TRENDnet TEW 632BRP - Wireless Router Manuale utente
The Wireless N Home Router delivers the highest level of security,
12x the speed and 4x the range of wireless g products. Install the
product in minutes with Easy-Go installation and seamlessly stream
live media, download files, play games and talk Online all at the
same time and with no wireless lag.
The latest in wireless encryption and a secure firewall provide the
ultimate in wired and wireless security. Advanced MIMO antenna
technology delivers superior range and eliminates dead spots. A
quick and intuitive installation process, remote man-agement
capabilities and a 3-year warranty make this product well suited for
your most demanding networking needs.
TEW-632BRP
Wireless N Home Router
TEW-632BRP
rev:09.13.2007
• Wi-Fi compliant with IEEE 802.11n (draft 2.0) and IEEE 802.11b/g standards
• 4 x 10/100Mbps Auto-MDIX LAN port and 1 x 10/100Mbps WAN port (Internet)
• Supports Cable/DSL modems with Dynamic IP, Static IP, PPPoE, PPTP, L2TP & BigPond connection types
• High-speed up to 300Mbps data rate using IEEE 802.11n connection
• 2 external antennas support high speed performance and great coverage with MIMO technology
• Firewall features Network Address Translation (NAT)
• Support Wi-Fi Protected Setup (WPS) for easy connection
• Universal Plug and Play (UPnP) and Application Level Gateway support for internet applications such as email, FTP, gaming,
remote desktop, Net Meeting, telnet and more
• Provides additional security of enable/disable wireless SSID, Internet Access Control (MAC Address, Domain & IP Filtering)
• Easy management via web browser and remote management
• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK
• Works with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
• Coverage up to 100 meters (330ft.) indoor;(depends on the environment)
• Coverage up to 300 meters (980ft.) outdoor;(depends on the environment)
• 3- year warranty
FEATURES
** Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will cary
depending on interference, network traffic, building materials and other conditions.
Wireless N Home Router
TEW-632BRP
Power Consumption
Internet Access Control
LED Indicator
Dimensions (LxWxH)
Weight
Temperature
• Max. 90% (Non-Condensing)
• 7W
• Operating: 0° ~ 40° C (32° ~ 104° F)
• Power, LAN1~LAN4, WAN, WLAN
• 5V DC, 2.5A external power adapter
• 195 x 120 x 30 mm (7.7 x 4.7 x 1.1 inches)
• 335g (11.8oz)
• CE, FCC
Humidity
Emissions
Hardware
SPECIFICATIONS
Power Adapter
• Storage: -20° ~ 60° C (-4° ~ 140° F)
Standards
LAN
Connection Type
• 1 x 10/100Mbps Auto-MDIX port (internet)
• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
• Dynamic IP, Static (Fixed) IP, PPPoE, PPTP, L2TP, BigPond
WAN
• 4 x 10/100Mbps Auto-MDIX ports
• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)
TEW-632BRP
rev:09.13.2007
WPS Button • WPS configuration
DMZ
DNS
• UPnP IGD 1.0 Compliant
• DMZ host & Virtual Servers
• Static or WAN assigned DNS servers; 3 verified services for DDNS
UPnP
Logging • 5 types event logging
• Email report logging report
• MAC Address Filter, Domain/URL Filter, Protocol/IP Filter
Frequency
Media Access Protocol
Data Rate
Receiving Sensitivity
Output Power
Security
Channels
• 2 x 2dBi fixed dipole antenna
• 2412~2484MHz ISM band
• 802.11b: 17dBm (typical)
• 1~11 (US), 1~13 (EU)
• CSMA/CA with ACK
• 802.11b: -85dBm (typical) @ 11Mpbs
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
Wireless
Antenna
• 802.11n (draft 2.0) : up to 300Mbps
• WEP(HEX/ASCII): 64/128-bit
• 802.11n: -62dBm (typical) @ 300Mbps
• 802.11g: -68dBm (typical) @ 54Mbps
• 802.11n: 13dBm (typical)
• 802.11g: 13dBm (typical)
• Enable/Disable SSID
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
• WPA(AES/TKIP): WPA/WPA2, WPA-PSK/WPA2-PSK
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
• Easy-Go installation CD-ROM
• TEW-632BRP
• Multi-language quick installation guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
RELATED PRODUCTS
TEW-630APB
TEW-621PC
TEW-623PI 300Mbps Wireless N-Draft PCI Adapter
300Mbps Wireless N-Draft Access Point
300Mbps Wireless N-Draft PC Card
• Power Adapter (5V DC, 2.5A)
• 1.5 meters (5 ft) Cat. 5 Ethernet cable
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web:
Email: [email protected]
www.trendnet.com
Wireless N Home Router
TEW-632BRP
TEW-624UB 300Mbps Wireless N USB 2.0 Adapter
HD
DATA
Wireless N Home Router
(TEW-632BRP)
300Mbps, share multimedia throughout the house
