Tripp Lite U444-06N-V-C Manuale utente

Owner’s Manual

USB 3.1 Gen 1 USB-C™

to VGA Adapter

Models:

(Charging) U444-06N-V-C, U444-06N-VB-C

(USB-A and USB-C Hub Ports) U444-06N-VU-C,

U444-06N-VUB-C

(Gigabit Ethernet+USB-A Hub Port+Charging)

U444-06N-VGU-C, U444-06N-VGUB-C

USB Type-C and USB-C are trademarks of USB Implementers Forum

PROTECT YOUR INVESTMENT!

peace of mind. You could also win an ISOBAR6ULTRA

surge protector—a $100 value!

www.tripplite.com/warranty

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

Español 9 • Français 16 • Русский 23

17-12-057-9336FA.indb 1 12/12/2017 12:49:40 PM

Package Includes

Product Features

• U444-06N-V-C, U444-06N-VB-C, U444-06N-VU-C,

U444-06N-VUB-C, U444-06N-VGU-C or

U444-06N-VGUB-C

• Owner’s Manual

Note: This section lists features for all USB Type-C models

referenced in this manual. See the USB Type-C Features

chart to determine which features your model supports.

• Supports USB DisplayPort Alternate Mode for

connecting a VGA monitor via a USB-C port

• Supports VGA video resolutions up to

1920 x 1080, including 1080p (60 Hz)

• Ethernet port supports true 10/100/1000 Mbps

network speeds

• USB-A and USB-C hub ports support data transfer

rates up to 5 Gbps; backward compatible with

previous USB generations

Optional Accessories

• P502-Series High-Resolution VGA Cables

• U322-Series USB 3.0 A/B Device Cables

• U326-Series USB 3.0 Micro-B Device Cables

• N201-Series Cat6 Gigabit Snagless Patch Cables

• U420-003 USB 3.1 Gen 1 USB-C Male/Male

Cable – 3 ft.

17-12-057-9336FA.indb 2 12/12/2017 12:49:40 PM

Product Features

USB Type-C Features

Models

U444-06N-V-C /

U444-06N-VB-C

U444-06N-VU-C /

U444-06N-VUB-C

U444-06N-VGU-C /

U444-06N-VGUB-C

VGA Port Y Y Y

USB-A Hub Port N Y Y

Gigabit Ethernet Port N N Y

USB-C Port Charging Support Y Y Y

USB-C Port Data Support N Y N

• USB-C port supports both data transfer and USB

Power Delivery (PD) charging with power input up to

20V 3A (60W)

• Plug and play; no software or drivers required

17-12-057-9336FA.indb 3 12/12/2017 12:49:40 PM

Installation

Note: When the unit is connected to the USB-C port on your

computer and to a network via Cat5e/6 cabling, a network

connection will be automatically established. If no connection

is made, you can manually establish one by going to your

computer’s network settings page. For example, on a Mac

you would navigate to the Network section found in System

Preferences, click the ‘Assist Me’ button to get to the Network

Setup Assistant, then follow the prompts to establish a

connection.

1. Connect the adapter’s USB Type-C connector to

the USB-C port on your laptop, tablet or other

compatible device.

2. Connect the adapter’s VGA port to the monitor’s

VGA port using a VGA cable (such as Tripp Lite’s

P502-Series VGA cables).

3. Charge your device by connecting its USB-C charger

to the adapter’s USB-C port.*

4. Connect a USB device to the adapter’s USB-A hub

port.*

5. Connect the adapter’s RJ45 port to a network using

a UTP cable (such as Tripp Lite’s N201-Series Cat6

cables).**

*USB-C port for U444-06N-VU-C and U444-06N-VUB-C

models support both data transfer and charging.

**See the USB Type-C Features chart for the features your

product supports.

