TTI FABRICATION STRATOS 40 Manuale utente

Swimming Pool Heat Pump

INSTALLATION AND OPERATION MANUAL

IMPORTANT

Please register your product with us on our web site.

www.ttifab.com

Content

1. APPLICATION...................................................................................................................................3

2. FEATURES..........................................................................................................................................3

3. TECHNICAL PARAMETERS..........................................................................................................4

3.1 Remarks.........................................................................................................................................4

3.2 Options for protecting devices.......................................................................................................4

4. POSITIONING.....................................................................................................................................5

4.1 Ventilation and accessibility...........................................................................................................5

4.2 Other recommendations.................................................................................................................5

4.3 Water supply and backflow plumbing connections........................................................................6

4.4 Minimum and maximum water flows............................................................................................6

5. CHLORINATORS, BROMINATORS AND OTHER AUTOMATIC SYSTMES ......................7

5.1 Basic connections, inline chlorinator or brominator......................................................................7

5.2 Salt Chlorinators............................................................................................................................7

5.3 Pressurized chlorinator or brominator............................................................................................7

6. ELECTRICAL POWER CONNECTION.........................................................................................8

7. OPERATION INSTRUCTIONS........................................................................................................9

7.1 Operations display..........................................................................................................................9

7.2 Water temperature setting...............................................................................................................9

7.3 Time setting....................................................................................................................................9

7.4 Timer on and off...........................................................................................................................10

7.5 Cancel timer on and off................................................................................................................10

8. TESTING............................................................................................................................................11

8.1 Inspection before use....................................................................................................................11

8.2 Trial..............................................................................................................................................11

9. PRECAUTIONS.................................................................................................................................11

9.1 Attention.......................................................................................................................................11

9.2 Safety............................................................................................................................................12

9.3 Warning........................................................................................................................................12

9.4 Precautions...................................................................................................................................12

10. MAINTENANCE.......…………...............................…………………......……………………….13

11 TROUBLE SHOOTING FOR COMMON FAULTS....................................................................13

12. FAILURE CODES...........................................................................................................................14

1. Application

Set swimming pool water temp efficiently and economically to provide you comfort and pleasure

2. Features

•High efficient titanium heat exchanger

•Sensitive and accurate temp control and water temp display

•High pressure, low pressure & water flow protection system

•Exceeding low outdoor temp auto stop protection

•Temp control compulsory defrosting

•International brand compressor

•Easy installation and operation

3. TECHNICAL PARAMETERS

MODEL STRATOS 40 STRATOS 50 STRATOS 65 STRATOS 80 STRATOS 100 STRATOS 120

Heating capacity 40000 BTU 50000 BTU 65000 BTU 80000 BTU 100000 BTU 120000 BTU

Breaker 20A 20A 30A 40A 40A 50A

Voltage 230V

Frequency/phase 60Hz/1Ph

Current* 6.2 A 8.7A 10.4 A 14.6 A 20 A 24 A

Heating power* 1.5 KW 2.1 kW 2.7 kW 3.6 kW 4.5 kW 5.7kW

Current** 6.9 A 9.5A 11.4 A 15.9 A 21.6 A 26A

Heating power** 1.7 KW 2.4 kW 3.2 kW 4.3 kW 5.4 kW 5.9 kW

Compressor RLA/LRA

7.8A/43.5A 10.7A/57.5A 13.4A/75A 17.9A/90A 38.4A/139A 37.5A/168A

Fan motor rating

0.43 A 0.58 A 0.74 A 0.92 A 1.8 A 1.8 A

Design pressure (High)

≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG ≥500 PSIG

Design pressure (Low)

≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG ≤250 PSIG

Noise Level 50 53 53 53 55 55

Refrigerant (R410A) 40 oz (1.13 kg) 48oz (1.36 kg) 56oz (1.59 kg) 64oz (1.81 kg) 88 oz (2.49 kg) 92 oz (2.6kg)

Net weight 45 KG 60 kg 65 kg 75 kg 85 kg 95 kg

Water circulation flow 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM 15-45 GPM

Test conditions: All tests were performed at a 700M altitude.

