MODEL TYPE：BX1-250 Welder
Trueshopping
www.TrueShopping.co.uk
Page: of 26
1
Before putting the machine into operation,
read this instruction manual thoroughly.
Contents
What's In The Box.........................................................................3
Electrical Connection Warning.................................................5
Putting It All Together..................................................................9
Fixing the face shield................................................................9
Fixing the Wheels..................................................................... 9
Attach Handle.......................................................................... 11
Safety Precautions...................................................................... 12
Operation.................................................................................... 18
Adjustment switch.................................................................. 18
Overload light..........................................................................18
Using The Welder....................................................................19
Maintenance................................................................................21
Trouble Shooting........................................................................ 22
Specifications..............................................................................24
Trueshopping
www.TrueShopping.co.uk
Page: of 26
2
Diagrams
Figure 1 UK plug wiring.................................................................5
Figure 2 Fixing the face shield..................................................... 9
Figure 3 The wheel bar.................................................................9
Figure 4 Fixing the wheel........................................................... 10
Figure 5 Place cover on wheel....................................................10
Figure 6 The handle..................................................................... 11
Trueshopping
www.TrueShopping.co.uk
Page: of 26
3
What's In The Box
Thank you for purchasing the BX1-B and BX1-C series portable
moving coil type AC ARC Welder. Please read this manual
carefully before using.
The portable moving coil type AC ARC Welder is designed and
manufactured by our company and has many advantageous
features and excellent performance. This machine is fitted
with automatic temperature control and a wind-cooling device
for ensuring long-term efficient and safe work. It adopts
moving coil controllable current design with 230V, 50 Hz AC
power. It is convenient to use and is a leading portable
product in the domestic market.
The welder is a good performer for thick and thin board
welding. You can use single-phase power so it is particularly
suitable for mobile and field operation.
When you open the box you will see:
Welder with the clamp and torch pre-attached.
Small bag with 2 bolts and circlips for the wheels.
2 wheels.
Carry handle with metal wheel bar attached to it.
Mask.
Mask handle.
Mask glass in small rectangular card box
Trueshopping
www.TrueShopping.co.uk
Page: of 26
4
The main welding machine comes with the following
accessories:
Mask with welding screening black glass.
Operations manual
This product is in accordance with the relevant EC
Directives
Trueshopping
www.TrueShopping.co.uk
Page: of 26
5
Electrical Connection Warning
This machine MUST be earthed. This welder
must be connected to a 230 V (50 Hz)
supply, having a rated capacity of greater than
12 amps.
A 13 amp (BS1363) plug is NOT supplied for
this device. Connect the three core mains leads to a suitably
fused supply through an isolator and heavy duty plug.
UK only: Ensure the unit is correctly earthed via a three pin
plug.
1. Connect the green/yellow earth wire to the earth terminal
‘E’.
2. Connect the brown live wire to live terminal ‘L’.
3. Connect the blue neutral wire to the neutral terminal ‘N’.
4. After wiring, check that there are no bare wires, that all
wires have been correctly connected, that the cable
external insulation extends beyond the cable restraint and
that the restraint is tight.
Figure 1 UK plug wiring
Trueshopping
www.TrueShopping.co.uk
Page: of 26
6
WARNING! It is the user’s responsibility to
read, understand and comply with the
following:
You must check all electrical equipment and
appliances to ensure they are safe before using.
You must inspect power supply leads, plugs and all
electrical connections for wear and damage.
You must ensure the risk of electric shock is
minimised by the installation of appropriate safety
devices. An RCCB (Residual Current Circuit Breaker)
should be incorporated in the main distribution
board.
We also recommend that an RCD (Residual Current
Device) is used with all electrical products. It is
particularly important to use an RCD together with
portable products that are plugged into an
electrical supply not protected by an RCCB. If in
doubt consult a qualified electrician.
You may obtain a Residual Current Device by
contacting your dealer.
Trueshopping
www.TrueShopping.co.uk
Page: of 26
7
You must also read and understand the following instructions
concerning electrical safety.
The Electricity At Work Act 1989 requires all
portable electrical appliances, if used on business
premises, to be tested by a qualified electrician,
using a Portable Appliance Tester (PAT), at least
once a year.
The Health & Safety at Work Act 1974 makes
owners of electrical appliances responsible for the
safe condition of the appliance, and the safety of
the appliance operator. If in any doubt about
electrical safety, contact a qualified electrician.
Ensure the insulation on all cables and the product
itself is safe before connecting to the mains power
supply. Use a Portable Appliance Tester (PAT).
Ensure that cables are always protected against
short circuit and overload.
Regularly inspect power supply leads, plugs and all
electrical connections for wear and damage and
especially power connections, to ensure that none
is loose.
Important: Ensure the voltage marked on the
product is the same as the electrical power supply
to be used and check that plugs are fitted with the
correct capacity fuse. A 13 amp plug may require a
fuse smaller than 13 amps for certain products.
DO NOT pull or carry the powered appliance by its
power supply lead.
Trueshopping
www.TrueShopping.co.uk
Page: of 26
8
DO NOT pull power plugs from sockets by the
power cable.
DO NOT use worn or damage leads, plugs or
connections. Immediately replace or have repaired
by a qualified electrician.
Ensure an U.K. 3 pin plug with ASTA/BS approval is
fitted. In case of damage, cut off and fit a new plug
according to the following instructions. Discard old
plug safely.
Trueshopping
www.TrueShopping.co.uk
Page: of 26
9
Putting It All Together
After unpacking your new welder you should check if the
equipment has been damaged during transit and notify your
dealer if there are any missing or broken parts. Ensure that
the packing material is not blocking any air ways in the welder.
Fixing the face shield
Figure 2 Fixing the face shield
Fixing the Wheels
Place metal wheel bar through the holes in the
rear/bottom of welder and out the other side.
Attach one circlip to the groove closest to
welder on both sides so the bar is now held in
place.
Figure 3 The wheel bar
