Tripp Lite IS250 Manuale utente
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: IS250
Isolation Transformer-Based Power Conditioner - Superior line noise reduction and spike suppression
Highlights
Complete line isolation, noise filtering and surge suppression is ideal for
sensitive equipment
250 watts, 2 outlets, 6-ft. power cord
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases
Description
Tripp Lite Isolator series isolation transformer-based power conditioners offer complete line isolation, continuous noise filtering and enhanced normal
and common mode surge suppression. Internal low-impedance isolation transformer component with Faraday Shield offers 100% isolation from the
input AC line. Secondary neutral to ground bonding eliminates common mode noise, providing an isolated ground reference for sensitive equipment
and an inexpensive alternative to the installation of dedicated circuits and site electrical upgrades. Removes EMI/RFI noise, utility switching
transients, background spikes generated by other on-site loads and utility or lightning related surge conditions. Additional surge suppression
components placed at both the line input and transformer output combined with full line isolation offers continuous line filtering of a full range of
power line noise in all modes. Continuous transformer filtering with no wearable parts uniquely reduces surges in the worst of power environments to
harmless levels. Reduces 6000V IEEE C62.41 Cat A&B ring wave and combination wave test surges to only 0.5V common mode. Model IS250
offers 250 watts capacity with 2 widely spaced output receptacles, a 6-ft power cord, circuit breaker overload protection and lighted power switch.
Rugged all-metal unit housing ships ready for upright tower or wallmount placement in industrial, medical, office or network environment.
PLUG/OUTLETS: Input: NEMA 5-15P/Output: 2 NEMA5-15R
ELECTRICAL: 120V AC, 60Hz, 2.1A, (Requires NEMA5-15R wall receptacle)
FORMAT: Upright tower with keyhole flanges for wall mount placement
ISOLATION: Transformer based line isolation with Faraday shield
Applications
Offers fully isolated ground reference with enhanced surge and noise filtering for sensitive point of sale (POS) equipment,
telecommunications systems, diagnostic testing and precise measurement devices, sophisticated CAD/CAM workstations, computer
networking equipment and other pieces of sensitive electronic equipment.
Package Includes
IS250 Isolation transformer system
Instruction manual with warranty information
Features
Tripp Lite Isolator series isolation transformer-based power conditioners offer complete line isolation, continuous noise filtering and
enhanced common mode surge suppression
Supports combined loads up to 250 watts continuous/2.1A at 120V
Isolation transformer with Faraday Shield offers 100% isolation from the input AC line
Neutral to ground bonding at the secondary eliminates common mode noise and provides an isolated ground reference for sensitive
equipment
Isolation transformer design serves as an inexpensive alternative to the installation of dedicated circuits and site electrical upgrades
Removes EMI/RFI noise, utility switching transients, background spikes and power problems generated by other on-site loads, utility
grid-switching and lightning related surges
Line isolation with additional surge suppression components offer continuous line filtering of a full range of power line noise in all modes
Continuous transformer filtering with no wearable parts reduces surges in the worst of power environments to harmless levels
Includes 2 widely-spaced NEMA5-15R output receptacles, 6 ft power cord, circuit breaker overload protection and lighted power switch
Rugged all-metal housing ships ready for upright tower or wallmount installation
Specifications
OVERVIEW
Amp Capacity 2.1A at 120V AC
Efficiency 96%
Form Factor Small tower format, wall mountable
Input Plug Type NEMA 5-15P
Let-through Voltage
(Combination Wave)
L-N:
Let-through Voltage (Ring
Wave)
L-N:
Noise Suppression Rating 33-65dB normal mode; >80dB common mode
Nominal Voltage / Frequency 120V / 60Hz
Output Receptacle Qty / Type 2 NEMA 5-15R
Over Current Protection Yes, 2A circuit breaker
Suppression Joule Rating 680 Joules
Surge Test Conditions Per ANSI/IEEE C62.41 - (IEEE587) Cat. A & B test waveforms
Total Harmonic Distortion less than 1%
Transformer Type Low impedence isolation transformer
VA / Watt Capacity 250
INPUT
Input cord length (ft.) 6
Input cord length (m) 1.83
PHYSICAL
Shipping weight (lbs) 13.7
Shipping weight (kg) 6.21
Cooling method Convection
Unit Dimensions (HWD/in) 4.75 x 4.75 x 7.5
Unit Dimensions (HWD/cm) 12.07 x 12.07 x 19.05
Shipping Dimensions
(HWD/in)
5.75 x 7.25 x 9
Shipping Dimensions
(HWD/cm)
14.61 x 18.42 x 22.86
Unit weight (lbs) 12.8
Unit weight (kg) 5.81
Receptacle Color Black
WARRANTY
Product Warranty Period
(Worldwide)
2-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=226.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
