Owner’s Manual

VGA Over Cat5 Extenders

and Extender/Splitters

Extender Kit Models: B130-101-2, B130-101A-2,

B130-101-WP-1, B130-101A-WP-1, B130-101S-2,

B130-111, B130-111A and B130-101-U

Transmitter Unit Models: B132-002-2,

B132-002A-2, B132-004-2 and B132-004A-2

Receiver Unit and Remote Repeater Models:

B132-100-1, B132-100A, B132-100-WP-1,

B132-100A-WP-1, B132-110 and B132-110A

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

All trademarks are the sole property of their respective owners.

WARRANTY

REGISTRATION:

chance to win a FREE Tripp Lite

product—www.tripplite.com/warranty

13-04-119-93-3289.indd 1 4/26/2013 2:00:21 PM

Table of Contents

Package Contents 3

Product Features 4

All 4

B130-101-2 4

B130-101A-2 4

B130-101-WP-1 4

B130-101A-WP-1 5

B130-101S-2 5

B130-111 5

B130-111A 6

B130-101-U 6

B132-002-2 7

B132-002A-2 7

B132-004-2 7

B132-004A-2 8

B132-100-1 8

B132-100A 8

B132-100-WP-1 8

B132-100A-WP-1 8

B132-110 9

B132-110A 9

Optional Accessories 10

Mounting Hardware 11

Instructions

Installation 12

EDID Copy 12

Extender Kit Installation 14

Non-Kit Standard Installation 17

Non-Kit Daisy Chain Installation 19

Extender/Repeater Kit 21

Installation

Non-Kit Remote Repeater 24

Installation

Non-Kit Daisy Chain Remote 27

Repeater Installation

Troubleshooting 31

Warranty and Warranty 34

Registration

Additional Warnings and 35

Notices

13-04-119-93-3289.indd 2 4/26/2013 2:00:21 PM

Package Contents

B130-101-2

B130-101A-2

B130-101-WP-1

B130-101A-WP-1

B130-101S-2

B130-111

B130-111A

B130-101-U

B132-002-2

B132-002A-2

B132-004-2

B132-004A-2

B132-100-1

B132-100A

B132-100-WP-1

B132-100A-WP-1

B132-110

B132-110A

Local Unit (L), Remote

Unit (R) or Both (B) B B B B B B B B L L L L R R R R R R

1 or 2 External Power

Supplies (Input: 100-

240 V, 50/60 Hz, 0.5 A

Output: 5 V, 2 A)

22222220 1111111111

Mounting Hardware X X X X X X X X X X X X X

Wallplate Screws X X X X

Screwdriver X X X X X X X X X X X X X X

3.5 mm Male to DB9 Male

Adapter Cable X

3.5 mm Male to DB9

Female Adapter Cable X

1 ft. VGA Splitter Cable X

1 ft. VGA + Audio Splitter

Cable X

1 ft. VGA Daisy Chain

Cable X

1 ft. VGA + Audio Daisy

Chain Cable X

13-04-119-93-3289.indd 3 4/26/2013 2:00:21 PM

Product Features

All

•Support a maximum resolution of 1920 x 1440 @ 60 Hz.

•All operating systems supported.

•Plugandplay;nosoftwareordriversrequired.

•HDCPcompliant.

B130-101-2

•ExtendsaVGAvideosignal(1024x768@60Hz)upto1,000ft.from

the source.

•FeaturesanadditionalVGAport,allowingfortheconnectionofalocal

monitor.

•Includesmountinghardwarethatallowsunitstobewall-mounted,rack

mounted or pole mounted.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B130-101A-2

•ExtendsbothaVGAvideo(1024x768@60Hz)andanaudiosignal

up to 1,000 ft. from the source.

•FeaturesadditionalVGAand3.5mmports,allowingfortheconnection

of a local monitor and speakers.

•Includesmountinghardwarethatallowsunitstobewall-mounted,rack

mounted or pole mounted.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B130-101-WP-1

•ExtendsaVGAvideosignal(1024x768@60Hz)upto1,000ft.from

the source.

