5
Detergent/Water Connection tubes
Yellow IN Green IN
Red OUT Bleu OUT
Machine start
•Before you use this appliance, check that the electrical current is the same as the voltage on
the appliance’s type-plate.
Steam function :
ONLY FOR FIRST STARTUP OR WITH AN EMPTY BOILER
•Insert the plug into the socket.
•Fill the water tank (10) and ensure that the connection tube (19) is correctly fitted.
•Press the main switch (1) and after the sound stopped press the switch (2) the light goes on.
•Wait for the boiler water filling pump to stop. Fil
•If the machine alarm is activated (red light 9 on + audible alarm),turn the switch 2 off,
leave it off for at least 5 seconds and then switch it on again.
ling is automatically performed when
required by the water level.
•The heating phase begins, lasting approx. 7 minutes. ( intermittent lamp)
•When pilot light 7 come fix, the machine is ready for use.
•Insert the hose plug into the socket 4, ensuring that it is securely fitted.
•Press the steam button (15 steam function selection) and press the red switch (17) on the
handgrip and direct the steam jet towards the area to be cleaned.
CAUTION
Before beginning steam cleaning operations, drain the condensation left inside the steam hose
into a bucket or other suitable place.
•Fill the tank (11) with water.
•Press the steam button (16 water function selection) and press the red switch (17) on the
handgrip and direct the steam/water jet towards the area to be cleaned.
Detergent connection tubes Water connection tubes
8
Cobra kit :
41 J8014 LARGE BRUSH
42 J7314 SMALL BRUSH
43 J8015 LIQUID SUCTION ACCESSORY WITH RUBBER STREAP
44 J8012 LIQUID SUCTION ACCESSORY WITH NYLON BRISTLES
45 J7326 LIQUID SUCTION ACCESSORY RUBBER/ NYLON
46 J7348 ECCENTRIC ACCESSORY WITH NATURAL HAIR BRISTLES
47 J7967 ECCENTRIC ACCESSORY WITH NYLON BRISTLES
48 J7664 DRY VACUUM ACCESSORY
49 J7905 MEASURE BOTTLE 1,7l
50 J7661 DETERGENT BOTTLE
MAINTENANCE
Cleaning the boiler : ONLY WITH COLD MACHINE
•Disconnect a power cord plug from general socket.
FOR VC 6000
•Disconnect a tank ( 10 and 11) connections.
•Take away a water and detergent tank.
•Unscrewing a discharge cup (14)
•Discharge a dirty water , if the water result to much dirty,
repeat for 2 or 3 times this operation.
•Close a discharge cup (14)
FOR VC 6000 FULL
•Disconnect a tank ( 10 and 11) connections.
•Take away a water and detergent tank.
•Take away a vacuum machine.
•Unscrewing a discharge cup (14)
•Unscrewing a safety cup (8)
•Discharge a dirty water , if the water result to much dirty , repeat for 2 or 3 times this
operation inserting a clean water from the hole of safety cup (8).
•Clean the safety cup electrical sensor (21) of calcium and , if damaged a “o” ring ( 22) .
•Close a discharge cup (14) and fill from the safety cup hole about 1 lt. of water.
•Close a safety cup (8) .
To restart the machine, follow the operations in the paragraph “Machine start”.
CAUTION
Check for any water leaks from the plug below the machine and tighten the plug if necessary.
