TRENDnet TU-IDES Manuale utente

The IDE to SATA Converter (TU-IDES) allows you to connect IDE

devices such as CD, DVD and hard disk drives to a Serial ATA

port on your computer's motherboard.

Without software installation required, simply connect power and

data cables to IDE devices to SATA connector on your computer.

TU-IDES(V1.0R)

IDE Device to Serial ATA Converter

TU-IDES

rev:05.15.2008

• Connect any IDE CD, DVD or hard drive device to an available Serial ATA port

• Use your current IDE device on new SATA motherboards

• Utilizes Serial ATA 1.0 and hot-pluggable technology

• Master/slave hard drive emulation supported

• Supports PIO mode 0~4 and Ultra DMA mode 0~7

• Supports ATAPI Packet command set, and 48-bit LBA addressing

• Supports additional ATA commands for serial ATA SCR access

• Power save mode built-in

• Serial ATA Built In Self Test (BIST) ready

• 2-Year Warranty

FEATURES

medianet

Supported OS

Temperature

Input

Output

Cables

Humidity

Certification

• ATA 33/66/100/133, SATA 1.0

• Any OS that supports ATA and SATA

• -20ºC to 60ºC (-4ºF to 140ºF)

• 7-pin female SATA data connector

• With wires: 40g (1.4oz.)

• 0~90%, (Non-Condensing)

• 57 x 35 x 12mm (2.3 x 1.4 x 0.4 in.)

• FCC, CE

Dimensions

Weight

Power Consumption

Standard

Hardware

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

PACKAGE CONTENTS

RELATED PRODUCTS

• TU-IDES

• TU2-IDSA USB to IDE/SATA Converter

• Multi-Language Quick Installation Guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

SPECIFICATIONS

• 1 x 25cm (10in.) SATA cable

• 1 x 10cm (4in.) Y power cable

• 78 mA

• 4-pin power connector

• 40-pin IDE female connector to IDE device

• 1x SATA cable • 1 x Y power cable

• Main: 15g (0.6oz.)

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

TU-IDES(V1.0R)

IDE Device to Serial ATA Converter

IDE to Serial

ATA Converter

(TU-IDES)

To Connector of Serial

ATA Port

IDE

Device

Power

Cable

To PC Power

Supply Connector

Motherboard
