Trust PowerCam Optical Zoom 970Z Manuale utente

TRUST 970Z POWERC@M OPTICAL ZOOM

Instructions when using for the first time Chapter

1. Preparing the camera (4)

2. Using the camera (5)

3. Advanced camera settings (6)

4. Connecting to a computer (7)

5. Application software (PC only!) (8)

1 Introduction

This instruction manual is for users of the TRUST 970Z LCD POWERC@M ZOOM.

The highest photograph resolution is 2048 x 1536 pixels (3.3 Mpixel). The camera

has an 8 MB internal flash memory, a webcam function, an automatic exposure, a

lens with a optical zoom, digital zoom and a flash function. The camera’s memory

can be increased up to a maximum of 512 Mbyte using an optional Secure Digital

Card (SD) or Multimedia Card (MMC). In addition, the camera can record short video

clips with sound. When using a MAC, be sure to read chapter 7.2. The included

application software only works on a PC in Windows.

Please consult one of the Trust Customer Care Centres if you have any problems.

You can find more information at the back of this instruction manual.

2 Safety

2.1 General information

Carefully read the following instructions before use.

-The TRUST 970Z POWERC@M OPTICAL ZOOM does not require any

special maintenance. Use a slightly damp, soft cloth to clean the camera.

-Do not use aggressive substances, such as white spirit, to clean the device.

These may harm the material.

-Do not submerge the device in liquid. This may be dangerous and will

damage the device. Do not use this device near water.

-Make sure nothing is placed on the cable. Do not use this device in an area

where the cable can become worn or damaged as a result of people walking

over it.

-Do not disassemble the camera. Touching the product’s internal parts could

result in injury. In the event of a malfunction, only a qualified technician

should repair the product. Should the product break open as a result of a fall

or other accident, take the product to an authorised service centre for

inspection.

-Avoid contact with liquid crystal. Should the LCD display break, care should

be taken to avoid injury due to broken glass and to prevent the liquid crystal

from touching the skin or entering the eyes or mouth.

-Do not look at the sun through the viewfinder. Viewing the sun or other strong

light source through the viewfinder could cause permanent visual impairment.

-Do not use in the presence of flammable gas. Using electronic equipment

near flammable gas could result in explosion or fire.

TRUST 970Z POWERC@M OPTICAL ZOOM

-Observe caution when operating the flash. Do not use the flash close to

anyone’s eyes. This can cause temporary damage to eyesight. Particular

care should be observed when photographing infants – keep the flash at a

distance of at least 1 meter from infants’ eyes.

2.2 Batteries

-Observe proper precautions when handling batteries. Uses only size AA

alkaline batteries. Batteries may leak or explode if handled improperly.

-The alkaline batteries supplied with the camera are not rechargeable. Do not

try to recharge them, because this may cause them to explode.

-Remove batteries (and memory card) from the camera if you are going to

store the camera for extended periods of time. Ensure the camera is turned

off before inserting or removing batteries.

-Do not insert batteries backwards or upside down.

-Do not disassemble batteries.

-Do not expose batteries to flame or excessive heat.

-Do not immerse batteries in or expose to water.

-Never throw the batteries onto an open fire. The batteries may explode.

-Keep the batteries out of the reach of small children.

-Discontinue use immediately if you notice any changes in the battery such as

discoloration, deformation or leakage.

-When the alkaline batteries are empty, ask your local authority where you

can dispose of them.

Note: Alkaline or NiMH batteries type AA are suitable for use with this

device.

Note: Do not use old and new batteries at the same time, because the

old batteries may deplete the new ones.

Note: The batteries should be removed if the camera is not going to be

used for some time. This will save the battery capacity.

3 Description of the camera

3.1 Front of the camera

Use table 1 in combination with figure 1.

Item Description Function

1Shutter Button Press this button to take pictures, or to

select menu options.

2Built-in Flash For taking photographs when there is

insufficient light. The flash has a maximum

effective range of 3 metres.

3Self-Timer LED When the mode dial is set to Pre-set and

the Self-Timer option is used before

pressing the Shutter Button, this LED will

blink for ten seconds before the camera

takes a picture.

4Light Sensor The digital camera automatically detects

ambient light levels and determines whether

or not the flash is needed. Light

measurements are made with this sensor.

