Transcend TS2G/4GMP615 Manuale utente

TS2G/4GMP615

Description

TS2G/4GMP615 is a 2GB/4GB USB

Flash Drive with 1 pcs of 2Gx8/4Gx8x8

Flash Memory assembled on the printed

circuit board. It combines a USB Flash

Drive with an MP3 player, AB repeater,

voice recorder and an FM radio.

Outline

Features

MP3 Player – supports MP3, WMA,

WMA-DRM10 (subscription music) and

WAV music formats

Recordable FM Radio with 20 station

presets

Advanced Digital Voice Recorder

Karaoke-style lyrics display

Vivid dual-color OLED screen displays

clear text at any angle and in any light

VAD (Voice Activity Detection) for high

quality gapless audio recordings

A-B repeat function allows you to

continuously replay a designated section

of a track

Hi-Speed mini USB 2.0 Connector

BMicrophone

CDual-Color OLED Display

DPlay / Pause / Power

EVolume Up

FPrevious / Rewind

GVolume Down

HNext / Fast-Forward

IHeadphone Jack

JLanyard Attachment Loop

KHold Switch

LRecord

MMenu Button

NA-B Repeat

OReset Button

Variable track playback speeds

Supports 13 languages including

menus, song/album title, artist name and

lyrics

USB flash drive capabilities for data

transfer and storage

Included software can be used to lock

your computer and password-protect your

files

7 Equalizer effects, including a

customizable USER EQ setting

Internal rechargeable Li-ion battery

provides over 15 hours of continuous

music playback*

High-speed mini USB 2.0 port for easy

computer connectivity and fast file

transfers

Real Time Clock displays local and

world times

Block Diagram

With 1 pcs of 2G/4G x8 Flash Memory

2Gx8

4Gx8

Microphone

Pinouts

Pin No. Pin Name

01 VCC

02 USB-

03 USB+

04 VSS

05 GND

Pin Identification

Symbol Function

USB+

USB- USB differential signal:

The pairs are used to transmit Data/Address/Command

VCC USB Power Input

VSS Ground

GND Ground

Specifications

 Size (L x W x H): 70mm × 34.5mm × 15.5mm

 Weight: 28g (with Li-ion battery)

 Music Formats: MP3 WMA and WMA-DRM10 (Subscription

music)

 Recording Format: ADPCM (WAV)

 Estimated Battery Life: 15 hours Music playback (fully charged battery)

 Compression Rates: 32Kbps to 320Kbps

 Data Retention: Up to 10 years

 Erase Cycles: ≥100,000 times

 Signal-to-Noise Ratio: ≥90dB

 Power Supply USB mass storage: DC5V ±10%

MP3 Player: 3.7V Li-ion battery

 Certificates: CE, FCC, BSMI

 Warranty: 2-years
