Turtle Tough TT-CL2 Manuale utente

TURTLE

TOUGH



OPERATION MANUAL

TT-CL2 FREE CHLORINE SENSOR

Ion Specic Chlorine Analyser

turtletoughsensors.com

CONTENT

SAFETY PRECAUTIONS 3

THEORY OF OPERATION 3

SPECIFICATIONS 4

Residual Chlorine sensor probe 4

Flow cells 4

Electrochemical Probe Simulator 4

INSTALLATION 5

Site selecon 5

Unpacking 5

Mounng 6

Water connecons 6

OPERATION 6

Calibraon 6

SENSOR 7

Installaon 8

Setup 8

Maintenance 11

4.0.3.1 Roune maintenance 11

4.0.3.2 Diagnosc maintenance 11

Storage 11

Spares 11

Single owcell 11

4.0.6.1 Inseron 12

Double owcell 13

COMMISSIONING 13

TROUBLESHOOTING GUIDE 13

Further help 13

APPENDICES 14

General layout drawings 14

Cercates and approval statements 15

Returns Procedure and ‘Free of Contaminaon Sheet’ 16

Warranty 17

MSDS safety data sheets for Free Chlorine Electrolyte (ECS2.1/GEL) Electrolyte (ECS2.1/GEL 18

Calibraon informaon and sensor setup 21

T T-CL2

Free Chlorine Sensor

SAFETY PRECAUTIONS

• Before aempng to unpack, set up, or operate this instrument, please read this enre manual.

• Make certain the unit is disconnected from the power source before aempng to service or remove any

component.

Make certain the unit is disconnected from other sources of force or pressure (for example, pneumac or hydrau-

lic), before aempng to service or remove any component.

• Failure to follow these precauons could result in personal injury and damage to the equipment.

1. THEORY OF OPERATION

The free chlorine sensor has been designed to measure the concentraon of dissolved free residual chlorine.

It does this using a Potenastac 3-electrode chronoamperometric sensor insulated from the water supply

by a hydrophilic membrane. The free chlorine diuses through the membrane and is reduced at the cathode

generang a small current that is proporonal to the concentraon of free chlorine. In potable, process, or

swimming pool water this means HOCl (hypochlorous acid) and OCl- (hypochlorite ion). The relave amount of

these two species is dependent on the pH of the soluon. At low pH’s the predominant species will be HOCl.

At higher pH's the predominant species will be OCl-. Tradional amperometric measurement systems need to

be buered to an exact pH in order that changes in the pH of the sample water do not aect the Free Chlorine

measurement. The probe supplied for Free Chlorine measurement with this instrument is not aected by changes

in pH to the same degree. This means that on many plants it will not be necessary to buer the sample water at

all. If it is necessary to buer the sample water, because the pH is both high and variable it will only be necessary

to reduce the pH to below 6.5. This is best done using the CO2 Buer accessory. The probes are available for a

variety of ranges which are specied at the me of purchase.

The sensor incorporates automac temperature compensaon (ATC).

TURTLETOUGH

IPM19 HaloSense Free Chlorine Probe

Manual date 12/1/2011 Page 4of 29

1.0 Theory of Operation

The free chlorine sensor has been designed to measure the concentration of dissolved free residual

chlorine. It does this using a Potentiastatic 3-electrode chronoamperometric sensor insulated from the water

supply by a hydrophilic membrane. The free chlorine diffuses through the membrane and is reduced at the

cathode generating a small current that is proportional to the concentration of free chlorine. In potable,

process, or swimming pool water this means HOCl (hypochlorous acid) and OCl-(hypochlorite ion). The

relative amount of these two species is dependent on the pH of the solution. At low pH’s the predominant

species will be HOCl. At higher pH's the predominant species will be OCl-. Traditional amperometric

measurement systems need to be buffered to an exact pH in order that changes in the pH of the sample

water do not affect the Free Chlorine measurement. The probe supplied for Free Chlorine measurement

with this instrument is not affected by changes in pH to the same degree. This means that on many plants it

will not be necessary to buffer the sample water at all. If it is necessary to buffer the sample water, because

the pH is both high and variable it will only be necessary to reduce the pH to below 6.5. This is best done

using the CO2Buffer accessory. The probes are available for a variety of ranges which are specified at the

time of purchase.

The sensor incorporates automatic temperature compensation (ATC).

Typical Probe Response to pH

(Unbuffered)

100

120

6.5

7.5

8.5

9.5

Chlorine Probe Response

Typical Amperometric Probe Response

T T-CL2

Free Chlorine Sensor

1.1 SPECIFICATION

1.1.1 Sensor

Type Membrane covered amperometric potenostac three-electrode system

Measurand Free Residual Chlorine

Range 0-2, 0-5, 0-10mg/l (ppm)

Resoluon 0.01mg/l (ppm)

Reproducibility ±5 %

Stability -2 % per month (without calibraon)

Working electrode Cathode made of gold

Counter electrode Anode made of stainless steel

Reference electrode Silver / silver halide

Membrane material Micro-porous hydrophilic membrane

Flow rate 0.5 l/min (0.13 gallon/minute [US])

Temperature range >5 and <45°C

Temperature compensaon Automacally by an integrated thermistor (ATC)

pH-range pH 4 up to pH 9.5

Permissible overpressure 0.5 bar

First-polarisaon me 120 min

Re-polarisaon me 30 min

Response me T90: approx. 2 min

Zero-point adjustment Not necessary

Zero running Running at zero de-polarises the probe

Calibraon Manual using DPD or Automac (Autocal)

Housing material PVC, silicone, polycarbonate, stainless steel, perspex

Dimensions Diameter approx. 25mm (1”), length 175mm (7”)

Maintenance intervals

Calibraon On control applicaons it is a week to a month & on non-control it is 1 to 3 months.

