TRENDnet TEW-684UB - Manuale utente

450Mbps Dual Band Wireless N USB Adapter

TEW-684UB(V1.0R)

TRENDnet’s compact 450Mbps Dual Band Wireless N USB Adapter,

model TEW-684UB, connects a laptop or desktop computer to an

ultra-high performance 450Mbps dual band wireless network.

Quickly connect to a 450Mbps 2.4GHz or 5GHz wireless network at the

touch of a button with the convenience of one-touch Wi-Fi Protected

Setup (WPS). Seamlessly stream HD video over the less congested

5GHz band.

Place the adapter in the most ergonomic location with the included

USB extension cable. Advanced Multiple Input Multiple Output (MIMO)

antenna technology with three spatial streams per antenna generates a

maximum theoretical wireless throughput of 450Mbps. WMM®

Quality of Service (QoS) technology prioritizes gaming, Internet calls,

and video streams. LEDs on the front of the adapter convey device

status. Upgrade your computer’s wireless connection to experience the

speed of a 450Mbps network.

FEATURES

• 450Mbps dual band wireless n technology

• Wi-Fi compliant with IEEE 802.11n/g/b/a standards

• USB 2.0 port

• One-touch wireless connection with external Wi-Fi Protected Setup (WPS) button

• 100 cm (3.2 ft.) USB cable to position the adapter in the optimum location

• USB Bus powered

• Multiple Input Multiple Output (MIMO) technology optimizes wireless coverage

• Maximum reliability, throughput, and connectivity with automatic data rate switching

• Supports 64/128-bit WEP, WPA/WPA2-RADIUS, and WPA-PSK/WPA2-PSK wireless encryption

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization

• Easy user setup and intuitive diagnostic utility

• Compatible with Windows operating systems

• Coverage of up to 100 meters outdoor (320 feet)* and 200 meters outdoor (640 feet)*

• 3-year limited warranty

*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical speciﬁ cations. Actual data throughput and coverage

will vary depending on interference, network trafﬁ c, building materials and other conditions.

TEW-684UB

rev: 04.18.2011

450Mbps Dual Band Wireless N USB Adapter

TEW-684UB(V1.0R)

TEW-658BRM

rev: 02.22.2011

SPECIFICATIONS

HARDWARE

Interface • USB 2.0

Standards • IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n

Button • WPS button: enables quick wireless connection with WPS function

Power Consumption • Receive mode: 406mA (max.) • Transmit mode : 428mA (max.)

Supported OS • Windows 7 (32/64-bit), Vista (32/64-bit), and XP

Dimensions (LxWxH) • 72 x 50 x 31 mm (2.8 x 2.0 x 1.2 in.)

Temperature • Operating: 0° ~ 40° C (32° ~ 104° F) • Storage: -20° ~ 60°C (-4°~ 140°F)

Weight • 40 g (1.41 oz)

Humidity • Max. 85% (non-condensing)

Certiﬁ cations • CE, FCC

Wireless

Modulation • CCK/ OFDM - BPSK, QPSK, 16-QAM, 64-QAM, DBPSK, DQPSK

Antenna • 3 Built-in on board antennas

Frequency • 802.11b/g/n: 2.412 ~ 2.484 GHz

• 802.11a/n: 5.15 ~ 5.825GHz (FCC), 5.470 ~ 5.725GHz (ETSI)

Data Rate (auto fallback) • 802.11a: up to 54Mbps

• 802.11b: up to 11Mbps

• 802.11g: up to 54Mbps

• 802.11n: up to 450Mbps

Output Power • 802.11b: -84dBm (typical) at 11mpbs

• 802.11g: -72dBm (typical) at 54Mbps

• 802.11n/g: -65dBm (typical) at 450Mbps

• 802.11n/a: -64dBm (typical) at 450Mbps

Receiving Sensitivity • 802.11b: -84dBm (typical) at 11mpbs

• 802.11g: -72dBm (typical) at 54Mbps

• 802.11n/g: -65dBm (typical) at 450Mbps

• 802.11n/a: -64dBm (typical) at 450Mbps

Encryption • 64/128-bit WEP, WPA/WPA2-RADIUS, WPA/WPA2-PSK

Channels • 802.11b/g/n: 1~11 (FCC), 1~13 (ETSI)

• 802.11a/n: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC), 36, 40, 44, 48 (ETSI)

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,

CONTACT INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web: www.trendnet.com

Email: [email protected]

1-888-326-6061

PACKAGE CONTENTS

TEW-684UB

CD-ROM (Utility & User’s Guide)

Multi-Language Quick Installation Guide

USB cable 100 cm (3.2 ft.)

RELATED PRODUCTS

TEW-691GR 450Mbps Wireless N Gigabit Router

TEW-690AP 450Mbps Wireless N Access Point

TEW-687GA 450Mbps Wireless N Gaming Adapter

NETWORKING SOLUTIONS

450Mbps Dual Band Wireless N USB Adapter

TEW-684UB(V1.0R)