*Air temperature: 80°F, Water temperature: 80°F, Humidity: 80%

**Air temperature: 80°F, Water temperature: 95°F, Humidity: 80%

3.1 Remarks:

•This product can work well with temperatures between 7°C to 35°C (45°F-95℉). Efficiency

will not be guaranteed out of this range and parameters are different under various conditions.

•Related parameters are subject to adjustment periodically for technical improvement without

further notice. For details, please refer to nameplate.

•Machine has heat function only

Note：The swimming pool heater must be grounded well.

3.2 Options for protecting devices.

Model STRATOS 40 STRATOS 50 STRATOS 65 STRATOS 80 STRATOS 100 STRATOS 120

Breaker Rated current (A) 20 20 30 40 40 50

Fuse (A) 20 20 30 40 40 50

4. POSITIONING

Choosing the area where your heat pump will be installed is extremely important. You must respect the

following guidelines.

4.1 Ventilation and accessibility

Your heat pump works, in large part, in symbiosis with the surrounding air: it is important that there be

adequate ventilation all around the heat pump. Therefore, the device should not be installed in a closed

space such as a garden shed or a basement.

Important:Your heat pump must have sufficient free space around it to function properly.

You should also clear any obstructions surrounding the heat pump, as indicated in the table below:

ALL MODELS

(1) in front of the evaporation coil

60 cm = 2 feet

(2) in front of all other surfaces

120 cm = 4 feet

(3) in front of the fan*

120 cm = 4 feet

(4) in front of the service panel

120 cm = 4 feet

*Objects should be placed as far away as possible from the area where air is evacuated.

4.2 Other recommandations

You should not install the device below a roof, so that your heat pump becomes buried under snow or

receives too much water if the roof is not fitted with gutters. Do not install your heat so that the sun

directly hits the regulator. This will not cause damages, but the display will be harder to read.

Similarly, you should not install automatic sprinkler near your pool heat pump. The device must be

installed on a flat, firm and level surface. A concrete slab or equivalent is preferred. Consider that your

device will produce condensation, so there will be water leaking around the unit.

It is highly recommended to use a solar blanket to cover the pool in order to reduce the heat and

loss, mainly during colder nights

4.3 Water supply and backflow plumbing connections

All STRATOS model connections have a 1 ½’ diameter.

4.4 Minimum and maximum water flows

For maximum efficiency, your heat pump must operate with water flows between 57 liters per minute

(15 U.S. gallons per minute) and 170 liters per minute (45 U.S. gallons per minute). With a water flow

of less than 57 lpm (15 U.S. GPM) and greater than 170 lpm (45 U.S. GPM), the heat pump will not

work properly and will suffer damage. (See table below).

Aset of valves (Fig. A) to isolate the heat pump and adjust the water flow must be installed.

We recommend installing this set of valves (Fig. A) in order to be able to adjust the optimal water flow

circulating in the heat exchanger (condenser). An adjustable automatic bypass valve must be installed

when a water pump of 2 HP or more is used to circulate the pool water.

Your water pump must be able to supply each heat pump with a water flow within the limits listed

below.

MODEL MINIMUM IDEAL MAXIMUM

STRATOS 40-50-65-80-100 57 l/m (15 GPM US) 170 l/m (45 GPM US) 170 l/m (45 GPM US)

1 U.S. gallon per minute (1GPM US) = 3.78 liters per minute (3.78 l/m)

WARNING

If the above-prescribed water flows are not respected,

damage will ensue and your warranty will be void.

WARNING

Pool heat pumps normally operate with (12-15 PSI) water pressure.

The maximum operating water pressure is 2.0 bars (30 PSI). Failure

to respect the prescribed water pressures will void the warranty of

your heat pump.

WATER OUT

By-pass valve closed during operation

WATER IN

BYPASS VALVES

5. CHLORINATORS, BROMINATORS AND OTHER AUTOMATIC SYSTEMS

5.1 Basic connections, inline chlorinator or brominator

This connection is mandatory to ensure the long working life of your pool heat pump.

Any automatic distribution system for chemicals, chlorine, bromine or other, must be installed so that

the distribution system’s water output is located after the pool’s heat pump. The heat pump’s warranty

will be void if the installation is not compliant to this rule.

