Tripp Lite TLM626TEL15 Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: TLM626TEL15

Protect It! Surge Suppressor

Highlights

6 right-angle outlets / 15 ft. cord

1208 joule rating

Tel/DSL surge protection (1 line)

$75,000 Ultimate Lifetime Insurance (USA & Canada only)

Description

Tripp Lite's TLM626TEL15 surge suppressor offers complete AC and Tel/DSL line surge suppression for comprehensive protection of workstations,

personal computers, home stereos, televisions, VCRs, DVD players and other sensitive electronics. Heavy grade AC surge suppression shields

connected equipment from damage and performance problems due to transient surges. Set of RJ-11 telephone line suppression jacks protect a

single dialup modem, DSL modem, fax or phone line. TLM626TEL15 offers 6 right-angle outlets, a 15 foot power cord and diagnostic LEDs to warn

of wiring problems and suppressor damage. AC surge suppression rated at 1208 joules shields equipment from surges and line noise. Rugged metal

housing with 2 designated transformer plug outlets offers convenient protection of desktop computer equipment and accessories. Lifetime warranty

with $75,000 Ultimate Lifetime Insurance (USA & Canada Only).

PLUG/OUTLETS: Input - 15 ft. AC line cord with NEMA 5-15P plug/Output - 6 NEMA 5-15R right-angle outlets

ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA 5-15R wall receptacle)

FORMAT: Metal strip

SUPPRESSION: AC: 150V RMS Clamping/1208 joules/330V UL1449

Applications

Ideal for personal computers, TV/VCR/DVD, stereos and lamps/lighting

Package Includes

TLM626TEL15 surge suppressor

6 ft. RJ-11 phone cord

Instruction manual and warranty information

Features

6 right-angle outlets

15 ft. cord

Built-in RJ-11 jacks prevent surges from damaging your telephone/DSL/modem/fax equipment; 6 ft. telephone cord included

Surge suppression rating: 1208 joules

EMI/RFI noise filtering

15 amp resettable circuit breaker protects against overload

Diagnostic LEDs confirm suppressor "protection present" (green) and "grounded" (red) status

Convenient keyhole slots allow secure mounting on wall or desk

Can accommodate up to 2 transformers without blocking adjacent outlets

Rugged metal case provides extra safety and durability

Illuminated power switch

$75,000 Ultimate Lifetime Insurance (USA & Canada Only) covers connected equipment

Lifetime product warranty

Specifications

OVERVIEW

Intended Application Home/Office

SYSTEM OVERVIEW

Voltage compatibility 120V AC

Frequency compatibility 50/60 Hz

OUTPUT

Output volt amp capacity

(amps)

Output watts 1800

Outlet quantity / type 6 NEMA 5-15R

Outlet orientation Single row of outlets

Overload protection 15A resettable combo switch / circuit breaker

Transformer accommodation Supports 2 large transformers without covering adjacent outlets

INPUT

Input connection type NEMA 5-15P

Input cord gauge, type 14 gauge, SJT

Input cord length (ft.) 15 ft.

Input cord length (m) 4.5

Recommended Electrical

Service

120V (110-125V)

LEDS ALARMS & SWITCHES

Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status

Switches Combination AC circuit breaker and 2 position on/off power switch

SURGE / NOISE SUPPRESSION

Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

AC suppression joule rating 1208 joules

Clamping voltage (RMS) 150V

AC suppression response

time

< 1 ns

UL1499 let through rating 330V - UL Verified

EMI / RFI filtering Up to 20dB

DATALINE SURGE SUPPRESSION

Telephone/DSL Protection Yes

Telephone/DSL Protection

Details

1 line

Cable (Coax) Protection No

Network (Ethernet) Protection No

PHYSICAL

Shipping weight (lbs) 2.5

Shipping weight (kg) 1.1

Shipping Dimensions

(HWD/in)

2.25 x 15 x 6

Shipping Dimensions

(HWD/cm)

5.7 x 38.1 x 15.2

Unit weight (lbs) 1.8

Unit weight (kg) .8

Unit Dimensions (HWD/in) 1.5 x 12.25 x 2.25

Unit Dimensions (HWD/cm) 3.8 x 31.1 x 5.7

Material of construction Metal

Form factors supported Supports floor / wall / desktop placement

Integrated keyhole mounting

tabs

Keyhole slots enable mounting to a variety of surfaces

Receptacle Color Light Gray

AC line cord color Black

Style Strip

CERTIFICATIONS

Additional International

Approvals

Complies with RoHS (Restriction of Hazardous Substances Directive)

UL1449 1998 Rev. (AC

Suppression)

UL1449

UL1363 (Power Tap) UL1363

FCC Part 68

(Communications)

FCC Part 68

cUL / CSA (Canada) cUL

Approvals Exceeds IEEE 587 category A&B specifications

WARRANTY

Product Warranty Period Lifetime

Connected Equipment

Coverage

$75,000

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3295.
