Tripp Lite P504-010 Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: P504-010

10-ft. SVGA/VGA Monitor + Audio Cable with Coax (HD15 M/M, 3.5mm M/M)

Highlights

Superior molded cables with foil-shielding for maximum EMI/RFI protection

CMR PVC rated

3.5mm Stereo Plugs

Description

Tripp Lite's 10 foot PVC SVGA/VGA monitor replacement cable features built-in 3.5mm stereo plugs, for extending audio as well video. The

mini-coax (RGB) and paired video wire construction delivers superior video signal quality. Nickel plated connectors and gold plated copper contacts

ensure excellent conductivity. Double shielding (foil and braid) provides maximum EMI/RFI protection. Both high density DB15 male connectors are

molded and have integral strain relief to ensure they last a long time.

Package Includes

10-ft. SVGA/VGA Monitor Cable HD15M to HD15M w/Built-in Audio connectors

Features

Extend both Video and Audio signals

Superior molded cables with foil-shielding for maximum EMI/RFI protection

Constructed from mini-coax (RGB) and paired video wire construction for superior signal quality.

HD15 male to HD15 male molded connectors

Computer side Audio Pigtail: 8in Display side Audio Pigtail: 24in

Specifications

OVERVIEW

Intended Application Connecting Peripherals

Display Style Direct Connect

INPUT

Cable Length (ft.) 10

Cable Length (m) 3.05

PHYSICAL

Color Black

Style Monitor Cables

CONNECTIONS

Connector A

HD15 (MALE)

Connector B

3.5MM (MALE)

Number of Connectors 4

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Video Cables & Adapters P500-025 25-ft. SVGA/VGA Monitor Extension Gold Cable with RGB coax, (HD15

M/F)

Video Cables & Adapters P500-050 50-ft. SVGA/VGA Monitor Extension Gold Cable with RGB coax, (HD15

M/F)

Video Cables & Adapters P500-100 100-ft. SVGA/VGA Monitor Extension Gold Cable with RGB coax,

(HD15 M/F)

Video Cables & Adapters P502-006 6-ft. SVGA/VGA Monitor Cable with RGB Coax

(HD15 M/M)

Video Cables & Adapters P502-050 50-ft. SVGA/VGA Monitor Gold Cable with RGB Coax

(HD15 M/M)

Video Cables & Adapters P504-025 25-ft. SVGA/VGA Monitor + Audio Cable with Coax

(HD15 M/M, 3.5mm M/M)

Video Cables & Adapters P504-025-P 25-ft. SVGA/VGA Monitor + Audio Plenum Cable with Coax, (HD15

M/M, 3.5mm M/M)

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3491.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