5.2 Salt chlorinators

Salt chlorinators are made to be installed as inline chlorinators. Therefore, they must be installed as

prescribed in the section above (“inline chlorinator or brominator”).

5.3 Pressurized chlorinator or brominator

Pressurized chlorinators or brominators start by using a small quantity of water as it exits the filter, then

add chemicals and forward this highly concentrated solution into the pool. Check valves must therefore

be extremely resistant to corrosion. Only use the valves that have been supplied or recommended by

the manufacturer of your chlorinator or brominator.

6. CONNECTION TO ELECTRICAL POWER

WARNING

To ensure your safety and the proper functioning of the device, the electrical

connections must be performed by a qualified electrician according to national

codes, provincial and local regulations.

A circuit breaker must be installed close to the heat pump, in an accessible location.

Never open the electrical box without shutting off the power to all sources used for the operation of the

heat pump. If your heat pump has a pool pump control option, remember to close the circuit breaker to

this pump.

The spec sheet for the heat pump contains all the requirements for voltage and amps.

If the power cord is damaged, it must be replaced by a qualified electrician.

7. OPERATION INSTRUCTIONS

7.1 Operation Display

•The display shows Time when the machine is off

•The display shows Temperature of the swimming pool water when the machine is on.

7.2 Water temperature setting

•Press the key or to set water temperature. The controller indicates flashing temp.

•Press or to adjust to your desired water temp.

•5 seconds later, the controller display will back to the normal mode.

•Switching between F° and C°, hold for 10 seconds

7.3. Time setting

•Available no matter whether the machine is on or off. Press key to set time，when the

clock on the screen is flashing, press again to set hour. Use or to adjust

hour.

•Before the flashing stops, press to set minute. Use or to adjust. After

adjusting，press and water temperature will be displayed. 30 seconds later，the controller

display will be back to the normal mode.

7.4. Timer on and off

•Press set timer on. When the indicator light is on and the time is flashing, press again to set hour.

Use or to adjust. Before the flashing stops, press to set minute.

•Use or to adjust. After adjusting, press and water temperature will be seen.

•30 seconds later, the controller display will be back to the normal mode.

•Press to set timer off. When the indicator light is on and the time is flashing, press

again to set hour. Use or to adjust before flashing stop, press to set minute.

Use or to adjust. After adjusting, press and water temperature will be seen.

30 seconds later, the controller display will be back to the normal mode.

7.5. Cancel timer on and off

•Press or to cancel timer on and off. When the number is flashing, press when

timer indicator light is off and LED shows water temperature, the timer on and off is canceled.

30 seconds later, the controller display will be back to the normal mode.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali TTI FABRICATION Pompa di calore

TTI FABRICATION

TTI FABRICATION ECOLO 50 Manuale utente

Manuali Pompa di calore popolari di altre marche

MICROWELL

MICROWELL HP 1000 GREEN Manuale utente

Sanyo

Sanyo SAP120FCH Manuale utente

Daikin

Daikin EHYHBH05AA Manuale utente

Panasonic

Panasonic WH-SDF03E3E5 Guida

Bryant

Bryant 544B Manuale utente

Airxcel

Airxcel 45000 Series Manuale

Mitsubishi Electric

Mitsubishi Electric PUZ-SWM60VAA Manuale utente

Dimplex

Dimplex LI 16I-TUR Guida utente

Carrier

Carrier WSHP Open v3 Guida rapida alla configurazione

TGM

TGM CTV14CN018A Manuale utente

Carrier

Carrier 38MGQ Series Manuale utente

Kokido

Kokido K2O K880BX/EU Guida alla risoluzione dei problemi

Viessmann

Viessmann VITOCAL 300-G PRO Type BW 2150 Guida rapida

Carrier

Carrier 48EZN Manuale utente

Viessmann

Viessmann KWT Vitocal 350-G Pro Series Istruzioni operative

Ariston

Ariston NIMBUS Manuale utente

Weishaupt

Weishaupt WWP L 7 Guida utente

GE Zoneline AZ85H09EAC Manuale utente
