Touch Board

User Guide

Touch Board 1

Portions Responsive Innovations, LLC, Microsoft Corporation

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose,

Turning Technologies, LLC, 255 West Federal Street, Youngstown, OH 44503 USA.

TurningPoint® is a registered trademark of Turning Technologies, LLC. Other trademarked product names mentioned in this manual

are owned by their respective companies.

The following regulatory statements apply to radio frequency and infrared transmitters and receivers mentioned in this manual,

including the ResponseCard RF, ResponseCard RF LCD, ResponseCard IR, ResponseCard XR, ResponseCard NXT, QT Device,

CPS IR, CPS Pulse, CPS Spark, Gen 2, PRS RF, PRS IR, DualBoard, Touch Board, Touch Board Plus, MeetingBoard, SchoolBoard,

iPannel, Mobi, MobiView, MobiKWIK, Mobi Learner, Mobi 360 and their respective receivers.

FCC Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any interference received, including interference that may cause

undesired operation.

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate

the equipment.

IC Statement

This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1)

this device may not cause interference, and (2) this device must accept any interference, including interference that may cause

undesired operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est

autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter

tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.

turningtechnologies.com/user-guides

Touch Board 2

TABLE OF CONTENTS

OVERVIEW 3

What's in the Box? 3

TECHNICAL REQUIREMENTS 4

Hardware 4

Software 4

Installing Ubuntu GNOME 5

SET UP 6

Installing WorkSpace 6

Mounting the Touch Board 7

Connecting the Video Projector 8

Connecting the Touch Board via USB 8

Calibrating the Touch Board via Device Manager 8

Calibrating the Touch Board (Windows 7 and Windows 8) 9

USING THE TOUCH BOARD 10

Mouse Actions 10

Touch Gestures 10

Care and Maintenance 11

Additional Solutions 11

WORKSPACE 12

WorkSpace Window 12

WorkSpace Modes 14

Annotating 14

Multi-User Mode 14

Setting Up Multi-User Mode 15

Selecting the Presenter 16

Locking Tablets and Clickers 16

Distributing WorkSpace Files 16

Distributing Files as GWB (PC Only) 16

Distributing Files as IWB 17

Exporting Files 17

DECLARATION OF CONFORMITY 18

turningtechnologies.com/user-guides

Touch Board 3

OVERVIEW

Built on the popular functionality of the DualBoard™, Touch Board features touch technology, allowing instructors and

participants to interact with the whiteboard using the Touch Board Wand or their fingers. Two points of contact can be used on

the Touch Board at the same time.

Touch Board Plus comes with Turning Technologies' WorkSpace® software, which allows for seamless creation of interactive

content. With Touch Board, you can control your WorkSpace lesson via the board's touch technology. Additionally, Touch

Board provides the ability to incorporate and work with teaching material in multiple formats from any source, including

ExamView® content, web-based content or third-party curricula.

WARNING

Do not assemble or use this product before reading the installation instructions.

Assemble and use this product only in accordance with the installation instructions.

What's in the Box?

Touch Board is compatible with most Mac, Windows® and Linux® operating systems. Refer to the Technical Requirements

on page 4 for software and hardware requirements.

WorkSpace DVD Wall Hanger

WorkSpace Content DVD Two (2) anchor clips

WorkSpace Language Pack DVD Four (4) mounting brackets

Touch Board User Guide Eight (8) bracket screws

Four (4) non-electronic Touch Board

pens USB Cable

Touch Wand

turningtechnologies.com/user-guides

Touch Board 4

TECHNICAL REQUIREMENTS

Touch Board is designed to function with most computers; however, there are some basic hardware and software

requirements.

