TFM-560X User’s Guide

Rev.1.00 - 1 -

TABLE OF CONTENT

1. Contents of Package .................................................................2

2. Comprehensive Modem Installation Instructions...................3

2.1 System Requirements ...........................................................3

2.2 Hardware Installation.............................................................3

2.3 System Setup ........................................................................5

2.3.1 Setup Instructions for Windows 98/Me/2000/XP.......................5

2.3.2 Uninstall Modem from Windows 98/Me/2000/XP......................7

2.4 Testing your modem ..............................................................9

2.5 Install Communication Software............................................9

3. Troubleshooting ......................................................................10

Appendix 1: Modem Specifications ...........................................12

Appendix 2: Government Compliance.......................................13

TFM-560X User’s Guide

Rev.1.00 - 2 -

Section 1 Contents of Package

- TFM-560X

- Quick Installation Guide (Multi-Language)

- Software, Driver & User’s Guide CD-ROM

- Power Adapter (9VAC, 1000mA)

- 1 x RJ11 Telephone Cable

- 1 x RS-232 Serial Cable

Please contact the place of purchase if any of the above listed items are missing.

TFM-560X User’s Guide

Rev.1.00 - 3 -

Section 2 Comprehensive Modem Installation Instructions

Section 2.1 System Requirements

The modem operates on a personal computer equipped with the following:

zWindows 95 / 98 / 98SE / ME / NT 4.0 / 2000 / XP/ 2003 Server, MacOS, Linux, or any control

device with RS-232 interface

zOne vacant RS-232C (COM) port

Section 2.2 Hardware Installation

Please refer to Fig. 2 - 1 and proceed to following steps for how to insert your modem into the computer and

connect telephone wire.

Model: TFM-560X

Figure 2-1 External Modem Rear Panel

1. Turn off and unplug your computer from the AC outlet.

2. Unplug any peripheral devices (keyboard, monitor, etc) from your computer.

3. Connect the male end of the serial cable into the connector marked RS-232 on the rear panel of the

modem. (see Figure 2-1)

4. Connect the female end of serial cable to the available serial port marked COMx, RS-232 or Serial on

the back of your computer.

5. Plug one end of telephone cord into the "LINE" jack at the modem's bracket. Plug the other end of the

telephone cord into the telephone wall jack

6. Some model may include a phone jack for an optional telephone. If you wish to use a phone through the

same telephone wall jack as the modem when the modem is not in use, plug the telephone cord of the

phone into "PHONE" jack at the modem's bracket now. Lift the handset and listen for a dial tone to

check for a properly connection.

7. Plug the power adapter into a AC outlet, and insert its plug into the "POWER" jack on the rear panel of

your modem after you verify the modem power switch is in the OFF position.

8. Plug the power cords, and peripherals back into the computer.

9. Turn on the modem power switch. Then turn the computer on.

TFM-560X User’s Guide

Rev.1.00 - 4 -

10. This finishes the hardware installation for external modem. If you have not encountered any problems,

you can go to Section 2.5 Install Communication Software. If you are having problems, see Section

3 Troubleshooting.

NOTE: The telephone wall jack you use must be for an ANALOG phone line (the type found in most homes).

Many offices are equipped with digital phone lines. Please be sure you know which type of line you

have.

The modem will be damaged if you use a digital phone line.

Indicator Lights

Your external modem features LED indicators on the front panel that report modem status :

MR Modem Ready Lights when the modem is turned on.

TR Terminal Ready Lights when the computer is ready to send or receive data. Indicates the status of the

DTR signal from the terminal or computer.

SD Transmit Data Flashes whenever data or commands are transmitted from the serial port of your

computer or other device to the modem.

RD Receive Data Light flashes when data is sent from the modem to your computer or other serial device.

At high speeds light may appear continuously on.

OH Off Hook Lights when the modem is off hook.

CD Carrier Detect Lights when the Data Carrier Detect (DCD) signal from the modem to the computer is on.

RS Request to Send Lights when the computer can accept data from the modem. The light will turn off

when the modem is set for hardware flow control and the computer is not ready, preventing data flow

from the modem

CS Clear to Send Lights when the modem can accept data from the computer.

The light will turn off when the modem is set for hardware flow control and the modem data buffer is full,

pre-venting data flow from the computer.

TFM-560X User’s Guide

Rev.1.00 - 5 -

Section 2.3 System Setup

Section 2.3.1 Setup instructions for Windows 98 / ME / 2000 / XP

STEP 1. Insert the Modem Driver CD-ROM disk attached with your modem into the CD-ROM drive device,

Then run <CD-ROM letter>:\Drivers\Setup.exe as shown in figure.

Then click on OK

STEP 2. And then, a prompt screen will ask you to ensure to install the modem driver.

Then click OK.

The setup utility will copy the needed files into windows system.

[Windows XP only]

STEP 2-1. Choose “Install the software automatically (Recommended)” and click “NEXT>” button.

TFM-560X User’s Guide

Rev.1.00 - 6 -

[ Windows 2000 & XP only ]

STEP 3. The prompt screen will ask you to ensure the driver for your modem as shown in figure when the

system have been restarted.

(Windows 2000) (WindowsXP)

Click on Yes to finish installation procedure. Then, click on Continue Anyway.

[Windows XP only]

STEP 3-1. The screen will prompt you the installation procedures be done.

Click on “Finish” button.

TFM-560X User’s Guide

Rev.1.00 - 7 -

Section 2.3.2 Uninstall Modem from Windows 98/Me/2000/XP

STEP 1. Right click on My Computer icon on Desktop and then choose Properties as shown in figure.

(Windows 98/Me/2000) (Windows XP)

STEP 2. Choose Hardware tab in System Properties window as shown in figure.

(Windows Me/2000) (Windows XP)

Then, click on Device Manager.

* Windows 98 users, please skip this step!

TFM-560X User’s Guide

Rev.1.00 - 8 -

STEP 3. (Windows 98)

Expand Modem item in Device Manager tab and choose Agere OCM Serial Modem as shown in

figure.

Click on Remove button.

(Windows Me/2000/XP)

Expand Modem item in Device Manager tab and choose Agere OCM Serial Modem as shown in

figure.

(Windows Me/2000) (Windows XP)

Right click on Agere OCM Serial Modem item and select Uninstall.

STEP 4. A prompt screen will ask you to ensure to remove this device from your system as shown in figure.

(Windows 98/Me/2000) (Windows XP)

Click on OK to complete the uninstall procedures.

TFM-560X User’s Guide

Rev.1.00 - 9 -

Section 2.4 Testing Your Modem

Before you set up your software, start with a quick test to check that your modem is working. Once you have

determined that your modem is setup properly, go on to Section 2.5 Install Communication Software to

install your communications software. If you are having problems, see Section 3 Troubleshooting.

Click on Start and point to Setting. Then click on Control Panel. When the Control Panel window opens.

Scroll down to the Modem icon and double click on it. Click on the Diagnostics tab and highlight the COM

port for your modem. Then click on More Info, your computer will automatically communicate with your new

modem using AT commands and receiving responses from your modem. Alist of response means the modem

is setup properly.

Section 2.5 Install Communication Software

You can install the communication software from the CD-ROM disc attached with your new modem. Please

consult the software manual in the CD-ROM disc for the detail of software installation.

You do not have to use the communication software attached with your new modem. The modem was

designed for and tested using a wide range of communications software packages. Many communication

applications identify the modem automatically and configure themselves for the correct operating settings.

Some of the communication applications will ask you to select the type of modem you are using. Select a

Generic Fax class 1 modem will let you use basic communication and fax functions.
