1988-2004 Ford F-Series Pickups
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 2
WIRING INFORMATION 1988 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire
reverse polarity, test using
driver’s door lock switch)
BLACK/ORANGE At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire
reverse polarity, test using
driver’s door lock switch)
PINK/GREEN At Harness In Passenger Kick
Panel
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 3
WIRING INFORMATION 1989 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire) BLACK/ORANGE At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire) PINK/GREEN At Harness In Passenger Kick
Panel
Test door lock wires using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 4
WIRING INFORMATION 1990 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire) BLACK/ORANGE At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire) PINK/GREEN At Harness In Passenger Kick
Panel
Test door lock wires using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 5
WIRING INFORMATION 1991 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire) BLACK/ORANGE At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire) PINK/GREEN At Harness In Passenger Kick
Panel
Test door lock wires using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 6
WIRING INFORMATION 1992 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire) PINK/YELLOW At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire) PINK/GREEN At Harness In Passenger Kick
Panel
Test door lock wires using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP YELLOW At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN RED At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN RED/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 7
WIRING INFORMATION 1993 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK (5-wire) PINK/YELLOW At Harness In Passenger Kick
Panel
POWER DOOR UNLOCK (5-wire) PINK/GREEN At Harness In Passenger Kick
Panel
Test door lock wires using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE At Courtesy Light Under Dash
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Alternator
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP YELLOW At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN RED At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN RED/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 8
WIRING INFORMATION 1994 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
SECOND ACCESSORY WIRE BLACK/GREEN Ignition Harness
THIRD ACCESSORY WIRE GRAY/YELLOW (18gauge) Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE Harness In Driver’s Kick Panel
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Harness Along Firewall By
Brake Pedal
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 9
WIRING INFORMATION 1995 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
SECOND ACCESSORY WIRE BLACK/GREEN Ignition Harness
THIRD ACCESSORY WIRE GRAY/YELLOW (18gauge) Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE Harness In Driver’s Kick Panel
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Harness Along Firewall By
Brake Pedal
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
CAR ALARM AND REMOTE START INSTALLATION GUIDE
Copyrght 2002-2004 Triple S Customs 10
WIRING INFORMATION 1996 Ford F-Series
WIRE WIRE COLOR LOCATION
12V CONSTANT WIRE YELLOW Ignition Harness
12V IGNITION WIRE RED/LT.GREEN Ignition Harness
12V ACCESSORY WIRE GRAY/YELLOW Ignition Harness
SECOND ACCESSORY WIRE BLACK/GREEN Ignition Harness
THIRD ACCESSORY WIRE GRAY/YELLOW (18gauge) Ignition Harness
STARTER WIRE RED/LT.BLUE Ignition Harness
PARKING LIGHTS (+) BROWN At Headlight Switch
POWER DOOR LOCK PINK/YELLOW Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
POWER DOOR UNLOCK PINK GREEN Harness In Passenger’s Kick
Panel
Models with OEM keyless entry: negative trigger, models without OEM keyless entry: 5-wire reverse
polarity- test using driver’s lock switch.
DOOR TRIGGER/DOMELIGHT
SUPERVISION (+)
BLACK/LT.BLUE Harness In Driver’s Kick Panel
BRAKE WIRE (+) LT.GREEN Harness In Driver’s Kick Panel Or
Brake Pedal Switch
TACHOMETER WIRE TAN/YELLOW
WHITE/BLACK (Diesels)
At Ignition Coil
At Harness Along Firewall By
Brake Pedal
DIESEL WAIT-TO-START (-) BLACK/PINK Behind Instrument Cluster
HORN TRIGGER (-) DARK BLUE Harness At Steering Column
LEFT FRONT WINDOW UP RED At Driver Window Motor Inside
Door
LEFT FRONT WINDOW DOWN YELLOW At Driver Window Motor Inside
Door
RIGHT FRONT WINDOW UP RED/BLACK Harness In Driver’s Kick From
Driver Door
RIGHT FRONT WINDOW DOWN YELLOW/BLACK Harness In Driver’s Kick From
Driver Door
Questo manuale è adatto per i seguenti modelli
1
Indice
Manuali Allarme auto popolari di altre marche
Federal Signal Corporation
Federal Signal Corporation Pathfinder Siren Series Manuale
Falcon
Falcon Predator XL3 Guida utente
Audiovox
Audiovox Auto Security XR91 Istruzioni operative
Clifford
Clifford Sabre II Manuale utente
CrimeStopper
CrimeStopper CS-8717 Guida rapida
Ultra Start
Ultra Start 450 SERIES Manuale utente