•IncludesaVGAsplittercable,whichallowsfortheconnectionofalocal

monitor.

•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatch

cables;no110punchdownconnectionsrequired.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

13-04-119-93-3289.indd 4 4/26/2013 2:00:22 PM

B130-101A-WP-1

•ExtendsbothaVGAvideo(1024x768@60Hz)andanaudiosignal

up to 1,000 ft. from the source.

•IncludesaVGA+audiosplittercable,whichallowsfortheconnection

of a local monitor and speakers.

•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatch

cables;no110punchdownconnectionsrequired.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

B130-101S-2

•ExtendsbothaVGAvideo(1024x768@60Hz)andRS-232Serial

signal up to 1,000 ft. from the source.

•Includesmountinghardwarethatallowsunitstobewall-mounted,rack

mounted or pole mounted.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B130-111

•Kitcomeswithbothlocaltransmitterandremoterepeaterunits.

•Locatemultiplemonitorsatdifferentpointsinachainofupto2,000ft.

by connecting an additional remote receiver unit (B132-100-1 or

B132-100-WP-1), or a remote repeater unit (B132-110).

•Upto4remoteunits(3remoterepeatersand1receiver)canbe

connected together, providing video to up to 4 remote displays in a full chain.

•Extenda1024x768(60Hz)signalupto1,000ft.betweenthelocal

transmitter and the ﬁrst remote repeater unit in the installation.

•Extenda1024x768(60Hz)signaluptoanadditional1,000ft.from

the ﬁrst remote repeater unit to the last display in the installation, for a

maximum extension distance of 2,000 ft.

•LocalunitincludesanadditionalVGAport,allowingfortheconnection

of a local monitor.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•Includesmountinghardwarethatallowsunitstobewall-mounted,

rack mounted or pole mounted.

Product Features continued

13-04-119-93-3289.indd 5 4/26/2013 2:00:22 PM

Product Features continued

B130-111A

•Kitcomeswithbothlocaltransmitterandremoterepeaterunits.

•Locatemultiplemonitors/speakersatdifferentpointsinachainofupto

2,000 ft. by connecting an additional remote receiver unit (B132-100A

or B132-100A-WP-1), or a remote repeater unit (B132-110A).

•Upto4remoteunits(3remoterepeatersand1receiver)canbe

connected together, providing audio/video to up to 4 remote displays/

speakers in a full chain.

•Extenda1024x768(60Hz)videoandaudiosignalupto1,000ft.

between the local transmitter and the ﬁrst remote repeater unit in the

installation.

•Extenda1024x768(60Hz)videoandaudiosignaluptoanadditional

1,000 ft. from the ﬁrst remote repeater unit to the last set of display

and speakers in the installation, for a maximum extension distance of

2,000 ft.

•LocalunitincludesadditionalVGAvideoand3.5mmaudioports,

allowing for the connection of a local monitor and speakers.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•Includesmountinghardwarethatallowsunitstobewall-mounted,

rack mounted or pole mounted.

B130-101-U

•ExtendsaVGAvideosignal(1024x768@60Hz)upto500ft.from

the source.

•PowerissuppliedbytheUSBconnectiononthelocaltransmitterunit;

noexternalpowersuppliesarerequired.

•Dongle-stylelocalandremoteunitscomewithbuilt-inVGAconnectors;

noexternalVGAcablesarerequired.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

13-04-119-93-3289.indd 6 4/26/2013 2:00:22 PM

Product Features continued

B132-002-2

•WorkswiththeB132-100-1andB132-100-WP-1remoteunitstoextenda

VGA video signal (1024 x 768 @ 60 Hz) up to 1,000 ft. from the source.

•AbletotransmitasingleVGAvideosignalto2monitors.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B132-002A-2

•WorkswiththeB132-100AandB132-100A-WP-1remoteunitsto

extend both a VGA video (1024 x 768 @ 60 Hz) and an audio signal up

to 1,000 ft. from the source.

