True Induction TI-2C PORTABLE Manuale utente
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL
TRUE INDUCTION DOUBLE BURNER
TI-2C PORTABLE
INDUCTION COOKTOP MANUAL
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL
Thank you for purchasing the True Induction Double Burner
Portable TI-2C cooktop. Please read the entire instruction
manual prior to using your unit. If you have any questions
regarding the True Induction cooktop please visit
http://www.Truelnduction.com or call: 1-877-862-7049.
I.
II.
III.
>
>
>
>
>
IV.
V.
VI.
1-2
2
3-4
3
3
4
4
4
5
5
6
Important safety Information.......................
Product Specifications................................
How to Use................................................
Power Invariance Technology..............
Using the Temperature Setting............
Using the Timer Function....................
Built-In Safety Shut Off.......................
Turning Off Unit..................................
Compatible Cookware.................................
Cleaning & Maintenance.............................
Troubleshooting Error Codes.......................
TABLE OF CONTENTS
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 1
• When the unit is on, do not touch outside the control panel as the surface may contain residual
heat.
• To protect against electric shock, do not immerse cord plugs or cooker in water (or other liquid
substances).
• When using any electric appliance used around children, close supervision is strongly
suggested.
• Do not operate any appliance with a damaged cord or plug, after a malfunction or if it has been
damaged in any manner. Read the seller's guidelines for warranty repairs and returns.
• Do not cook on a broken or damaged cooktop as spillovers may penetrate the surface and create
a risk of electric shock.
• To avoid potential injury, do not use accessory attachments which aren't recommended by the
manufacturer.
• Do not let the cord dangle over the edge of the table or counter. Keep the cord away from hot
surfaces.
• Do not place cooktop on or near: hot gas, electric burner or heated oven.
cooking area.
the unit.
• The power cord provided has been sized accordingly, however, with caution and care extension
cords may be used.
a. The marked electrical rating should be at least as great as the electrical rating of
the appliance.
b. The cord should be arranged so that it will not drape over the countertop or
tabletop where it can be pulled on by children or tripped over.
• Do not use with empty pans/pots.
• Do not place metallic objects such a knives, forks, spoons, lids, cans or aluminum foil on the
cooktop.
area.
When using electrical appliances, basic safety precautions should always be followed. For the
True Induction cooker, even with built-in safety features, it is essential to heed all precautions:
I. Important Safety Information
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 2
• This appliance has a polarize plug (one blade is wider than the other). To reduce the risk of
DO NOT attempt to modify
the plug in anyway.
• It is important to be aware that the unit's surface will remain hot for a short period of time after
use.
• Disconnect power and allow to cool before performing any maintenance or repairs.
• Clean cooktop with caution - do not clean while unit is still hot, some cleaners produce steam or
fumes if applied to a heated surface.
• Do not use cooktop for any other use then directed by the manufacturer.
Power
Voltage
Temperature Range
Level Selection
Max Time
Material
Unit Measurement
1800 Watts
12v/60Hz
150°F - 450°F (Exact Temp Settings)
Selecting Settings 1-10
Set Timer Up to 150 Minutes
Glass Ceramic Top
23 ” W x 15 ” L x 2 ¹²/” H
I. Important Safety Information Cont...
II. Product Specifications
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 3
The maximum power of an individual burner level is at setting 10. But, when operating both burners
their combined total is level 14, meaning that when operating the two burners at the same time
they'll self adjust levels accordingly:
• Plug the power plug into a standard outlet.
• The power button will light up and the unit will sound to indicate on.
• The device will remain in standby mode, awaiting user direction.
• Place ferromagnetic cookware (with water, oil or food already inside) on the center of the glass
ceramic top center.
• Now press the power button on the control panel, this will turn the cooktop on. The power display
will blink and sound another indicator.
• Press the heat function key once. The preset power level "5" is the default selection as the device
turns on.
• Using the +/ - keys you can change the settings at any time, ranging from 1 - 10. This is
considered to be the HEAT function.
• When you increase the power of one side, the power output of the other side will reduce
automatically (i.e., one side is at 6, the other burner automatically reduces power to level 8 creating
a total of max 14 setting).
