TP-Link Archer C7 Manuale utente

www.tp-link.com

Features：

Description：

Archer C7 AC1750 Wireless

Dual Band Gigabit Router

The TP-LINK’s Archer C7 upgrades your network to the next generation of Wi-Fi. With combined wireless speeds of up to 1.75Gbps and 6 antennas,

the device provides ultimate speeds and wireless range. You can run multiple bandwidth intensive applications in a large home or oce. Simple

tasks like sending e-mails or web browsing can be handled by the 2.4GHz band while bandwidth intensive tasks like online gaming or HD video

streaming can be processed by the 5GHz band– all at the same time.

If you prefer a wired connection, the Archer C7 boasts ve gigabit ports to provide a lightning-fast and lag-free experience. The two USB 2.0 ports

will allow you to power a robust home Internet network by sharing printers, ash storage, ftp servers, or media players.

The next generation of Wi-Fi, leading 802.11ac standard

Simultaneous 5GHz 1300Mbps and 2.4GHz 450Mbps

connections for1.75Gbps of total available bandwidth

Full gigabit ports ensure ultra fast data transfer speeds

3*5dBi external antennas and 3 internal antennas provide

maximum whole directional wireless coverage and reliability

Dual USB Ports - easily share printers, les or media with your

friends or family locally or over the internet

The device’s built-in print server supports wireless printing from

dierent computers by connecting a USB printer to the router

Guest Network Access provides secure Wi-Fi access for guests

sharing your home or oce network

Supports IPV6 (Internet Protocol Version 6)

Wireless On/O Switch lets you simply turn the wireless radio on

or o

Easy one-touch wireless security encryption with the WPS button

Parental Control allows administrators to establish restricted

access for children or sta

Dual

USB Ports

Gigabit

Ports

Up to

1300Mbps

+450Mbps

Security

Connection

Dual Band

5+2.4GHz IPv6-

Enabled

Maximum

Range

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

Specifications：

Archer C7 AC1750 Wireless Dual Band Gigabit Router

Interface

Button

External Power Supply

Antenna type

Wireless Standards

Frequency

Signal Rate

EIRP

Reception Sensitivity

Wireless Functions

Wireless Security

WAN Type

DHCP

Quality of Service

Port Forwarding

Dynamic DNS

VPN Pass-Through

Access Control

Firewall Security

USB Sharing

Management

Internet Protocol

HARDWARE FEATURES

WIRELESS FEATURES

SOFTWARE FEATURES

4 10/100/1000Mbps LAN Ports

1 10/100/1000Mbps WAN Port

2 USB 2.0 Port

WPS/Reset Button

Wireless On/O Switch

Power On/O Button

12VDC / 2.5A

Three 5GHz 5dBi detachable antennas (RP-SMA)

Three 2.4GHz internal antennas

IEEE 802.11a/n/ac, 5GHz

IEEE 802.11b/g/n, 2,4GHz

2.4GHz and 5GHz

5GHz: Up to 1300Mbps

2.4GHz: Up to 450Mbps

<20dBm

5GHz

11a 6Mbps：　-96dBm, 11a 54Mbps：　-79dBm

11ac HT20: -71dBm, 11ac HT40: -66dBm, 11ac HT80: -63dBm

2.4GHz

11g 54M: -77dBm

11n HT20: -74dBm, 11n HT40: -72dBm

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics

WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption

Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)/BigPond

Server, Client, DHCP Client List,

Address Reservation

WMM, Bandwidth Control

Virtual Server, Port Triggering, UPnP, DMZ

DynDns, Comexe, NO-IP

PPTP, L2TP, IPSec

Parental Control, Local Management Control, Host List, Access

Schedule, Rule Management

DoS, SPI Firewall

IP Address Filter/MAC Address Filter/Domain Filter

IP and MAC Address Binding

Support Samba(Storage)/FTP Server/Media Server/Printer Server

Access Control

Local Management

Remote Management

IPv4, IPv6

www.tp-link.com

Specifications：

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

trademarks or registered trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make

any derivative such as translation, transformation, or adaptation without permission from TP-LINK Technologies Co., Ltd.

Diagram:

Dual USB Ports Sharing

Archer C7 AC1750 Wireless Dual Band Gigabit Router

Package:

Archer C7 AC1750 Wireless

Dual Band Gigabit Router

3 detachable antennas

Power supply unit

Resource CD

Ethernet Cable

Quick Installation Guide

Certications

System Requirements

Dimensions (W X D X H)

Environment

OTHERS

CE, FCC, RoHS

Microsoft Windows 8/7/Vista/XP/2000/NT/98SE, MAC OS, NetWare,

UNIX or Linux.

9.6 x 6.4 x 1.3 in. (243 x 160.6 x 32.5mm)

Operating Temperature: 0℃~40℃(32℉~104℉)

Storage Temperature: -40℃~70℃(-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Internet

Archer C7 AC1750 Wireless

Dual Band Gigabit Router

Printing or scanning files

Power On/Off

Power Wireless On/Off

Dual USB Ports

Internet

Connect to DSL, Fiber or Cable modem

Gigabit Ethernet

Connect to computers, TVs and

game consoles

WPS/Reset

Sharing files/photos/musics/videosHard drive1/Flash disk/

Printer2connection

Related Products:

Archer T4U AC1200 Wireless

Dual Band USB Adapter

Archer T2U AC600 Wireless

Dual Band USB Adapter

DSL/Fiber/Cable modem

1Some USB hard drive that works at a high power without using any external power adapter might not be supported.

2The USB Printer Controller supports Windows 8/7/Vista/XP 32/64bits and Mac OS. For the printer compatibility information,

please visit www.tp-link.com