•TransmitsasingleVGAvideoandaudiosignalto2setsofmonitorsand

speakers.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B132-004-2

•FeaturesanadditionalVGAport,allowingfortheconnectionofalocal

monitor.

•WorkswiththeB132-100-1andB132-100-WP-1remoteunitstoextenda

VGA video signal (1024 x 768 @ 60 Hz) up to 1,000 ft. from the source.

•Abletotransmitupto5(4remote,1local)VGAvideosignals.

•Expandthenumberofconnectedmonitorstoupto25(24remote,

1 local) by daisy chaining up to 6 local units together.

Note: B132-002-2 local units cannot be daisy chained.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

•UptothreelocalunitscanbeconnectedtoaTrippLiteB132-004-RB

rackmountbracketandmountedinjust1Uofrackspace.

13-04-119-93-3289.indd 7 4/26/2013 2:00:22 PM

Product Features continued

B132-004A-2

•WorkswiththeB132-100AandB132-100A-WP-1remoteunitsto

extend both a VGA video (1024 x 768 @ 60 Hz) and an audio signal up

to 1,000 ft. from the source.

•FeaturesadditionalVGAand3.5mmports,allowingfortheconnection

of a local monitor and speakers.

•TransmitsasingleVGAvideoandaudiosignaltoupto5sets

(4 remote, 1 local) of monitors and speakers.

•Expandthenumberofconnectedmonitors/speakerstoupto25

(24 remote, 1 local) by daisy chaining up to 6 local units together.

Note: B132-002A-2 local units cannot be daisy chained.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•UptothreelocalunitscanbeconnectedtoaTrippLiteB132-004-RB

rackmountbracketandmountedinjust1Uofrackspace.

•EDIDcopyfeatureensuresoptimaldisplaycompatibility.

B132-100-1

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

B132-100A

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

B132-100-WP-1

•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatch

cables;no110punchdownconnectionsrequired.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

B132-100A-WP-1

•IncludesRJ45jacks,allowingforeasyconnectionviastandardpatch

cables;no110punchdownconnectionsrequired.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

13-04-119-93-3289.indd 8 4/26/2013 2:00:22 PM

Product Features continued

B132-110

•BothextendsandexpandsyourTrippLiteVGAoverCat5installation,

allowing you to locate multiple monitors at different points in a chain of

up to 2,000 ft.

•Upto4remoteunits(3remoterepeatersand1receiver)canbeconnected

together, providing video to up to 4 remote displays in a full chain.

•Extenda1024x768(60Hz)signalupto1,000ft.betweenthelocal

transmitter and the ﬁrst remote repeater unit in the installation.

•Extenda1024x768(60Hz)signaluptoanadditional1,000ft.from

the ﬁrst remote repeater unit to the last display in the installation, for a

maximum extension distance of 2,000 ft.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

B132-110A

•BothextendsandexpandsyourTrippLiteVGA+audiooverCat5

installation, allowing you to locate multiple monitors/speakers at

different points in a chain of up to 2,000 ft.

•Upto4remoteunits(3remoterepeatersand1receiver)canbe

connected together, providing audio/video to up to 4 remote displays/

speakers in a full chain.

•Extenda1024x768(60Hz)videoandaudiosignalupto1,000ft.

between the local transmitter and the ﬁrst remote repeater unit in the

installation.

•Extenda1024x768(60Hz)videoandaudiosignaluptoanadditional

1,000 ft. from the ﬁrst remote repeater unit to the last set of display

and speakers in the installation, for a maximum extension distance of

2,000 ft.

•Featuresbuilt-inequalizationandgaincontrolstoadjustthevideoimage.

•Includesmountinghardwarethatallowsunittobewall-mounted,rack

mounted or pole mounted.

13-04-119-93-3289.indd 9 4/26/2013 2:00:22 PM

Optional Accessories

• B132-004-RB1URackmountBracket

• N001-SeriesCat5eSnaglessPatchCables

• N002-SeriesCat5ePatchCables

• N020-01K-GYGrayCat5eBulkStrandedCable–1,000ft.