Hardware

Touch Board

lUSB port

Touch Gestures

lWindows® 7 or Windows® 8

Software

WorkSpace

lMicrosoft Windows® XP SP 2,

Vista, 7 or 8

lIntel® Pentium® dual-core

processor, 2 GHz or higher (or

equivalent)

l2 GB RAM

l1 GB hard disk space for

installation (600 MB for additional

Gallery content)

lDVD-ROM drive for installation

lUSB port

lXVGA (1024x768) or higher

resolution with minimum 24-bit

color

lVideo card with support for DirectX

9 or greater

lSpeakers and microphone for audio

and video files

lAdobe® Flash® Player 9.0 or

higher

Mac

lOS X v.10.7, 10.8 or 10.9

lPowerPC G4 1GHz or

higher

l512 MB RAM

l1.8 GB hard disk space for

installation

lDVD-ROM drive for

installation

l1024x768 or higher

resolution

lUSB port

lJava™ 6 or higher

l“libUSB” - USB support

Linux

lUbuntu GNOME 12.04 (LTS) or 14.04

lIntel® Pentium® IV Processor 1 GHz

or higher (or equivalent)

l512 MB RAM

l1.5 GB hard disk space for installation

l1024x768 or higher resolution

lDVD-ROM drive for installation

lUSB port

lXDG compliant (menus and file

association)

l"gksu" utility is required to run the

installer on Ubuntu 14.04

turningtechnologies.com/user-guides

Touch Board 5

Installing Ubuntu GNOME

TouchBoard must be used with the Ubuntu GNOME environment. Follow the steps below to install GNOME.

1Ubuntu 12.04 users: open Terminal and run one the following commands:

lsudo apt-get install gnome -session -fallback

lsudo apt-get install gnome -session -panel

2Ubuntu 14.04 users: open Terminal and run the following command:

lsudo apt-get install gnome -session -flashback

3Ubuntu 12.04 users must log in with GNOME Classic (No effects). Ubuntu 14.04 users must log in with GNOME

Flashback (Metacity)

turningtechnologies.com/user-guides

Touch Board 6

SET UP

This chapter covers:

Installing WorkSpace

Mounting the Touch Board

Connecting the Video Projector

Connecting the Touch Board via USB

Calibrating the Touch Board via Device Manager

Calibrating the Touch Board (Windows 7 and Windows 8)

Installing WorkSpace

You must have administrative privileges to install WorkSpace. If you do not have administrative privileges on your computer,

contact your IT department.

Prerequisites

The WorkSpace disc and Content disc are required unless the software is downloaded from

http://www.turningtechnologies.com/responsesystemsupport/downloads.

PC and Mac

1Insert the WorkSpace disc into the DVD drive. If the disc does not auto-run, navigate to your disc drive and double-click

the auto-run.exe file.

2Follow the on-screen prompts to proceed through the installation process.

3Repeat steps 1 and 2 using the WorkSpace Content disc.

4Restart your computer to complete the installation process.

After the installation, a shortcut for the software will appear on the desktop and the Turning Technologies icon will

appear in the notification area (PC)/Menu Extras area (Mac).

Linux

1Login as "root" or "sudo."

2Insert the WorkSpace disc into the DVD drive. Double-click the DVD icon that appears on the desktop.

3Under Permissions, select Allow executing file as program.

4Follow the on-screen prompts to proceed through the installation process.

After the installation, the software can be found in Home\eInstruction\WorkSpace\WorkSpace.

5Repeat steps 1 - 4 using the WorkSpace Content disc.

6Restart your computer to complete the installation process.

turningtechnologies.com/user-guides

Touch Board 7

Mounting the Touch Board

WARNING

It is recommended that a skilled professional assess the strength of the wall and determine the

appropriate hardware required to securely attach the Touch Board to the wall. A minimum of two people

are required to safely lift and mount the board to the wall.

1Attach the wall hanger to the wall.

2Using the provided bracket screws, attach the two anchor clips to the bottom of the Touch Board.

3Carefully mount the Touch Board on the wall hanger.

4Secure the anchor clips to the wall.

turningtechnologies.com/user-guides

Touch Board 8

Connecting the Video Projector

TIP

For optimal usage and viewing, the minimum

required screen resolution should be set at 1024 x

768.

1With the computer turned on, connect the projector video

cable from the computer to the video projector.

2Turn on the video projector.

3With the video projector aimed at the Touch Board, align the

projected image onto the Touch Board so that it is within the

board's active area.

