Tripp Lite Internet Office INTERNET750U Manuale utente
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: INTERNET750U
Internet Office 750VA Ultra-compact Standby 120V UPS with USB port
Highlights
750VA ultra-compact 120V standby UPS
Maintains AC output during power failures
6 UPS battery supported outlets, 6 surge-only outlets
USB port, TEL/DSL protection, Wall mountable, 99% efficient
NEMA 5-15P input plug and 12 NEMA 5-15R outlets
Description
Tripp Lite's INTERNET750U standby UPS offers complete protection for PCs, workstations and other sensitive electronics in an attractive,
ultra-compact, mountable housing. Prevents data loss and system downtime by providing battery-supported AC output during brownouts and
blackouts. 12 widely spaced output receptacles accommodate large transformer plugs without blocking outlets. 6 outlets provide full battery support
and surge suppression for computers, monitors and other vital system components. 6 additional surge suppression-only outlets are ideal for printers
and other accessories not requiring battery support. Single-line telephone suppression jacks protect directly connected modems, fax machines,
cordless phones or other peripherals sharing a standard dialup or DSL phone line connection. USB port with PowerAlert monitoring software and
cabling enables a safe, unattended system shutdown. HID-compliant USB interface enables integration with built-in power management and
auto-shutdown features of Windows and Mac OS X. Audible alarm and front panel LEDs offer status information regarding line and battery power
operation. 750VA/450W power handling ability supports entry-level PCs for up to 45 min. during power failures. $100,000 connected equipment
insurance (USA and Canada Only).
Package Includes
INTERNET750U UPS System
USB cable
Instruction manual
Features
INTERNET750U standby UPS offers complete protection from blackouts, brownouts and surges on AC and tel/DSL dataline connections
12 widely spaced outlets accommodate large transformer plugs without blocking outlets
6 battery-supported outlets protect computers and vital system peripherals. 6 surge suppression-only outlets protect system accessories
that do not require battery support
Provides battery-derived AC output during blackouts and brownouts
750VA/450W power handling ability supports a variety of PCs, workstations and other sensitive electronics
Supports entry-level PC systems up to 45 min. during blackouts
Single-line telephone suppression jacks protect directly connected modems, fax machines, cordless phones or other peripherals sharing a
standard dialup or DSL phone line connection
USB communications interface, FREE PowerAlert Software and cabling provide monitoring of site power conditions
Supports Tripp Lite's Watchdog system service to restore operation to locked equipment through soft reboot of application/OS or hard
power off/on reboot of connected equipment; ideal for unattended kiosk applications
power off/on reboot of connected equipment; ideal for unattended kiosk applications
Hot-swap battery replacement supported via battery access door
Space-saving ultra-compact housing
Keyhole mounting flanges enable secure wallmount installation
$100,000 Ultimate Lifetime Insurance protects connected equipment from surge damage (USA, Puerto Rico, & Canada only)
Specifications
OUTPUT
Output Volt Amp Capacity
(VA)
750
Output Watt Capacity (watts) 450
Nominal Output Voltage(s)
Supported
115V; 120V
Frequency compatibility 60 Hz
Output voltage regulation
(Battery mode)
115V (+/- 5%)
Built-in UPS output
receptacles
12 5-15R outlet(s)
Surge suppression only
outlets
6 UPS outlets, 6 surge-only outlets
Output AC waveform (AC
mode)
Sine wave
Output AC waveform
(battery mode)
PWM sine wave
INPUT
Rated input current (at
maximum load)
10A
Nominal Input Voltage(s)
Supported
120V AC
UPS input connection type 5-15P
Input circuit breaker 10A
UPS Input cord length (ft.) 6
UPS Input cord length (m) 1.8
Recommended Electrical
Service
15A 120V
Phase Single-Phase
BATTERY
Full load runtime (minutes) 2.4 min. (450w)
Half load runtime (minutes) 11.4 min. (225w)
DC system voltage (VDC) 12
LEDS ALARMS & SWITCHES
LED Indicators 2 LEDs indicate power status and overload/check battery status
Alarms Audible alarm indicates power-failure and overload status
Switches Combination switch controls on/off power status and self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression joule
rating
420
UPS AC suppression
response time
Instantaneous
UPS Dataline suppression 1 line TEL/DSL (1 in / 1 out)
EMI / RFI AC noise
suppression
Yes
PHYSICAL
Installation form factors
supported with included
accessories
Tower; Ultra-compact desktop; Wallmount (using keyhole mounting tabs)
Included mounting
accessory description
Wallmount installation supported using keyhole mounting tabs
Primary form factor Desktop
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / inches)
3.1 x 12.2 x 6.9
UPS / Power Module
dimensions in primary form
factor (height x width x
depth / cm)
7.8 x 31 x 17.6
UPS / Power Module weight
(lbs)
8.7
UPS / Power Module weight
(kg)
3.9
UPS Shipping dimensions
(height x width x depth /
inches)
4.6 x 15 x 9.8
UPS Shipping dimensions
(height x width x depth / cm)
11.7 x 38.2 x 25
Shipping weight (lbs) 9.6
Shipping weight (kg) 4.4
UPS housing material ABS
ENVIRONMENTAL
Operating Temperature
Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full load) 15.5
Battery mode BTU / hr. (full
load)
291.4
COMMUNICATIONS
Communications interface USB (HID enabled)
PowerAlert software Free download from www.tripplite.com
Communications cable USB interface cable included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time 2-4 milliseconds
Low voltage transfer to
battery power (setpoint)
99
High voltage transfer to
battery power (setpoint)
139
SPECIAL FEATURES
Cold Start (startup in battery
mode during a power failure)
Cold-start operation supported
Green & high efficiency
features
Greater than 95% efficiency - GREEN UPS
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category
B (EMI)
WARRANTY
Product Warranty Period
(U.S. & Canada)
3-year limited warranty
Product Warranty Period
(International)
2-year limited warranty
Product Warranty Period
(Mexico)
3-year limited warranty
Product Warranty Period
(Puerto Rico)
3-year limited warranty
Connected Equipment
Insurance (U.S., Canada &
Puerto Rico)
$100,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Related Model Description Qty.
CT120 Instant-Read- AC Outlet Circuit Tester 1
WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
WEXT5-INTERNET 5-Year Extended Warranty - For Internet Office, AVR and ECO Series UPS Systems 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3142.
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