• If one side of the double burner is using the HEAT function and the other side uses the TEMP
settings, the maximum HEAT setting is "5".
Using the +/ - keys you can change the temperature settings at any time. Settings range from
150-450° Fahrenheit. (Exact temperatures: 150, 180, 210, 240, 270, 300, 330, 360, 390, 420
and 450° F).
III. How to Use
Power Invariance Technology
Using the Temperature Setting
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 4
• Upon completion of cooking, the fan remains on for 1 minute to let the unit cool.
• After selecting the HEAT or TEMP mode, press the TIMER button once. The display will show the
number "0". Using the +/ - keys you can select the operating time in 5 minute intervals (up to max
150 min.) and reducing 1 minute.
• The display will count down the duration in minutes. Once the time is up, the unit sounds and
automatically goes into standby mode. To continue cooking, press the power button and heat button
to restart.
• During the timer operation, you can change the timer duration at any time with the arrow keys. The
device's built-in memory maintains the HEAT or TEMP setting previously entered.
• You can also change the HEAT or TEMP
• This function occurs for both the HEAT and TEMP settings. Display will show “H” if the cooking
zone is hot.
• In the event your food requires further cooking, the unit can easily be turned back on and reset to
the desired setting.
III. How to Use Cont...
Built-In Safety Shut Off
Turning Off Unit
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 5
Induction requires pots and pans that are made of ferrous (meaning magnetic) materials. Check
your cookware's retail box for the induction symbol. To tell if your current cookware is compatible with
the induction technology, grab a magnet and see if it holds. If your magnet stays then your cookware
is ready to be used on the True Induction double burner induction portable cooktop!
give the best results. Pans with warped or curved bottoms will not heat evenly. For wok cooking, use
DO NOT use a wok with a support ring. Look for this induction image on the retail
box:
• Heat-resistant glass, ceramic, copper, aluminum pan/pots, round bottomed cookware, or cookware
with a base less than 4.72 inches.
The following are NOT COMPATIBLE:
Induction
Please follow these directions along with important safety steps for cleaning advised at the beginning
of the manual:
• Before cleaning always switch OFF the device and wait for it to be completely cool. Clean the unit
after each use to remove food residues.
best). Dishwashing soap may be used when necessary.
• Make sure that no water seeps into the device. Never use abrasive cleaners (i.e. metal pads) or
oil based liquids. Never run the cooktop under water.
• A vacuum cleaner attachment may be used to suck up dirt from the air intake and exhaust vent.
IV. Compatible Cookware
V. Cleaning & Maintenance
DOUBLE BURNER TI-2C INDUCTION COOKTOP MANUAL P. 6
If the display shows an error code, please reference this sheet for a potential solution:
- -
E1
E2
E3
E4
E5
E6
E7
E8
Error Code Cause & Potential Solution
No cookware found or improper placement of cookware on
cooking zone. Ensure cookware is centered on cooking zone
and that it’s induction compatible *See COMPATIBLE COOKWARE
Internal circuit error, contact manufacturer
IGBT (Insulated Gate Bipolor Transistor) overheating. Turn
off the unit to allow IGBT to cool. Restart the unit once it has
cooled off
Supplied voltage to cooktop is too high. This may occur
when there is an decrease in voltage supplied to the house
circuit. Once the supplied voltage returns to normal, the
code will disappear.
Top plate sensor open/short circuit. Turn OFF the cooktop,
then shut off power at the circuit breaker for 30 secs. Turn
the power on and press POWER button to the unit. If error
message persists, call for service.
IGBT sensor open/short circuit. Turn OFF the cooktop, then
shut off power at the circuit breaker for 30 secs. Turn
the power on and press POWER button to the unit. If error
message persists, call for service.
Top plate overheating. Please turn off the cooktop to let it
cool down.
Control panel connection loosen, power sharing invalid.
Supplied voltage to cooktop is too low. This may occur
when there is an increase in voltage supplied to the house
circuit. Once the supplied voltage returns to normal, the
code will disappear.
VII. Troubleshooting Error Codes
