Mister 50

Atomizing Humidiﬁer

H-MIST50-1008

TECHNICAL ENGINEERING SPECIFICATION

Air Purification Systems

Performance:

Save on Energy Costs and Improve Comfort•

Increasing a Home’s Relative Humidity Makes it Feel More•

Comfortable at 68ºF / 20ºC than it does at 73º F / 23ºC at a Low

Relative Humidity Level

Lower Thermostat Settings Deliver Substantial Savings on Monthly•

Energy Bills

Evaporative Capacity 10.7 Gallons At 60 PSI•

Features:

Installs with Ease Even in the Tightest Situations•

All Units Come with a Self-Piercing Saddle Valve for Added•

Installation Convenience

Tilt-Out Mounting Allows Fast Access to the Key Parts of the Unit•

Unique Multi-Position Nozzle Assembly Allows for Precise,•

Reliable Moisture Delivery

Maximum Evaporative Capacity up to 11 Gallons per Day•

How Humidiﬁers Work:

Atomizing humidiers are installed onto the supply duct, where a

nozzlegeneratesasupernemistthatisdistributedintothehomeand

quickly absorbed into the air. The combination humidistat / thermostat

automatically controls the operations to ensure that the proper amount

of humidity is added to the home. A built-in thermostat starts the unit

when the temperature in the warm air duct reaches the proper setting.

The humidistat, installed either on the wall or in the cold air return duct,

turns on the unit.

Warranty:

2-year Limited Warranty•

www.trioninc.com

Mister50

Atomizing Humidiﬁer

of Air System Components, Inc.Trion®reservestherighttoreviseormodifyproductsand/orspecicationswithoutnotice.

Allproductspecicationsreectavailableinformationattheprintingofthisbrochure.

Trion®| 101 McNeill Road | Sanford, NC 27330 | Phone: 800-884-0002 | Fax: 800-458-2379

Web: www.trioninc.com | Email: [email protected]

H-MIST50-1008

TECHNICAL ENGINEERING SPECIFICATION

Air Purification Systems

Model Mister50

PART NO. 351367-101

TYPE OF UNIT Atomizing

MAX EVAPORATIVE CAPACITY 11 Gallons Per Day – GPD (1.7 LPH)

VOLTS/HZ 24 V / 60 HZ

DIMENSIONS 6” W X 6” H X 23/4” D (152w x 152h x 70d Mm) / Packaging 61/4” W x 6” H X 91/4”D (159w x 152h x 235d mm)

WEIGHT 11/2 Lbs. (0.68 Kg.) / Shipping – 3 Lbs. (1.36 Kg.)

NOZZLE 0.75 GPH (2.84 LPH) Stainless Steel, 60° Hollow Oil Nozzle

Installation Options

UpowBottom

Return

Downow

Counterow

Upow

Side Return

Horizontal

Mister50

Evaporator Supply Capacity

Furnace Temp. Mister 50

°F °C Gallons

per Day

Liters

per Hour

100°F 37.7°C Do Not Use at this Temperature

120°F 48.8°C 11.0 1.7

140°F 60°C 11.0 1.7

Evaporator Supply Capacity

Water Pressure Evaporative Capacity

Gallons per

Day

Liters

per Hour

Gallons

per Day

Liters

per Hour

40 PSI 2.78 9.0 1.4

60 PSI 1.14 10.7 1.7

80 PSI 5.52 13.2 2.0