17-12-057-9336FA.indb 4 12/12/2017 12:49:40 PM

Models

U444-06N-V-C /

U444-06N-VB-C

U444-06N-VU-C /

U444-06N-VUB-C

U444-06N-VGU-C /

U444-06N-VGUB-C

Input Connectors

USB USB-C

(Male)

USB-C

(Male)

USB-C

(Male)

USB-C Port Charging

Support Y Y Y

USB-C Port Data Support N Y N

Output Connectors

VGA VGA

(Female)

VGA

(Female)

VGA

(Female)

USB N/A USB-A

(Female)

USB-A

(Female)

Ethernet N/A N/A RJ45

(Female)

Environmental

Operating Temperature 32°F to 113°F (0°C to 45°C)

Operating Humidity

10% to 85% RH, Non-Condensing

Storage Temperature 14°F to 158°F (-10°C to 70°C)

Storage Humidity 5% to 90% RH, Non-Condensing

Power Requirements

USB-C Charging Port

Supports up to 20V 3A (60W) Input

USB 3.0 Port N/A Provides up to 5V 1A

(5W) Output

Specifications

17-12-057-9336FA.indb 5 12/12/2017 12:49:40 PM

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials

and workmanship for a period of three (3) years from the date of

initial purchase. TRIPP LITE’s obligation under this warranty is limited

to repairing or replacing (at its sole option) any such defective

products. To obtain service under this warranty, you must obtain a

Returned Material Authorization (RMA) number from TRIPP LITE or

an authorized TRIPP LITE service center. Products must be returned

to TRIPP LITE or an authorized TRIPP LITE service center with

transportation charges prepaid and must be accompanied by a brief

description of the problem encountered and proof of date and place

of purchase. This warranty does not apply to equipment, which has

been damaged by accident, negligence or misapplication or has

been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO

WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied

warranties; therefore, the aforesaid limitation(s) or exclusion(s) may

not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE

BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS

PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH

DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as

lost profits or revenue, loss of equipment, loss of use of equipment,

loss of software, loss of data, costs of substitutes, claims by third

parties, or otherwise.

PRODUCT REGISTRATION

Visit www.tripplite.com/warranty today to register your new Tripp Lite

product. You’ll be automatically entered into a drawing for a chance

to win a FREE Tripp Lite product!*

* No purchase necessary. Void where prohibited. Some restrictions

apply. See website for details.

17-12-057-9336FA.indb 6 12/12/2017 12:49:40 PM

Warranty and Product Registration

FCC Notice, Class B

This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.

Note: This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly

approved by Tripp Lite could void the user’s authority to operate this

equipment.

17-12-057-9336FA.indb 7 12/12/2017 12:49:40 PM

1111 W. 35th Street, Chicago, IL 60609 USA

www.tripplite.com/support

WEEE Compliance Information for Tripp Lite Customers and

Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment

(WEEE) Directive and implementing regulations, when

customers buy new electrical and electronic equipment

from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like

basis (this varies depending on the country)

• Send the new equipment back for recycling when this ultimately

becomes waste

Use of this equipment in life support applications where failure of

this equipment can reasonably be expected to cause the failure

of the life support equipment or to significantly affect its safety or

effectiveness is not recommended. Do not use this equipment in

the presence of a flammable anesthetic mixture with air, oxygen or

nitrous oxide.

Tripp Lite has a policy of continuous improvement. Specifications are

subject to change without notice.

Warranty and Product Registration

17-12-057-9336FA.indb 8 12/12/2017 12:49:41 PM

Manual del Propietario

Adaptador de USB 3.1

Gen 1 USB-C™ a VGA

Modelos:

(Carga) U444-06N-V-C, U444-06N-VB-C

(Puertos de Hub USB-A y USB-C) U444-06N-VU-C,

U444-06N-VUB-C

(Gigabit Ethernet+Puerto de Hub USB-A+Carga)

U444-06N-VGU-C, U444-06N-VGUB-C

USB Type-C y USB-C son marcas comerciales registradas del USB

Implementers Forum

1111 W. 35th Street, Chicago, IL 60609 EE UU

www.tripplite.com/support

English 1 • Français 16 • Русский 23

17-12-057-9336FA.indb 9 12/12/2017 12:49:41 PM

El paquete incluye

Características del Producto

• U444-06N-V-C, U444-06N-VB-C, U444-06N-VU-C,

U444-06N-VUB-C, U444-06N-VGU-C o

U444-06N-VGUB-C

• Manual del Propietario

Nota: Esta sección lista las características para todos los

modelos con USB Type-C referidos en este manual. Para

determinar qué funciones soporta su modelo, consulte la tabla

Características de USB Type-C.