• N022-01K-GYGrayCat5eBulk24AWGSolidCable–1,000ft.

• N030-01010-packofRJ45PlugsforSolid-wireCat5eCable

• N031-05050-packofRJ45PlugsforStranded-wireCat5eCable

• N201-SeriesCat6SnaglessPatchCables

• N202-SeriesCat6Snagless24AWGSolidPatchCables

• N222-01K-GYGrayCat6Bulk24AWGSolidCable–1,000ft.

• P312-SeriesAudioCables

• P502-SeriesVGAMonitorCableswithRGBCoax

• P504-SeriesVGAMonitor+AudioCableswithRGBCoax

• P520-006RS-232SerialExtensionCable–6ft.

• P524-01KZero-SkewUTPBulkCable–1,000ft.

13-04-119-93-3289.indd 10 4/26/2013 2:00:22 PM

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Tripp Lite Estensione

Tripp Lite

Tripp Lite B123-001-60 Manuale utente

Tripp Lite

Tripp Lite B130-202 Manuale utente

Tripp Lite

Tripp Lite B203-101-POC Manuale utente

Tripp Lite

Tripp Lite B127-1A1-CH Manuale utente

Tripp Lite

Tripp Lite B127E-1A1-HH Manuale utente

Tripp Lite

Tripp Lite B127F-1A1-MM-HH Manuale utente

Tripp Lite

Tripp Lite 0DT23001 Manuale utente

Tripp Lite

Tripp Lite B162-001-POE Manuale utente

Tripp Lite

Tripp Lite B126-1D10-WHD1 Manuale utente

Tripp Lite

Tripp Lite B132-100 Manuale utente

Tripp Lite

Tripp Lite Wireless Console Extender B014-000 Manuale utente

Tripp Lite

Tripp Lite B126-1A1-POC Manuale utente

Tripp Lite

Tripp Lite B125-101-60-IR Manuale utente

Tripp Lite

Tripp Lite B125-150 Manuale utente

Tripp Lite

Tripp Lite B120-000-SL Manuale utente

Tripp Lite

Tripp Lite HDMI B122-000-60 Manuale utente

Tripp Lite

Tripp Lite P167-000 Manuale utente

Tripp Lite

Tripp Lite B140-101X-U Manuale utente

Tripp Lite

Tripp Lite B127M-101-H Manuale utente

Tripp Lite

Tripp Lite B120-000-SL Manuale utente

Tripp Lite

Tripp Lite B203-101-IND Manuale utente

Tripp Lite

Tripp Lite B130-101A Manuale utente

Tripp Lite

Tripp Lite B126-1P0-WP-1 Manuale utente

Tripp Lite

Tripp Lite B203-101 Manuale utente

Manuali Estensione popolari di altre marche

SY HDBT-60T Manuale utente

Appsys ProAudio

Appsys ProAudio ADX-16 Manuale utente

Atlona

Atlona RS232 Manuale utente

IDK

IDK OPF-TH1000-A Manuale utente

Enable-IT

Enable-IT 824WP Manuale utente

Worx

Worx Landroid RadioLink WA0864 Scheda tecnica

TP-Link

TP-Link TL-WA730RE Manuale utente

Camplex

Camplex CMX-HDMI-SFPL Manuale utente

SC&T

SC&T HE03-4K Manuale utente

Marmitek

Marmitek MegaView70 Manuale utente

Samsung

Samsung SCS-26UC4 Manuale utente

Foxun

Foxun SX-GES24 Manuale utente

MuxLab

MuxLab 500771 Manuale utente

foxunhd

foxunhd SX-AEX01 Manuale utente

TERK Technologies

TERK Technologies LFIRX2 Manuale utente

Devolo

Devolo Audio Extender Manuale

Edimax

Edimax EW-7438RPn V2 Manuale utente

Shinybow USA

Shinybow USA SB-6335T5 Manuale utente
