Tripp Lite TLP808 Manuale utente
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: TLP808
Protect It! Surge Suppressor
Highlights
8 outlets / 8-ft. cord
1900 joule rating
$75,000 Ultimate Lifetime Insurance (USA, Puerto Rico & Canada only)
Description
Tripp Lite's TLP808 offers complete AC surge suppression for comprehensive system protection of workstations, desktop PCs, telecom systems and
other sensitive electronics. Heavy grade AC surge suppression shields connected equipment from damage and performance problems due to the
heaviest transient surges. TLP808 offers 8 total outlets, 8 foot cord with space-saving angled plug and diagnostic LEDs to warn of wiring problems
and suppressor damage. Network grade AC suppression rated at 1900 joules shields equipment from surges and line noise. Integrated child-safety
outlet covers safely seal off unused outlets. Attractive white suppressor housing with keyhole mounting tabs and 3 designated transformer plug
outlets offers convenient protection of desktop computer equipment and accessories. Lifetime warranty with $75,000 connected equipment
insurance (USA & Canada Only).
PLUG/OUTLETS: Input: NEMA5-15P/Output: 8 NEMA5-15R/8 ft. AC line cord
ELECTRICAL: 120V AC, 50/60Hz, 15A (Requires NEMA5-15R wall receptacle)
FORMAT: Corded multi-outlet strip with transformer spaced outlets
SUPPRESSION AC: 150V RMS Clamping/1900 joules
Applications
Ideal for any desktop, network or home computing application requiring AC protection.
Package Includes
TLP808 Surge Suppressor
Instruction manual with warranty information
Features
1900 joules AC surge suppression shields equipment from the strongest surges and line noise
8 AC outlets with room for 3 transformer plugs without blocking outlets covers computers and all peripherals
Long 8 foot AC line cable with space-saving angle input plug conveniently reaches distant outlets
Lighted power switch with integrated 15 amp circuit breaker offers power control and overload protection
Integrated child-safety sliding outlet covers safely seal off all unused outlets
Diagnostic LEDs confirm outlet grounding and surge suppression status
Attractive white suppressor housing with keyhole mounting tabs allow versatile placement options
Lifetime warranty with $75,000 Ultimate Lifetime Insurance (USA & Canada Only)
Specifications
OVERVIEW
Intended Application Home/Office
SYSTEM OVERVIEW
Voltage compatibility 120 VAC
Frequency compatibility 50/60 Hz
OUTPUT
Output volt amp capacity
(amps)
15
Output watts 1800
Outlet quantity / type 8 NEMA 5-15R
Outlet orientation Single row of 5, plus a second row of 3 for transformer accommodation
Outlet safety covers Includes built-in sliding outlet safety covers
Transformer accommodation Supports 3 large transformer plug accessories without covering remaining outlets, accepts up to 6 transformers
total
INPUT
Input connection type NEMA 5-15P
Input cord gauge, type 14 gauge, SJT
Input cord length (ft.) 8 ft.
Input cord length (m) 2.4
Recommended Electrical
Service
120V (110-125V)
Input plug features Space-saving right angle input plug
LEDS ALARMS & SWITCHES
Diagnostic LEDs Built-in LEDs confirm suppressor "protection present" (green) and "grounded" (red) status
Switches Combination AC circuit breaker and 2 position red illuminated on/off power switch
SURGE / NOISE SUPPRESSION
Protection modes Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression
AC suppression joule rating 1900 joules
Clamping voltage (RMS) 150V
AC suppression response
time
< 1 ns
UL1499 let through rating 330V - UL Verified
EMI / RFI filtering Up to 40 dB
DATALINE SURGE SUPPRESSION
Telephone/DSL Protection No
Cable (Coax) Protection No
Network (Ethernet)
Protection
No
PHYSICAL
Shipping weight (lbs) 1.6
Shipping weight (kg) 0.7
Shipping Dimensions
(HWD/in)
2 x 7.5 x 12.75
Shipping Dimensions
(HWD/cm)
5.1 x 19.1 x 32.4
Unit weight (lbs) 1.8
Unit weight (kg) 0.8
Unit Dimensions (HWD/in) 1.5 x 4.25 x 9.1
Unit Dimensions (HWD/cm) 3.8 x 10.8 x 23.1
Material of construction Plastic
Integrated keyhole mounting
tabs
Keyhole mounting tabs enable wall mounting
AC line cord color Gray
Style Strip
CERTIFICATIONS
UL1449 1998 Rev. (AC
Suppression)
UL1449
UL1363 (Power Tap) UL1363
cUL / CSA (Canada) cUL
Approvals Exceeds IEEE 587 category A&B specifications
WARRANTY
Product Warranty Period Lifetime
Connected Equipment
Coverage
$75,000
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=138.
©2009 Tripp Lite. All Rights Reserved.