• Soporta USB DisplayPort de Modo Alterno para

conectar un monitor VGA mediante un puerto

USB-C

• Soporta resoluciones de video VGA hasta

1920 x 1080, incluyendo 1080p (60 Hz)

• El puerto Ethernet soporta velocidades de red de

10/100/1000 Mbps

Accesorios Opcionales

• Cables VGA de Alta Resolución de la Serie P502

• Cables para Dispositivo USB 3.0 A/B de la Serie

U322

• Cables para Dispositivo USB 3.0 Micro-B de la

Serie U326

• Cables Patch Gigabit Snagless Cat6 Serie N201

• Cable USB 3.1 Gen 1 USB-C Macho/Macho

U420-003 – 91 cm [3 pies]

17-12-057-9336FA.indb 10 12/12/2017 12:49:41 PM

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Tripp Lite Adattatore

Tripp Lite

Tripp Lite U238-000-1 Manuale utente

Tripp Lite

Tripp Lite U444-06N-VU-C Manuale utente

Tripp Lite

Tripp Lite U236-000-R Manuale utente

Tripp Lite

Tripp Lite USB 2.0 to SATA/IDE Combo Adapter U238-000... Manuale utente

Tripp Lite

Tripp Lite U444-06N-HD-AM Manuale utente

Tripp Lite

Tripp Lite P116-006-HDMI-A Manuale utente

Tripp Lite

Tripp Lite U209-000-R Manuale utente

Tripp Lite

Tripp Lite U442-DOCK5D-GY Manuale utente

Tripp Lite

Tripp Lite U444-06N-MDP-AL Manuale utente

Tripp Lite

Tripp Lite U444-06N-H3U-C Manuale utente

Tripp Lite

Tripp Lite U260-000-R Manuale utente

Tripp Lite

Tripp Lite U444-06N-VGA-RA Manuale utente

Tripp Lite

Tripp Lite U444-06N-2H-MST Manuale utente

Tripp Lite

Tripp Lite S236-000 Manuale utente

Tripp Lite

Tripp Lite U444-06N-H4-C Manuale utente

Tripp Lite

Tripp Lite 8TLB032VU1 Manuale utente

Tripp Lite

Tripp Lite U344-001-HDMI-R Manuale utente

Tripp Lite

Tripp Lite N254-024-6A Manuale utente

Tripp Lite

Tripp Lite U336-1G-SFP Manuale utente

Tripp Lite

Tripp Lite High-Speed USB Serial Adapter USA-19HS Manuale utente

Tripp Lite

Tripp Lite P116-000-HDSC2 Manuale utente

Tripp Lite

Tripp Lite USA-19HS Manuale utente

Tripp Lite

Tripp Lite U436-06N-GBW-RA Manuale utente

Tripp Lite

Tripp Lite U244-001-R Manuale utente

Manuali Adattatore popolari di altre marche

PCB Piezotronics

PCB Piezotronics 090B274 Manuale utente

Auvidea

Auvidea J20 Manuale del prodotto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manuale utente

Akribis

Akribis ITF-21-BISS-MIT Manuale utente

Tenda

Tenda W54U Manuale utente

ROHO

ROHO AGILITY Manuale utente

PROLiNK

PROLiNK WN2001 Manuale utente

Hawking

Hawking HUF2 Manuale utente

Airlink101

Airlink101 AWLC4030 Manuale utente

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manuale utente

Philips

Philips SWA4554S/10 Manuale utente

JVC

JVC TS-C9D2B Manuale di istruzioni

NETGEAR

NETGEAR A6100 Manuale utente

D-Link

D-Link DWA-121 Manuale utente

Philips

Philips SWA2037 Manuale utente

Basalte

Basalte 0610-20 Manuale utente

Yealink

Yealink EHS40 Manuale utente

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manuale utente
