TRENDnet TEW-726EC Manuale utente

TEW-726EC

rev: 02.21.2013

FEATURES

• Wi-FicompliantwithIEEE802.11nstandard(dualband802.11n2.4GHzor5GHzconnection)

• BackwardscompatiblewithIEEE802.11g,IEEE802.11b,andIEEE802.11anetworks

• Detachableantennas

• Lowprolebracketincluded

• LEDactivityindicator

• InterfacePCIExpress

• MultipleInputMultipleOutput(MIMO)antennatechnology

• Wi-FiMultimedia(WMM)QualityofService(QoS)dataprioritization

• SupportsInfrastructuremodeviaAccessPointandad-hocnetworkviapeertopeercommunication

• Maximumreliability,throughput,andconnectivitywithAutomaticDataRateSwitching

• SupportsadvancedwirelessencryptionuptoWPA2-RADIUS

• CompatiblewithWindows8(32/64-bit),7(32/64-bit),Vista(32/64-bit),andXP(32/64-bit)operatingsystems

• Easyusersetup&diagnosticutilities

• Coverageofupto100metersindoor(330feet)and300metersoutdoor(980feet)*

• 3-yearlimitedwarranty

*MaximumwirelesssignalratesarereferencedfromIEEE802.11theoreticalspecications.Actualdatathroughputandcoverage

willvarydependingoninterference,networktrafc,buildingmaterialsandotherconditions.

N600 Wireless Dual Band PCIe Adapter

TEW-726EC (v1.0R)

TRENDnet’s N600 Wireless Dual Band PCIe Adapter, model

TEW-726EC, upgrades a desktop computer to proven 300 Mbps dual

band wireless speed and coverage.

Quickly connect to a common 2.4 GHz or a less congested 5 GHz

wireless network to seamlessly stream HD video and surf the internet.

Advanced WPA and WPA2 encryption protects your wireless network.

Multiple Input Multiple Output (MIMO) antenna technology increases

wireless coverage and signal strength. WMM®Quality of Service (QoS)

technology prioritizes gaming, Internet calls, and video streams.

PRODUCT OVERVIEW

• Easysetup

• Upgradeyourdesktopto300MbpsDualBandWirelessN

• SeamlesslystreamHDvideooverthelesscongested5GHzband

• Lowprolebracketincluded

• WorkswithastandardPCIExpress(PCIe)slot

• CompatiblewithWindowsoperatingsystems

TEW-726EC

rev: 02.21.2013

N600 Wireless Dual Band PCIe Adapter

TEW-726EC (v1.0R)

SPECIFICATIONS

HARDWARE

Interface • PCIExpress1.0

Standards • IEEE802.11a,IEEE802.11b,IEEE802.11g,IEEE802.11n

LED Indicator • Datatransmission:blinking

• Linkestablished:solid

• WPS(Wi-FiProtectedSetup):blinkingrapidly

• Disconnected:blinkseverytenseconds

Power Consumption • Transmitmode:670mAmax

• Receivemode:350mAmax

Supported OS • Windows8(32/64-bit),7(32/64-bit),Vista(32/64-bit),XP(32/64-bit)

Dimensions • 66x55mm

Weight • 45g(1.6oz)

Temperature • Operating:0°~40°C(32°~104°F)

• Storage:-20°~75°C(-4°~167°F)

Humidity • 90%max(non-condensing)

Certications • CE,FCC

WIRELESS

Modulation • DBPSK,DQPSK,DSSS,CCK,BPSK,QPSK,16-QAM/64-QAMwithOFDM

Antenna • 2x2dBidipoledetachableantennaswithreverseSMAconnector

Frequency • 802.11b/g/n:2.400~2.483GHz

• 802.11a/n:5.150~5.350GHz/5.725~5.825GHz(FCC)

5.150~5.350GHz/5.470~5.725GHz(ETSI)

Data Rate (auto fallback) • 802.11a:upto54Mbps

• 802.11b:upto11Mbps

• 802.11g:upto54Mbps

• 802.11n:upto300Mbps(for2.4or5GHz)

Output Power • 2.4GHz:TypicalRFOutputPower(tolerance+/-2dB)

• 802.11b:18dBm

• 802.11g:18dBm

• 802.11n:HT20:18dBm

HT40:13dBm

• 5GHz:TypicalRFOutputPower(tolerance+/-2dB)

• 802.11a:16dBm

• 802.11n:HT20:13dBm

HT40:13dBm

Receiving Sensitivity • 802.11a:-65dBm(typical)at54Mbps

• 802.11b:-76dBm(typical)at11Mbps

• 802.11g:-65dBm(typical)at54Mbps

• 802.11n:-62dBm(typical)at300Mbps(for2.4or5GHz)

Encryption • 64/128-bitWEP,WPA/WPA2-PSK,WPA/WPA2-RADIUS

Channels • 2.4GHz:1~11(FCC),1~13(ETSI)

• 5GHz:36,40,44,48,149,153,157,161,165(FCC)36,40,44,48,52,56,60,64,100,104,108,112,116,120,124,128,132,

136,140(ETSI)

CONTACT INFORMATION

20675ManhattanPlace,Torrance,CA90501USA

Tel:1-310-961-5500

Fax:1-310-961-5511

Web:www.trendnet.com

Email:[email protected]

1-888-326-6061

PACKAGE CONTENTS

TEW-726EC

CD-ROM(Utility&User’sGuide)

Multi-LanguageQuickInstallationGuide

Standard&LowProleBrackets

RELATED PRODUCTS

TEW-692GR N900DualBandWirelessRouter

TEW-691GR N450WirelessGigabitRouter

TEW-731BR N300WirelessHomeRouter

NETWORKING SOLUTIONS

N600 Wireless Dual Band PCIe Adapter

TEW-726EC (v1.0R)

TRENDnetisaregisteredtrademark.OtherBrandsandproductnamesaretrademarksoftheirrespectiveholders.InformationprovidedinthisdocumentpertaintoTRENDnetproductsandissubjecttochangeatanytime,without

notice.Forthemostrecentproductinformationpleasevisithttp://www.trendnet.comCopyright©TRENDnet.AllRightsReserved.
