Tristar Products PPJJEE VV22 Manuale utente

Tristar Products, Inc.

Wallingford, CT 06494

Distributed By:

We are very proud of the design and quality

of our Power Juicer Express. This product has been manufactured

to the highest standards. Should you have any problem our friendly

customer service staff is here to help you

if you have a question.

We are available at:

-8

-5

-2

9:00AM–7:00PM EST Monday–Friday

9:00AM–5:00PM EST Saturday

OPERATING

MANUAL

TABLEOFCONTENTS

Important Safety Information

Helpful Hints

Parts List

Assembly

Disassembly

Cleaning Your Juicer

Troubleshooting

Replacement

Parts Kit #1

Exciting Offers from

Power Juicer Express

Accessory Kit

& Cookbook

YES! Please Send Me the following Items:

nnOne Accessory Kit & Cookbook for only $19.99

plus $3.99 s&h. Total $23.98.

nn“Recipes for Healthy Living” Cookbook

for only $9.99 plus $1.99 s&h. Total $11.98.

nnReplacement Parts Kit #1 for only $12.99

plus $2.99 s&h. Total $15.98.

nnReplacement Parts Kit #2 for only $9.99

plus $2.99 s&h. Total $12.98.

nnVISA nnMasterCard nnDiscover Exp. Date______

Credit Card #______________________________________

nnCheck nnMoney Order (NJ, PA, CT residents add 6%

sales tax. NV & NY add applicable rate.)

U.S. CURRENCY ONLY

Please make checks payable to: POWER JUICER EXPRESS

Print Name ________________________________________________

Address____________________________________________________

______________________________________________Apt._________

City______________________________________________________

State___________________ Zip_______________________________

Phone# (____________) _____________________________________

E-mail ____________________________________________________

Mail Payment Today To: POWER JUICER EXPRESS

26 Barnes Industrial Rd. North, P.O. Box 3125, Dept. PE999, Wallingford, CT 06494

Call 1-800-526-2984

M–

–7

y–

–F

M–

–5

Please allow 4-6 weeks for shipping.

“Recipes for Healthy Living” Cookbook

Power Juicer Express Platform

Filter Brush

Overflow Platform

Measuring Cup

Pulp

Collector

Pusher

www.powerjuicerexpress.com

Replacement

Parts Kit #1 Filter/Blade

Replacement

Parts Kit #2

Removable

Juicer Spout

The motor does not

run after being

switched on.

The motor is running

with loud noise and

shaking.

The motor overheats

causing the power to

automatically shut off.

Juice splashes from the

rim of the receptacle.

Machine is running, but

no juice is coming out.

• Check to see if unit is plugged in.

• Locking bar is not locked in place properly.

• Check if all parts are assembled properly.

• Check if there is any residue left between blade and receptacle.

• Make sure pulp collector is properly assembled as the safety

MicroSwitch will cause the unit not to operate if pulp collector

is not in place.

• Check filter/blade is secured firmly in place.

• Check that all parts are assembled properly and in the

correct position.

• Juicing overripe fruit may result in too much pulp and will

clog the filter. Turn machine off and clean the filter.

• The motor needs to warm up for 10 seconds before use.

• The fruits and vegetables may be soft or overripe.

• There may be too much pulp in the filter. Turn machine off

and clean the filter.

• Motor stops running due to the built-in feature, the overheat

safety control.

• This is normal.

• Check spout to make sure it is the down position. The juice

will not come out if spout is in the upright position.

TROUBLESHOOTING

Problem PossibleReasonsandSolution

IMPORTANTSAFEGUARDS

READTHESESAFEGUARDSCAREFULLY

BEFOREUSINGTHISPRODUCT!

When using electrical appliances, basic safety precautions should always

be followed including the following:

• NOT FOR USE BY CHILDREN! Keep out of the reach of children to avoid injury.

This appliance is not a toy.