TRUST 970Z POWERC@M OPTICAL ZOOM

Item Description Function

Take care not to block the sensor while

taking pictures.

5Viewfinder The viewfinder helps you frame a picture.

The actual picture is taken with the lens and

not the viewfinder, however.

6Lens The lens focuses the light onto the digital

image capturing circuitry. For the best

picture quality, care should be taken to

ensure it remains free of dust, fingerprints,

and scratches.

7Microphone Records audio when you use the camera for

filming 1-minute movies.

Table 1: Functions of the front of the camera

3.2 Rear of the camera

Use table 2 in combination with figure 2.

Item Description Function

1Status LED When power is first turned on, or the

camera is working (and not available to take

a picture), the LED will flash. When the

camera is ready to take a picture or accept

user commands, the LED is a solid green

colour.

2Viewfinder The viewfinder is used to frame your

pictures. The actual picture is taken with the

lens and not the viewfinder.

Power Button

Press this button to turn on the digital

camera. Press it again to turn it off.

4WB/Delete Press this button to cycle through the White

Balance pre-sets: Auto, Daylight, Shade,

Tungsten and Fluorescent. See also chapter

6.2.

5Strobe / Copy Copies pictures during playback from

internal, on-board camera memory to the

SD/MMC Card.

6Zoom Out Key While in Snapshot mode, press this key to

zoom out. If pressed repeatedly in during

Playback, Zoom Out switches between

thumbnail and full-screen views. If zooming

in on a photo during Playback mode,

pressing this key zooms back out again.

7Zoom In Key While in Snapshot mode, press this key to

zoom in on your subject. In Playback mode,

use this key to zoom in on a photo.

8Shutter Button Press this button to create a digital photo.

While navigating the camera’s options

menus, use it to select menu items..

9Power Plug the AC Adapter into the camera here to

supply it with electricity from an external,

non-battery power source

TRUST 970Z POWERC@M OPTICAL ZOOM

Item Description Function

10 Video Out Jack Connect your video out cable here and then

the other end to your television set in order

to use the camera as a digital video camera.

See also figure 8.

1. Turn off the camera.

2. Open the battery holder on the bottom of the camera by pressing on the

cover and sliding in the direction of the arrow toward the outside edge of the

camera.

3. Insert batteries into the chamber making sure that the positive and

negative ends are properly oriented, as indicated on the compartment’s

interior wall.

4. Close the battery cover.

The battery condition is shown on the LCD screen (bottom left-hand corner) as

follows:

The batteries are full.

The battery capacity is low. Only a few more photographs can be

taken.

Table 6: Battery conditions

4.3 Placing the camera on the tripod

Screw the tripod to the fixing point (1, figure 3) on the bottom of the camera. Make

sure the tripod is fitted as shown in figure 14, with the middle foot facing the side of

the camera with the USB/TV connection. Move the feet of the tripod as far apart as

possible, so that the camera is stable.

Caution: If the tripod is not fitted as described above, the camera could

easily fall over.

TRUST 970Z POWERC@M OPTICAL ZOOM

Note: You can also fit the camera to a more professional tripod. These

are available from your local photography shop.

5 Using the camera

This chapter will explain the following:

-How to set up the camera for the first time.

-The most used settings of this camera.

-How to take pictures in SNAPSHOT and PRE SET mode.

-How to record your video clips.

-How to review your pictures / video clips.

-How to connect the camera to a TV.

-How to turn-off the camera.

Note: Make sure you have installed 2 Alkaline or 2 NiMH batteries type

AA.

Note: If you want to store your photos on a SD/MMC Card, make sure it

is also installed before you turn on the camera. If you want to store

images directly to the camera's internal memory, either remove the

memory card, or select Internal from the Storage Media menu.

Note: Using the LCD display consumes more battery power. To prolong

the life of your batteries it is recommended to keep the LCD display

shut off when not needed.

5.1 Setting the camera for the first time

To use the camera for the first time it’s recommended to set the language and date

& time first before taking any pictures or recording any movies.

To go to the set-up menu of the camera do the following steps:

1. Rotate the Mode Dial to Set-up mode (2, figure 4).

2. Turn the camera on.

3. The Set-up menu will be displayed on the LCD (see figure 5).

Choose a language

The digital camera can display text and messages in English, French, Spanish,

German, Italian and Japanese.

