TRENDnet TFC-2000S20 Manuale utente

This Fiber Converter with SC-Type connector transforms

1000Base-T UTP/STP media to 1000Base-LX single-mode. The

1000Base-T port supports auto-MDIX. Designed to connect up to

20KM, the converters are the perfect Gigabit, single-mode solution.

TFC-2000S20 (v1.0R)

1000Base-T to 1000Base-LX

SC-Type Single-Mode Fiber Converter

TFC-2000S20

rev:03.02.2007

• Compliant with IEEE 802.3ab 1000Base-T, 802.3z 1000Base-LX

• One 1000Base-T Auto-MDIX RJ-45 port

• One 1000Base-LX single-mode SC-type Fiber port

• Supports LLCF (Link Loss Carry Forward)

• Provides Dip switches to enable LLCF function in both TX and Fiber port

• Diagnostic LEDs

• Plug & Play, Hot Swappable

• Optional 19” Fiber Converter Chassis (TFC-1000) holds up to 10 Fiber Converters

• 5-Year Warranty

FEATURES

TFC-2000MSC 1000Base-TX to 1000Base-SX

SC-Type Multi-Mode Fiber Converter

Frame Packet Size

Network Media

Protocol

Minimum Cable Length

Transfer Rate

Ports

Dip Switch

Diagnostic LED

Dimensions

Power Adapter

Weight

• IEEE 802.3ab1000Base-T • IEEE 802.3z 1000Base-LX

• Dip Switch 1: ON: TX Port LLCF Enable OFF: TX Port LLCF Disable

• 1000Base-T: Cat. 5e, 6

• 1000Base-LX: 9/125ìm Single-Mode Duplex SC-Type Fiber Cable

• CSMA/CD

• 50 Meters

• 64 to 1536 Bytes

• 1 x 1000Base-T RJ-45 Port • 1 x 1000Base-LX: Single-Mode SC-Type Fiber Port

• 1000Mbps (Half/Full Duplex)

• 9V DC, 700mA External Power Adapter

• Per Device: Power

• 3.6 Watts (max)

Standard

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

1000Base-T to 1000Base-LX SC-Type Single-Mode Fiber Converter

TFC-2000S20 (v1.0R)

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

SPECIFICATIONS

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

• Dip Switch 2: ON: Fiber Port LLCF Enable OFF: Fiber Port LLCF Disable

* After changing the DIP Switch settings, power cycle the Fiber converter.

• Per port (TX): 1000Mbps, Link/Activity, Full Duplex/Collision; (FX): Link/Activity, Full Duplex/Collision

• 85 x 125 x 25mm (3.35 x 4.92 x 0.98in.)

• 300g (10.6oz.)

Humidity

Temperature

Certification

• Operating : 0°C ~ 45°C (32°F ~ 113°F) • Storage : -40°C ~ 70°C (-40°F ~ 158°F)

• 5% ~ 90% RH

• CE, FCC

20km

TFC-2000S20 -8 -23 15

Sensitivity Power Budget (dBm) Distance

Wavelength

Media Power Output (dBm)

(1270 nm~1355nm)

1310nm

(9/125 µm)

SMF

RELATED PRODUCTS

TFC-2000S50

TFC-1000 10-Bay Fiber Chassis

1000Base-T to 1000Base-LX

SC-Type Single-Mode Fiber Converter

PACKAGE CONTENTS

• Power Adapter

• TFC-2000S20

• Multi-Language Quick Installation Guide
