TRENDnet TEW-646UBH Manuale utente

FEATURES

• 1 x USB 2.0 connector

• 1 x 2dBi detachable antenna (Reverse SMA)

• 500mW wireless transmission power

• USB bus powered adapter

• Wi-Fi compliant with IEEE 802.11n standard

• One-touch wireless connection with external Wi-Fi Protected Setup (WPS) button

• Backwards compatible with IEEE 802.11g and IEEE 802.11b devices

• Supports Ad-Hoc (Client-Client) and Infrastructure (AP-Client) Mode

• Maximum reliability, throughput, and connectivity with automatic data rate switching

• Supports 64/128-bit WEP, WPA/WPA2-RADIUS and WPA /WPA2-PSK

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization

• Universal Plug and Play (UPnP) supported

• Easy user setup and intuitive diagnostic utility

• Coverage of up to 100 meters indoor (330 feet) and 200 meters outdoor (660 feet) *

• 3-year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical speciﬁ cations. Actual data throughput and coverage

will vary depending on interference, network trafﬁ c, building materials and other conditions.

TEW-646UBH

rev: 05.06.2011

High Power 150Mbps Wireless N USB Adapter

TEW-646UBH (V1.0R)

The High Power 150Mbps Wireless N USB Adapter (model TEW-646UBH)

connects a laptop or desktop computer to a high speed wireless n network.

An adjustable external antenna and a 200% increase** in power output

maximizes wireless throughput and coverage.

Setup is a breeze with one-touch Wi-Fi Protected Setup (WPS) technology.

Advanced wireless encryption protects your valuable data. Wi-Fi Multimedia

(WMM) Quality of Service (QoS) prioritizes important video, audio, and

gaming trafﬁ c. Stream video, download ﬁ les, play games, and talk online

with this high power adapter.

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

High Power 150Mbps Wireless N USB Adapter

TEW-646UBH (V1.0R)

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TEW-646UBH

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

RELATED PRODUCTS

TEW-657BRM 150Mbps Wireless N ADSL 2/2+ Modem Router

TEW-651BR 150Mbps Wireless N Home Router

TEW-648UB 150Mbps Mini Wireless N USB Adapter

SPECIFICATIONS

HARDWARE

Interface • USB 2.0

Standards • IEEE 802.11b, IEEE 802.11g, based on IEEE 802.11n technology

LED Indicators • Power, Link

WPS Button • Enables WPS connection

Power Consumption • 2.5 W

Antenna Connectors • SMA

Supported OS • Windows: 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit) • Mac: OS 10.4-10.6

Dimensions (LxWxH) • 60 x 16 x 8 mm (2.3 x 0.6 x 0.3 in.)

Weight • 5.7 g (0.2 oz)

Temperature • Operating: 0° ~ 55° C (32° ~ 131° F) • Storage: -20° ~ 70° C (-4 ~ 158° F)

Humidity • Max. 90% (non-condensing)

Certiﬁ cations • CE, FCC

WIRELESS

Modulation • OFDM, DSSS

Antenna • 1 x 2dBi omni-directional detachable antenna (Reverse SMA)

Frequency • 2.4 ~ 2.497 GHz

Quality of Service • 802.11e, WMM

Data Rate (auto fallback) • 802.11b: 11Mbps • 802.11g: 54Mbps • 802.11n: 150Mbps

Output Power • 802.11b: 27dBm • 802.11g: 24dBm • 802.11n: 22dBm

Receiving Sensitivity • 802.11b: -86dBm at 11mpbs • 802.11g: -72dBm at 54Mbps • 802.11n: -65dBm at 150Mbps

Encryption • 64/128-bit WEP, WPA/WPA2-RADIUS, WPA /WPA2-PSK

Channels • 1~11 (FCC), 1~13 (ETSI)

NETWORKING SOLUTIONS