To select a different language:

4. Use the Down button to select Language then press the Display button

to enter this menu.

TRUST 970Z POWERC@M OPTICAL ZOOM

5. Use the Up and Down buttons / to select the language you want

to use.

6. Press the Display button to set it. The Set-up Menu returns.

Set the date and time

When you transfer a photo to a computer and/or print it, the time and date will show

when it was taken.

To set the date display style:

1. Use the Down button to select Date/Time and then press the Display

button .

2. Select the Style option by using the Down button. Press the Display button

to enter that menu.

3. Choose either Month/Day or Day/Month as the display style for the date.

4. When the settings are correct, press the Display button to save the

changes and return to main menu.

5. Select again Date/Time and press the Display button .

6. Select the Clock option.

7. Use the Up and Down buttons / to set the time / date values.

8. Use the Strobe / Copy button (5, figure 2) to move through the time

and date fields.

9. When finished press the Display button to save the changes and return

to main menu.

Note: If you make a mistake and need to go back, use the White

Balance/Delete button .

5.2 Most used settings

5.2.1 LCD screen

The LCD screen can be turned off to save the batteries. You can also turn off the

menu items to have a better view of the image. The functions of the LCD button in

the PLAYBACK mode (3, figure 4) are different to the functions in the SNAPSHOT

(4, figure 4) or PRE SET mode (5, figure 4). The LCD button is 16 in figure 2.

PLAYBACK mode:

Press once to turn off the symbols.

Press twice to return to the beginning. The symbols are turned back on.

TRUST 970Z POWERC@M OPTICAL ZOOM

SNAPSHOT or PRE SET mode:

Press once to turn off the following indicators:

-pictures remaining

-quality

-battery status

Press twice to turn off LCD screen. The LCD screen is turned off to save the

batteries. Use the optical viewfinder to direct the camera.

Press once again to go back to the beginning. The LCD screen will be turned on

again and all symbols are visible.

5.2.2 Flash

The flash settings are automatic flash, never flash or automatic + red-eye reduction.

Carry out the following to set the flash:

1. Turn Mode Dial to SNAPSHOT or PRE SET mode.

2. Press button 5 (figure 2) to change flash-settings.

3. See table 7.1 for the description of the flash settings.

Symbol Name Description

< empty >

Auto Flash The camera senses whether the flash is

needed by detecting the amount of ambient

light.

Flash Off

Flash is turned off, regardless of the amount of

light available.

Red-Eye

Reduction

Use the Red-Eye Reduction function to reduce

the occurrence of "red-eye" (eyes appear red

in the pictures due to flash reflection off the

eyes’ retinas.) This function causes the camera

to flash quickly before the picture is taken to

reduce red-eye.

Flash On Flash is always on, regardless of light

available.

Table 7.1: Description of the flash-symbols

Note: The flash does not function when recording video clips.

5.2.3 Zoom

Optical Zoom

This camera has an optical zoom which allows you to zoom on a subject in the

highest resolution. Use Zoom In button (7, figure 2) to enlarge the subject or

Zoom Out button (6, figure 2) to widen the area of the subject. When using

optical zoom the zoom-indicator at the left of the LCD screen (9, figure 6) will be in

the white area.

TRUST 970Z POWERC@M OPTICAL ZOOM

Digital Zoom

This function allows you to zoom up to 3 x on a subject in 5 steps when taking a

photograph. In the PLAYBACK mode, you could zoom in on parts of a photograph or

display a number of photographs on the screen at once. The zoom ratio will appear

on the middle top of the LCD screen (figure 6) and the zoom-indicator (9, figure 6)

will be in the red area.

Note: The use of the digital zoom function when taking photographs will

slightly reduce the quality.

Note:The digital zoom does not function when recording video clips.

5.3 Taking pictures

There are two modes for taking pictures: SNAPSHOT and PRESET. Snapshot mode

is for basic picture taking, while the Pre-set mode allows you to take pictures in one

of five pre-set schemes: Landscape, Portrait, Night Scene, Self-Timer and Macro.

5.3.1 Taking pictures in SNAPSHOT mode

Note: To save the batteries, the camera will turn off automatically when it

has not been used for 3 minutes

See figure 2.

