TP-Link kasa KC410S Manuale utente
User Guide
Kasa Spot Pan Tilt, 24/7 Recording
KC410S
© 2021 TP-Link1910012918 REV1.0.0
Contents
About This Guide ···················································· 1
Introduction ······························································· 2
Appearance ······························································· 3
Insert a microSD Card·········································· 4
Set Up Your Camera·············································· 5
Main Device Controls··········································· 7
Pan/Tilt·········································································· 8
Add ViewPoints························································ 9
Set Schedules ························································10
Set 24/7 Recording ·············································14
Manage Device Settings ··································16
Reset Your Camera··············································29
Smart Actions - Motion Sensing··················31
Discover Kasa·························································36
1
About This Guide
This guide provides a brief introduction to the Kasa Spot Pan Tilt and the Kasa Smart app, as well as regulatory information.
Features available in Kasa Smart may vary by model and software version. Kasa Smart availability may also vary by region or ISP. All images, steps, and
descriptions in this guide are only examples and may not reect your actual Kasa Smart experience.
Conventions
In this guide, the following convention is used:
Convention Description
Teal Key information appears in teal, including management page text such as menus, items, buttons and so on.
Underline Hyperlinks are in teal and underlined. You can click to redirect to a website.
More Info
• Specications can be found on the product page at https://www.tp-link.com.
• Our Technical Support and troubleshooting information can be found at https://www.tp-link.com/support/.
• A TP-Link Community is provided for you to discuss our products at https://community.tp-link.com.
• Frequently Asked Questions (FAQs) can be found at https://www.tp-link.com/support/faq/.
2
Introduction
With the Kasa Spot Pan Tilt connected to your home network, you can get the full picture of any space in your apartment, dorm or home. With a 360°
horizontal view and 113° vertical view, the Pan Tilt has everything covered. With Motion Tracking and Patrol Mode, track activity from beginning to end
and set multiple distinct viewpoints for your camera to monitor at set intervals.
• Crystal Clear Video – Sharp and clear 4MP Full HD provides high-quality video right in the palm of your hand.
• Pan and Tilt – Swipe up, down, left and right on your phone to rotate and set the camera’s point of view.
• Motion Tracking – When motion activity is detected, Kasa Spot Pan Tilt tracks and follows the subject to keep it within the camera’s eld of view.
• Cloud Storage Plans – Upgrade your Kasa Care subscription plan and enjoy video recordings for up to 30 days.
• Patrol Mode – Set 4 distinct viewpoints and program your pan tilt camera to keep an eye on each region at intervals of your choosing.
• Night Vision – Even in the dark, the camera has Night Vision up to 30 feet. Never miss a thing at night and still get the same high-quality video you’re used to.
• Instant Activity Alerts – No need to check your Kasa Spot Pan Tilt throughout the day. Get automatic alerts when it detects motion. Take quick
action when you see your pet on the couch, a roommate walking through your room, or an intruder enter your front door.
• Two-Way Audio - Use crisp two-way audio to communicate with nosy roommates, family or even mischievous pets.
• Activity Zones - Control what alerts you receive by creating up to 16 custom activity zones, at no charge, around areas that are important to you.
• 24/7 Recording -Support continuous video recording with a SD card inserted to your Kasa Spot Pan Tilt.
113° Vertical View
3
Appearance
Kasa Spot Pan Tilt has a system LED that changes color according to its status, a lens, microphone, speaker, micro USB port, a SD card slot and a
RESET button. Refer below for details.
Micro SD RESET
RESET Button
Tilt your camera lens up to
nd the RESET button.
• Press and hold for 3s to 15s:
Reset Wi-Fi connection
• Press and hold for over 15s:
Reset to Factory mode
System LED
• Solid amber:
Rebooting
• Alternating amber and green:
Ready for setup
• Flashing red:
Connecting to Wi-Fi
• Flashing green:
Connected to Wi-Fi
• Solid green:
Bound to Cloud
• Flashing amber:
Resetting to SoftAP/Factory mode
Speaker
The sound comes
out of the camera.
Microphone
Built-in microphone.
Note: Do NOT insert
objects into the hole.
Micro USB Port
Connect the power
cord provided.
Lens
microSD Slot
Insert a microSD
card for recording.
4
Insert a microSD Card
Kasa provides options for your video recording. You can subscribe to a Kasa Care Plan to store 30-day video clips to the cloud for added backup and
more benecial functions.
Or you can save the footage continuously on a microSD card* and play back with your Kasa Smart app. The camera will overwrite the oldest les when
the microSD card memory is full. See the instructions below to insert a microSD card to your Kasa Spot.
*Micro SD card not included.
1. Roll up the lens of your camera and nd the SD card slot.
2. Holding the card in the correct orientation, carefully insert the SD card into the slot. Push in the SD card until you hear a clicking sound.
Micro SD RESET
microSD
5
Set Up Your Camera
Follow the steps below to get started with your new camera.
Step 1. Download Kasa
Get the Kasa Smart app from the App Store
or Google Play, or by scanning the QR code
below.
Step 2. Log In
Open the app, and log in with your TP-Link ID.
If you don't have an account, create one rst.
Step 3. Start Setup
Tap the button in the Kasa app and select
Cameras > Kasa Spot Pan Tilt.
6
Step 4. Congure Camera
Follow app instructions to configure your camera and add it to your
home network.
Step 5. Place Camera
Place your camera on a at surface, or install it on a wall or ceiling with
the provided indicator label and mounting screws.
• For soft surface: Directly screw the screws in.
• For cement wall: Drill two φ6mm holes with the help of indicator label, insert the plastic
expansion tubes into holes and screw the mounting screws into the expansion tubes.
n 7.5
2 20
3.5
UNIT: mm
n 6
301.8
3.5
UNIT: mm
Note: Your camera might use one of
the following two types of screws.
7
Main Device Controls
After you successfully set up your camera, you will see the home page of the Kasa Smart app. Here you can view and manage all devices that you've
added to Kasa. Tap your camera to enter the live view page and further manage it.
Home Page
You can see all your Kasa devices listed in
the Home page.
Turn on/o your camera
Turn on/o your camera quickly by tapping the switch in the home page. If the camera
is o, it means you are entering the privacy mode and cannot stream live video.
8
Pan/Tilt
Pan/Tilt: This allows you to move your camera up / down, left / right.
1. Tap your camera in the Home page to
enter the live view page.
2. Tap the arrow icon to rotate your
camera as you like.
Tilt your camera up.
Tilt your camera down.
Tilt your camera left / right.