Connecting the Touch Board via

USB

The Touch Board connects to your computer via a USB cable. A separate power supply is not necessary since the Touch

Board is powered through the USB connection.

1Plug the USB cable into the USB port on the right side of the board.

2Plug the other end of the USB cable into a working USB port on your

computer.

TIP

A powered USB hub may be used.

3Ared light at the bottom of the board indicates that the board is receiving

power through the USB cable. A blue light indicates the proximity of the

pen to the board.

Calibrating the Touch Board via Device Manager

Recommended for OS X and Linux platforms, as well as PC users who need to recalibrate Touch Board.

IMPORTANT

Linux users must calibrate the DualBoard in the Ubuntu GNOME environment. Refer to Installing

Ubuntu GNOME on page 5.

The steps below walk you through performing a calibration via Device Manager. Aside from using these steps on an OS X or

Linux platform, you can also perform them on a PC if you moved the Touch Board. It is strongly recommended to recalibrate

the Touch Board if the board or projector has been moved.

NOTE

If an error occurs during the calibration process, end the process and start over.

1From your computer, right click/control-click the Turning Technologies icon in the notification area (PC)/Menu

Extras area (Mac)/Applications (Ubuntu GNOME).

turningtechnologies.com/user-guides

Touch Board 9

2Select eInstruction Device Manager.

The Device Manager window opens.

3Select the Touch Board device from the Device Manager window.

4Select the Calibrate icon from the toolbar.

The Calibration window opens.

5Touch each target as it appears on the board.

TIP

For optimal accuracy, use a Touch Board pen during the calibration process.

NOTE

In addition to the Device Manager calibration, Windows 7 and 8 requires a second calibration when using

the Touch Board independent of WorkSpace. Refer to Calibrating the Touch Board (Windows 7 and

Windows 8) on page 9 for instructions on performing the second calibration.

Calibrating the Touch Board (Windows 7 and Windows 8)

Prerequisites

You must have administrative privileges to perform the Touch Board 16 pt. calibration. After the initial 16 pt. calibration, a 4 pt.

calibration can be performed by a non-administrative user. If you do not have administrative privileges, contact your IT

department.

1From your computer, right-click the Turning Technologies icon in the

notification area.

2Select eInstruction Device Manager.

The Device Manager window opens.

3Right/control-click the Touch Board device from the Device Manager window.

4Click Touch Settings.

The Tablet PC Settings window opens.

5From the Tablet PC Settings window, click Calibrate.

NOTE

If the board has been previously calibrated, click Reset to erase previously stored calibration

data.

6Touch each target as it appears on the board.

7After the calibration, you must save the calibration data by clicking Yes from your keyboard or mouse.

NOTE

This calibration only needs to be performed once. If the Touch Board and/or projector is moved, you must

perform both calibrations again.

turningtechnologies.com/user-guides

Indice

Altri manuali Turning Technologies Lavagna bianca

Turning Technologies

Turning Technologies MOBIVIEW Manuale utente

Manuali Lavagna bianca popolari di altre marche

Copernicus

Copernicus RC105 Manuale utente

IKEA

IKEA MALA 104.889.67 Manuale utente

SMART

SMART SBX800 Manuale utente

SMART

SMART Board MX V3 Series Manuale utente

funtronic

funtronic EasyBoard Manuale utente

Best-Rite

Best-Rite Baby Folding Wheasel 784-T Manuale utente

Best-Rite

Best-Rite Modular Room Divider Manuale utente

IKEA

IKEA MALA 504.565.92 Manuale utente

Panasonic

Panasonic TX-47P800HQ TX-47P800HZ Manuale utente

SMART

SMART ST442i Manuale utente

Quartet

Quartet QRT-72981 Manuale utente

SMART

SMART Smart Board 480 Manuale utente

EGAN

EGAN GlassWrite TableScreen TSG Manuale utente

Claridge

Claridge Edify Mobile Manuale utente

Legamaster

Legamaster e-Board Touch 2 Manuale utente

Nureva

Nureva WALL Manuale utente

Best-Rite

Best-Rite Black Splash Manuale utente

Da-Lite

Da-Lite Cosmopolitan Electrol Manuale utente