1. Turn the camera on using the ON/OFF button (3).

2. Place the MODE DIAL (13) in the SNAPSHOT mode (4, figure 4).

3. You can turn on/off the LCD screen by pressing the LCD button (16) or you

can use the viewfinder (2). If the LCD screen is used, all the settings will also

be visible. See chapter 3.5 for their meaning.

4. Look through the viewfinder or look at the LCD screen to get a good image of

the subject.

5. You can use the Zoom In or Zoom Out buttons to narrow or

widen the lens’ field of view. Use the LCD display to preview the effects of

the zoom function.

6. Press the SHUTTER button (8) half way and keep it in this position. The

camera will adjust itself to the surrounding light conditions and then beep (if

the beep-settings on the camera is switched on).

7. Fully press the SHUTTER button. The photograph will now be taken. The

image on the LCD screen will disappear for a short period and the LED (1)

will flash.

8. The next photograph can be taken when the LED no longer flashes. The

photograph has been saved in the camera’s memory.

Note: Keep the glass of the lens clean. Use a lens tissue to clean the lens. If

necessary, use special cleaning liquid for camera lenses. Do not use

a different cleaning product.

Tip: The quality of the photograph depends on the surrounding light. More

light will result in a better picture.

Tip: The number of photographs that can be taken depends on the

number of details of the object to be photographed. The photograph

indicator on the LCD screen is an approximation.

Tip: The image viewed through the viewfinder may be slightly different to

what is recorded through the lens. You can use the LCD for greater

accuracy.

Indice

Altri manuali Trust Macchina fotografica digitale

Trust

Trust POWERCAM VIDEO DV-2400V Manuale utente

Trust

Trust 350FS POWERC@M FLASH Manuale utente

Trust

Trust FAMILYC@M 300 DIGITAL MOVIE Manuale utente

Trust

Trust DC-4700 POWERCAM OPTICAL ZOOM Manuale utente

Trust

Trust POWERCAM OPTICAL ZOOM 910Z Manuale utente

Trust

Trust 735 Powercam Zoom Manuale utente

Trust

Trust DC-4200 Manuale utente

Trust

Trust FAMILYCAM 300 Manuale utente

Trust

Trust FAMILYC@M 500 FLASH Manuale

Trust

Trust FlexCam Manuale utente

Trust

Trust PowerCam Mini DC-3500 Manuale utente

Trust

Trust 1210K POWERCAM OPTICAL Manuale utente

Trust

Trust PowerCam Zoom 920 Manuale utente

Trust

Trust 913 POWERC@M ZOOM Manuale utente

Trust

Trust POWERCAM CCD 960 Manuale utente

Trust

Trust 962Z POWERC@M Manuale utente

Trust

Trust 610 Manuale utente

Trust

Trust 1490Z Manuale utente

Trust

Trust FAMILYCAM 510FX Manuale utente

Trust

Trust 735S POWERCAM ZOOM Manuale utente

Trust

Trust 782AV Manuale utente

Trust

Trust POWERCAM 922Z Manuale utente

Trust

Trust 740C POWERC@M ZOOM Manuale utente

Trust

Trust 1290Z Manuale utente

Manuali Macchina fotografica digitale popolari di altre marche

Mercury

Mercury 350K Manuale utente

Pentax

Pentax Optio LS 465 Manuale utente

Sanyo

Sanyo VPC-S1085 Manuale utente

GE SMART A1255 Manuale utente

Point Grey

Point Grey Gazelle Manuale utente

Nikon

Nikon COOLPIX A Manuale utente

Pentax

Pentax P-5 Manuale utente

BlazeVideo

BlazeVideo A280 Manuale utente

Sony

Sony MCA-20 Manuale utente

Sony

Sony Alpha DSLR-A290 Manuale utente

ATIK Cameras

ATIK Cameras One Manuale utente

CohuHD Costar

CohuHD Costar 3930 Series Manuale utente

Leica

Leica M10-R Manuale utente

FujiFilm

FujiFilm FinePix A700 Manuale utente

Lorex

Lorex LNZ81P25 Series Manuale utente

GE J1470S Manuale utente

Sony

Sony A6700 Guida utente

Canon

Canon EOS ELAN7 Manuale utente