• Consult your physician before giving fresh juice to children, especially infants.

• Be sure to turn to OFF position after each use of your juicer

• Make sure the lid is attached properly and securely locked before operating

the Power Juicer.

• Do not unfasten the locking bar during operation.

• To avoid risk of injury keep hands and utensils out of the juicer and away from its sharp

blade during operation.

• Use the pusher, not fingers or utensils, to propel the food into the juicer.

• Should food become lodged in the opening use pusher to push it down. If food remains

stuck, turn the power off, wait until motor stops, unit shuts down completely, and is

unplugged before disassembling the juicer and removing the blocked food.

• Make sure the motor stops completely and the unit is unplugged from the electrical outlet

before cleaning, putting on or removing parts.

• To protect against risk of electrical shock or injury, never immerse power cord,

plug, or main unit in water, or other liquids.

• If juicer stops due to improper operation or if there is excessive noise, turn power off,

wait for blade to stop spinning, unplug from electrical outlet, disassemble and clean

all components then reassemble machine.

• Do not use outdoors.

• Do not operate this or any appliance with a damaged cord or plug.

• Do not operate if appliance malfunctions, is dropped or damaged in any manner.

Let a qualified appliance repair person examine and or repair appliance before using.

• To avoid electric shock or serious injury do not use any attachments that were

not recommended or sold by the manufacturer.

• Do not let power cord hang over the edge of table, counter, or let cord touch

hot surfaces such as stoves.

• To reduce the risk of injury, never place blade on base without properly

assembling the unit.

• This appliance has a polarized plug (one blade is wider than the other). To reduce

the risk of electric shock, this plug will fit in a polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified

electrician. Do not modify or force the plug in any way.

• The motor will not run if unit is not properly assembled. The motor has a built-in safety

feature that will not let the power turn on unless the locking bar is locked in place

and the pulp container is assembled properly.

HELPFULHINTS

ObtainthebestresultsfromyourJackLaLannePowerJuicer

Expressbyfollowingthesehelpfulhints.

• Do not put any fruit or vegetables in your machine until power is turned on.

• Allow unit to run for at least 10 seconds before juicing.

• Do not force food into the juicer. Allow food to pass through slowly and steadily

using the pusher. You do not need to apply pressure unless the juicer starts to

vibrate. Then only a slightly harder push should bring it back to balance.

• Any fruit or vegetable that will fit the chute can be put through whole. The only

time it is necessary to cut is when something is too large. Then it should be cut

into large enough pieces to fit in the chute. Do not cut pieces too small.

• Remove large pits such as peach, mango, etc. as they will damage the blade

and possibly the unit.

• Cleaning can be made easy by placing a plastic bag inside the pulp collector

container. When you are done juicing, the bag can be lifted out and disposed

of easily leaving the pulp collector easier to clean.

• Let the Power Juicer Express run for a few minutes before turning off to allow

any excess juice to be extracted from the pulp. Once turned off it is quite normal

for the juicer to spin for a minute or so due to the very fine precision balancing

of this appliance. Wait until it is done spinning before disassembling.

• Do not use bananas or avocados as they do not contain juice and will clog

machine. Add them separately in a blender.

• We do not recommend using overripe fruit as it will leave too much pulp

in the filter and clog the machine.

• Do not pour liquids into the machine at any time.

• Be sure to lower the juice spout before starting to juice.

• When adding long stalks such as carrots or celery add 3 at a time.

SAVE THESE INSTRUCTIONS

CLEANINGYOUR

POWERJUICEREXPRESS

• Turn off the power switch and wait until the motor completely stops.

• With dry hands, unplug the power cord from electrical outlet.

• Disassemble the machine. (See disassembly instructions.)

• Clean all other parts in warm, soapy water. A mild detergent is recommended. Rinse well

and dry thoroughly. All components are dishwasher safe with the exception of the base.

Do not use in European Import or a Commercial dishwasher.

