TRENDnet TE100-P1P - Parallel Print Server Manuale utente

TE100-P1P

Quick Installation Guide

Table of Contents

Version 10.08.2007

English ...................................................................................................... 1

1. Before You Start

2. How to Install .....................................................................................

3. Configure the Print Server .................................................................

4. Add the Printer to your PC .................................................................

.................................................................................

Troubleshooting ........................................................................................

1. Before You Start

English

Package Contents

System Requirements

Application

?CPU: 300MHz or above/ 800MHz or above (Windows Vista)

?Memory: 256MB RAM or above/ 512MB RAM or above (Windows Vista)

?indows Vista/2003 Server/XP/2000/ME/98SE, Unixware, Linux,

Mac OS X

D-ROM Drive

TE100-P1P

Quick Installation Guide

Utility CD-ROM?

?AC Power Adapter (5V DC, 2.5A)

Cable/DSL

Modem

1-Port

Parallel Print Server

(TE100-P1P)

10/100Mbps

Workstations with

Fast Ethernet PCI Adapter

(TE100-PCIWN)

Parallel Printer

Cable/DSL 4-Port

Broadband Router

(TW100-S4W1CA)

Internet

*Mac Systems are only compatible with Post-Script printers

2. How to Install

English

Note: Please power off all printers before connecting them to the print server.

1. Connect a RJ-45 network cable

from a Switch/Router to the LAN

port of the Print Server.

2. Connect the AC Power Adapter to

the Print Server and then to a

power outlet.

4. Power ON printer.

3. Connect the Parallel Printer to the

Parallel port on the Print Server.

English

1. Insert the Utility CD-ROM into

your computer's CD-ROM Drive

and then click Utility > PS Utility.

3. Click Start > Programs >

TRENDnet > PS Utility, and then

click PS-Utility v3.11.

2. Follow the InstallShield Wizard

instructions. Click Finish.

3. Configure the Print Server

Note: The Print Server can be managed using the PS-Utility or a web browser.

For Mac users, change your computers IP address to 192.168.0.X (where X is

an available number from 2-254). Since the Print Server's default IP address is

192.168.0.1, make sure no other network devices are assigned an IP address

of 192.168.0.1. Then enter http://192.168.0.1 in your web browser to access

the Print Server's Web Utility.

For Windows Users

6. Click Show Web Setup.

5. Click OK.

English

4. Select the Print Server and click

Change IP Address.

Manually assign the IP Address of

the Print Server and then click OK.

Note: The IP Address must match

the network segment of your

network.

Print Server configuration is now complete.

To ensure the highest level of customer service and support, please take a moment to

Thank you for choosing TRENDnet

English

4. Add the Printer to your PC

Note: For printing instructions for Windows ME and 98SE, please consult the

User's Guide included on the Utility CD-ROM.

Windows Vista/2003 Server/XP/2000

2. Select the print server, select the

desired port and then click Add

Printer.

1. Click PS Wizard and then click

Win 2000/XP/Vista.

3. Click Select from manufacturer

list. Select the appropriate driver

for your printer and then click Next.

English

Add Printer is now complete.

For detailed information regarding the TE100-P1P configuration and advanced

settings, please refer to the User's Guide on the Utility CD-ROM or

TRENDnet's website at www.trendnet.com

5. Click Print Test Page.

4. Click Next.

7. Click Finish.

8. Repeat steps 1 to 7 to add the

printer to other computers on the

network.

6. Click OK.

Q1.

A1.

Q2.

A2.

Q3.

A3.

Q4.

A4.

The PS Wizard / PS Utility is unable to see my printer server. What should I

do?

First, double check your hardware connections; make sure that the print

server and printer are powered ON and are properly connected. Second, click

Discover. Third, disable any software firewall programs (e.g. ZoneAlarm). If

your computer is running Windows XP or Vista, disable the built in firewall

program.

I successfully added a printer to my computer and I can print a test page, but I

cannot print anything from Microsoft Word or other applications.

Make sure to set the newly installed network printer as your default printer.

Click Start and then click Printers & Faxes, verify that your printer icon has a check

on it.

I configured my print server to automatically receive an IP Address from a

DHCP server, and now I cannot go into the Print Server’s web utility.

Open PS-Utility v3.11 (See 3. Configure the Print Server) to locate your print

server’s IP Address.

How do I setup the TE100-P1P on a Mac?

Type in http://192.168.0.1 in you browser to logon to the built-in web

configuration.

If you still encounter problems or have any questions regarding the TE100-P1P, please

refer to the User's Guide included on the Utility CD-ROM or contact TRENDnet’s

Technical Support Department.

Troubleshooting

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.
