Tripp Lite PDUMV15NET Manuale utente

LOAD(AMPS)

MODEL:

PDUMV15NET

Switched Rackmount PDU

Low Voltage

Input/Output

16 Outlets 15A Max Capacity Load Meter Network

Interface

0U Rackmount Toolless

Mounting

Buttons

100-125V

50/60Hz 5-15/20R 15A 0U

Specications

Model PDUMV15NET

Voltage 100-125V

Frequency 50/60 Hz

Maximum Capacity 15A

Agency-Derated Capacity 12A

Input Connector 5-15P

Cord Length 10 ft.

Outlets 16 (5-15/20R)

Primary Mounting Option 0U (Vertical) Rackmount

Unit Weight & Dimensions 7 lb / 4.25 x 49 x 2.25 in.

See next page for detailed unit measurements.

Certications Tested to UL 60950-1 (US & Canada), NOM (Mexico),

FCC Class A

Tripp Lite has a policy of continuous improvement. Specications are subject to change without notice.

• Distributes power to 16 outlets

• Remote monitoring and control via SNMP, Web or Telnet

• Displays total load in real time

• Perfect for rackmount server, network and telecom

applications

SEE NEXT PAGE FOR DETAILED UNIT MEASUREMENTS

A Digital Load Meter

B 5-15/20R Outlets

with On/O LEDs

CDurable Metal Case

D Removable Cord

Retention Brackets

E Removable Mounting

Brackets

F Toolless Mounting

Buttons

G 10 ft. Input Power Cord

H 5-15P Input Plug

I Network Interface

J RJ45 Ethernet Jack

K Manual Conguration Port

Environmental

Monitoring Port

Network Interface

Reset Button

AC Input Connection: Insert 5-15P plug

into compatible 5-15R or 5-15/20R

utility, generator or UPS outlet.

1111 W. 35th Street

Chicago, IL 60609 USA

773.869.1234

www.tripplite.com

Also Includes: Cable Ties,

Owner’s Manual

Network Interface: Connect to Ethernet

for remote monitoring and individual

outlet control via SNMP, Web or Telnet.

Add optional ENVIROSENSE accessory for

temperature/humidity monitoring and

dry contact interface.

REAR VIEW

FRONT VIEW SIDE VIEW

5-15P

5-15R OUTLETS

101.05

3.98

1243.22

48.94

10.75

273

16.08

408.56

2.185

55.5

SEE

DETAIL C

120

3048

1.60

40.75

REMOVABLE MOUNTING

BRACKET

82.10

3.23

1.25

31.75 768.30

30.25

9.53

242.07

1.73

1.86

47.36

107.05

4.22

CORD RETENTION

BRACKET

REMOVABLE

TOOLLESS

MOUNTING

BUTTON

761.95

157.72

6.21

36.73

933

9.34

237.24

REMOVABLE

MOUNTING

BRACKET

TOOLLESS

MOUNTING

BUTTON

DETAIL E

TOOLLESS

MOUNTING

BUTTON

DETAIL C

CORD RETENTION

BRACKET

REMOVABLE

MOUNTING BRACKET

DETAIL A

3.40

86.43

DETAIL B

.56

14.17

DETAIL D

.28

7.10

Dimensions: [mm] INCHES

Tripp Lite has a policy of continuous improvement. Specications are subject to change without notice.

MODEL:

PDUMV15NET

1111 W. 35th Street

Chicago, IL 60609 USA

773.869.1234

www.tripplite.com