• See instructions below for cleaning juice spout.

• Wipe base with a soft damp cloth or sponge. Do not submerge base in water.

Do not spray with water or any other liquid. Base is not dishwasher safe.

• To clean the filter/blade, hold under warm running water. Use a soft-bristled dish washing

brush gently to completely clean pulp from filter. Rinse the filter from the outside under

running water.

• Dry components thoroughly then assemble the machine and turn the power on to spin out

any excess water.

• Make sure unit and parts are completely dry then store in a cool, dry place.

• We recommend removing juice spout after each use.

To Clean Juice Spout:

STEP 1:

Locate removable juice spout locking mechanism on

the bottom side of receptacle.

Note: Juice spout will be in the locked position.

STEP 2:

To unlock, turn locking mechanism counter-clockwise,

lining up notch with juicer spout hinge pivot arm.

IMPORTANT: When reattaching juice spout back into

original position make sure juice spout is in the locked

position and tightly secured before use.

STEP 3:

Lift up juice spout carefully from receptacle

and remove to clean.

To Reattach: insert juice spout back into original

position and turn the locking mechanism clockwise to

lock into place.

Locking

Mechanism

Hinge

Pivot Arm

LOCKED POSITION

UNLOCKED POSITION

Locking

Bar

DISASSEMBLY

IMPORTANT: Before disassembling the unit make sure you turn the power OFF

and unplug the machine from the electrical outlet.

STEP 2:

Lower the locking bar (silver) into position

as shown.

STEP 3:

Remove lid with built-in pulp guard by

pulling up off of receptacle.

STEP 1:

Remove pusher from the chute.

STEP 5:

Remove filter/blade/receptacle unit from base

by grasping the receptacle with two hands. Then

lift receptacle and twist in either a clockwise or

counter-clockwise direction while pulling in an

upward direction until filter/blade/receptacle unit

is separated from the main base.

Note: Do not remove screws from blade. The filter

and the blade are one piece. They are not meant

to be separated.

STEP 4:

Remove pulp collector by sliding the

bottom away from the base in the

direction of the arrows while unhooking

from under lip on receptacle.

Chute

Pusher

Pulp

Collector Receptacle

Lid with built-in

Pulp Guard

Pulp Collector Base

Lip

Base

Receptacle

Lift and Twist......

Lip

Pulp Guard

Chute

Locking Bar

Pusher

Filter/Blade

MAIN UNIT

(Fully Assembled)

Receptacle

Removable

Juice Spout

Safety MicroSwitch

(Located on reverse side)

Base

Pulp

Collector

PARTSLIST

Lidwith Built-inPulp Guard

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Tristar Products Spremiagrumi

Tristar Products

Tristar Products PowerXL SHL96 Manuale utente

Manuali Spremiagrumi popolari di altre marche

GE 169201 Manuale utente

Exquisit

Exquisit ZP 3001 WET Manuale utente

Philips

Philips HR1851 Manuale utente

Sam Cook

Sam Cook MASTERCHEF EXECUTIVE PSC-50 Manuale utente

Termozeta

Termozeta spremiagrumi Manuale utente

ElectrIQ

ElectrIQ WF1000 Manuale utente

Bella

Bella WHOLE FRUIT JUICER Manuale utente

HAEGER

HAEGER Little Juice CJ-025 006A Manuale utente

Havells

Havells Fusion Manuale utente

Siemens

Siemens MK554 SERIES Manuale utente

Beper

Beper 90.302B Guida rapida

NATURSAFT

NATURSAFT 015.401.3 Manuale utente

Moulinex

Moulinex BKB 2 Manuale utente

Royal Catering

Royal Catering RCJU-01 Manuale utente

camry

camry CR 4002 Manuale utente

AIGOSTAR

AIGOSTAR 30HIM Manuale utente

ZUMEX

ZUMEX MINEX Manuale utente

Skymsen

Skymsen EX Manuale utente
