Tripp Lite SmartOnline SU8000RT3UPM Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: SU8000RT3UPM

SmartOnline 8000VA Power Module - Hot-swappable power module for redundant power applications

Highlights

8000VA on-line 3U rack/tower hot-swappable power module

Ideal for use as a spare or redundant power module for mission-critical UPS

configurations involving SU8000RT3UPM

Description

8,000 VA (8kVA) on-line, double-conversion UPS power module for spare or redundant UPS configurations involving SU8000RT3U,

SU8000RT3U1TF, SU7500RT3U or SU7500RT3U1TF UPS bundles. POWER MODULE ONLY.

Package Includes

SU8000RT3UPM POWER MODULE ONLY (3u)

Features

8,000VA (8kVA) on-line, double-conversion UPS power module for spare or redundant UPS configurations involving SU8000RT3U,

SU8000RT3U1TF, SU7500RT3U or SU7500RT3U1TF UPS bundles.

POWER MODULE ONLY

Specifications

OVERVIEW

Model Type Power Modules

OUTPUT

Output Volt Amp

Capacity (VA)

8000

Output kVA capacity

(kVA)

Output Watt Capacity

(watts)

7200

Output kW capacity 7.2

Output power factor 0.9

Crest Factor 3:1

Nominal Output

Voltage(s) Supported

200V; 208V; 220V; 230V; 240V

Frequency compatibility 50 / 60 Hz

Output AC waveform

(AC mode)

Sine wave

Output AC waveform

(battery mode)

Pure Sine wave

INPUT

Nominal Input

Voltage(s) Supported

200V AC; 208V AC; 220V AC; 230V AC; 240V AC

LEDS ALARMS & SWITCHES

Front panel LCD display Selectable LCD display with scroll and selection buttons enables UPS control and detailed monitoring options;

LED/LCD panel rotates for viewing in rack/tower formats (see manual)

Alarms Unique audible alarms for all major UPS, environmental and power conditions (see manual)

Alarm cancel operation Alarm cancel switch

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; 2 additional switches support set and

execute scrolling LCD functions

PHYSICAL

Installation form factors

supported with included

accessories

4 post 19 inch rackmount (mounting rail kit included)

Primary form factor Rackmount

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / inches)

5.14 x 17.5 x 25.82

UPS / Power Module

dimensions in primary

form factor (height x

width x depth / cm)

13.1 x 44.4 x 65.6

UPS / Power Module

weight (lbs)

UPS / Power Module

weight (kg)

19.5

UPS dimensions details 3U power module component only

UPS Shipping

dimensions (height x

width x depth / inches)

9.7 x 23.6 x 39.4

UPS Shipping

dimensions (height x

width x depth / cm)

24.6 x 59.9 x 100.1

Shipping weight (lbs) 66

Shipping weight (kg) 30

UPS housing material Steel

COMMUNICATIONS

Communications

interface

USB (HID enabled); DB9 Serial; EPO (emergency power off); Slot for SNMP/Web interface

CERTIFICATIONS

UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to CE (EU); Meets FCC

Part 15 Category A (EMI)

WARRANTY

Product Warranty

Period (Worldwide)

2-year limited warranty

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3553.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
