technical
Support page on the TP-LINK website or the User Guide on the
resource CD.
Scan the QR code to access the
Technical Support page.
Or access the website:http://
www.tp-link.com/en/support/faq/
Open ports for Game Console FAQ ID: 72
Set up Bandwidth Control FAQ ID: 194
Set up Parental Control FAQ ID: 350
Set up Access Control FAQ ID: 359
Set up WDS Bridging FAQ ID: 440
Set up/Change the wireless security settings FAQ ID: 256
Upgrade the rmware FAQ ID: 296
Restore the factory default settings FAQ ID: 426
