TRENDnet TE-PCI Manuale utente

The TE-PCI is a jumperless, plug and play, 32-bit Ethernet

adapter featuring half/full duplex operations. The TE-PCI

utilizes the latest PCI Bus Mastering technology to process

network packets with minimal CPU utilization..

Taking advantage of Bus Mastering technology, 32-bit bus

width and speed up to 33MHz, the TE-PCI/W is superior to all

ISA adapters. It is equipped with both BNC and RJ-45

connectors, includes drivers for every popular network

operating system and is backed by TRENDware's 5 Year

Parts and Labor Warranty.

TE-PCI

High Performance Plug-n-Play Ethernet Adapter

Compliant with IEEE 802.3 10Base-2 and 10Base-T

Ethernet standards

Full-duplex operation at 10Base-T connection

Compliant with PCI Local Bus Specification 2.0

Simply insert the card and it will be automatically configured

in a PnP system

Supports PCI Bus Slave mode

Supports Multi-thread Operation

Supports Virtual Memory

NE2000 Compatible

Auto-sensing connector in use

On-board socket for optional Boot ROM

External LED Indicators for troubleshooting (LINK and

TRAFFIC)

10Mbps (Half duplex)/20Mbps (Full duplex) Transfer Rate

5 Year Warranty

FEATURES

TE-PCIW (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

SPECIFICATIONS

TE-PCI

High Performance Plug-n-Play Ethernet Adapter

TE-PCI

High Performance Plug-n-Play Ethernet Adapter

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

ORDERING INFORMATIONORDERING INFORMATION

TRENDnet

TRENDware, USA

TE-PCI

32-bit PCI Plug-n-Play Ethernet Adapter

with BNC + RJ-45 Connectors

Standards:

IEEE 802.3 10Base-2 and 10Base-T

On-board Connector:

RJ-45 and BNC

Media Interface:

UTP Cat. 3, 4, 5; EIA/TIA-568 non-standard

100-ohm STP cable; RG-58A/U coaxial cable

Data Bus Supported:

32-bit, PCI Local Bus Specification 2.0

(Bus Master)

IRQ’s Supported:

Assigned by the BIOS to a free IRQ (interrupt)

number

I/O Base Address:

Assigned by the BIOS to a free I/O address block

LAN Chipset:

DEC 32-bit Intelligent Ethernet interface controller

•

Boot ROM Size:

16Kb

FCC Compliance:

FCC Class A certification;

FCC Class B certification

CE Mark:

Compliance with EMI EN50081-1, EN55022,

EMS EN50082-1, IEC 801-2 (ESD),

IEC 801-3 (RS), IEC 801-4 (EFT)

Power Consumption:

2.72W max.

Temperature:

Operating: 32° - 131°F (0° - 55°C)

Storage: -4° - 176°F (-20° - 80°C)

Operating Humidity:

10 to 90%, non-condensing

•

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
