TurboChef TORNADO Manuale utente

This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.

Preventive Maintenance Guide PREP PAGE 2.48

PREP/SERVICE AREA Tornado Oven – TurboChe

Clean ven Interior and Exterior

12/07

What You Will Need:

• SUBWAY®Oven Cleaner

• SuperSanTM sanitizer

• Nylon scrub pad

• Cleaning towel

Speed oven should be cleaned each morning

before it is turned on to avoid having to wait

for it to cool down

Prepare the ven for Cleaning

1. Turn off the oven by pressing the “BACK”

key on the control pad – the control panel

will display the message “ VEN FF

C LING D WN”. The cooling process will

take approximately 90 minutes.

✓TASK QUICK STEPS

✓Turn off the oven – press the “BACK”

key on the control panel, and wait 90

minutes for the oven to cool

completely

✓Clean food particles from lower access

panel – remove panel, wipe out with

damp cloth, reattach panel

✓Clean wire rack – remove; wash, rinse,

sanitize and let dry; reinstall

✓Clean interior – under bottom heating

element, with damp towel; remove

stains; wipe heating element;

thoroughly dry cooking cavity –

especially bottom of cook cavity and

wave guide covers

✓Clean exterior – where access panel is

connected and all other finished

surfaces

Do not attempt to clean the

Tornado oven during the cool

down cycle, as indicated by the

“COOLING DOWN” message

displayed on the control panel – the oven

operates at 500° /260°C and may cause

injury if not allowed to cool completely

before cleaning

CAUTION

This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.

Preventive Maintenance GuidePREP PAGE 2.49

PREP/SERVICE AREA Tornado Oven – TurboChe

Clean ven Interior and Exterior continued

12/07

Clean Food Particles from Lower Access Panel

1. Remove the lower access panel, below the

oven door – grip the panel on both ends and

pull to disengage the four clips that secure

the panel to the oven

2. Wipe out any food particles and crumbs that

have collected inside the access panel and

around the oven base with a towel

Clean the Wire Rack

1. Remove the wire rack from inside the oven

2. Wash and rinse the wire rack, and then sanitize

using SuperSan™ sanitizer; let dry

Clean the ven Interior

1. Lift the bottom heating element, and while

holding it up, use a damp towel to remove any

large food particles from the bottom of the oven

2. If stubborn stains are present, sparingly spray

SUBWAY®Oven Cleaner into the oven cavity

and on the inside of the door, and allow the

cleaner to penetrate for five minutes

•

Only use SUBWAY®Oven Cleaner – using any

other cleaning products can damage critical

parts and may void the warranty on those parts

• Never saturate the bottom of the oven

with water or oven cleaner – doing so will

damage vital components and result in a

non-warranty service call

• Never spray the top of the cavity

Do not touch the heating

element until the cool down

cycle has completed and the

element has cooled completely

– the heating element operates at

1000° /538°C and can cause burns if not

completely cooled

CAUTION

This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.

Preventive Maintenance Guide PREP PAGE 2.50

PREP/SERVICE AREA Tornado Oven – TurboChe

Clean ven Interior and Exterior continued

12/07

3. Using a nylon scrub pad, clean the oven

interior and door, being careful not to apply

pressure to the Wave Guide Caps – breaking

the caps will result in a non-warranty service

call

4. Cracked wave guide covers must be replaced

immediately

5. Wipe the oven interior, heating element,

and door using a clean damp towel. Repeat

as necessary until all oven cleaner residue is

removed

Clean ven Exterior

1. Wipe the area beneath the oven door –

Do NOT spray any chemical in this area!

2. Wipe the oven exterior with a clean, damp

cloth

This manual contains confidential information, It is not to be copied, or duplicated without the consent of Doctor’s Associates Inc.

Preventive Maintenance GuidePREP PAGE 2.51

PREP/SERVICE AREA Tornado Oven – TurboChe

Clean ven Interior and Exterior continued

12/07

Prepare the ven for peration

1. Lower the bottom heating element and

reinstall the wire rack

2. Reinstall the lower access panel

3. Power up the oven – Press the “ VEN N”

soft key, and the control panel will display

“WARMING UP”. It will take approximately

15 minutes for the oven to warm up, and

the oven will sound a tone when the oven is

ready to use.