Electrolyte Quarterly

Calibraon reagent Six monthly (Autocal unit only)

Membrane Yearly

Interferences High levels of other oxidants such as Ozone and Chlorine Dioxide

1.1.2 Flow cell

Inlet ¼” or 6mm barb ng, or 8mm pipe push-ng

Outlet ½” or 12mm barb ng

No. of probes Single and double ow cells available

Service isolaon Ball valve

Flow 0-1.4 l/min (preferred ow rate 0.5 l/min)

Inlet pressure 0.5 bar

Flow cell pressure Eecvely zero, cell open to atmosphere

Weight 1kg (single), 1.5kg (double)

Filter (if ed) 100um

Flow switch available as an opon to give a low ow alarm if sample ow is lost.

1.1.3 Electrochemical probe simulator

Supplied with your instrument, if ordered. It simulates a constant output from a sensor and allows for easier

troubleshoong.

TURTLETOUGH

T T-CL2

Free Chlorine Sensor

2.0 INSTALLATION

As with all instrumentaon the installaon and commissioning of this instrument is crucial to its safe and accurate

funcon. This instrument must be used only for its purpose as outlined in this manual and must be installed and

commissioned in accordance with this manual and by trained and qualied personnel.

2.1 Site Selecon

Please choose a suitable locaon for the installaon of the probe and the electronics. The choice of installaon

point on any site is a compromise and is best undertaken by experienced installaon personnel. The following is

a list of the factors that need to be taken into consideraon. This list is not intended as a checklist neither is it

implied that the list is complete.

• Ensure that the mounng allows access to all serviceable parts.

• Try to mount the electronics in a posion where they are not habitually hosed down in a cleaning process.

• Consider the length of wiring runs when mounng the instrument.

• Try to keep the electronics away from substaons or other large EMI emiers.

• Consider whether the sample will be representave and well mixed.

• Consider sample return points.

• In a plasc run, with a low conducvity sample consider earthing the sample.

2.2 Unpacking

Please have a copy of your order with you when you unpack your instrument. All orders are checked when they

leave the factory. Please double check that you have all the parts that were ordered as soon as you open the box.

This may include (but not necessarily);

 Probe

 Probe mounng overow cell.

 Electrolyte

 Membranes

 Abrasive paper (blue)

 Manual

 CO2 Buer kit - opon

 Acid buer unit - opon

If anything is missing, or damaged, please contact your sales outlet immediately. If the instrument needs to be

returned for any reason please follow the instrucons given in Appendix C of this manual.

TURTLETOUGH

T T-CL2

Free Chlorine Sensor

2.3 Mounng

For mounng of the ow cell (single or double), with its backplate (9mm thick), please refer to the drawings below.

2.4 Water connecons

The incoming water sample connecon is to the owcell lower barb or push ng.

In all cases the incoming water sample should be regulated to 0.5 l/min (0.13 gallon/minute [US]).

The ow cell is open to atmosphere, large changes in water pressure can cause water leaks.

If the pressure within the owcell exceeds 0.5 bar, there is a possibility of unstable readings.

The incoming ng is a ¼” or 6mm barb ng, or an 8mm pipe push-ng.

The outlet ng is a ½” or 12mm barb ng.

TURTLETOUGH

IPM19 HaloSense Free Chlorine Probe

Manual date 12/1/2011 Page 7of 29

2.3 Mounting

For mounting of the flow cell (single or double), with its backplate (9mm thick), please

refer to the drawings below.

2.4 Water connections

The incoming water sample connection is to the flowcell lower barb or push fitting.

In all cases the incoming water sample should be regulated to 0.5 l/min (0.13 gallon/minute [US]).

The flow cell is open to atmosphere, large changes in water pressure can cause water leaks. If the pressure

within the flowcell exceeds 0.5 bar, there is a possibility of unstable readings.

The incoming fitting is a ¼” or 6mm barb fitting, or an 8mm pipe push-fitting.

The outlet fitting is a ½” or 12mm barb fitting.

3.0 OPERATION

Refer to the instrument menu structure.

3.1 Calibraon

In order to perform a span of the sensor it is necessary to have an independent method of determining the level

of the measurand, e.g. a DPD test kit to measure free chlorine in the sample water. Refer to the appendix of this

manual for further calibraon informaon. Zeroing of this sensor is not required.

T T-CL2

Free Chlorine Sensor

4.0 SENSOR

WARNING!WARNING!WARNING!WARNING!

PLEASE READ THE INSTRUCTIONS BELOW BEFORE DOING ANYTHING WITH THIS

PROBE. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN DAMAGE TO

THE MEMBRANE CAP AND WARRANTIES FOR THIS DEVICE MAY BE VOIDED.

You will nd a membrane cap that is loosely screwed onto the end of your probe.

DO NOT REMOVE OR TIGHTEN THIS MEMBRANE CAP UNTIL YOU HAVE READ THESE INSTRUCTIONS!

There is an elasc seal around the membrane cap which is used to seal the vent hole on the membrane cap during

normal operaon. Prior to servicing the probe the elasc seal must be slid down to expose this vent hole. Do not

loosen the membrane cap without having the vent hole exposed and unobstructed. If the vent hole is blocked

o when the membrane cap is removed, then the membrane may rupture (i.e. develop a ny tear) and the probe

may not produce accurate readings.

When the membrane cap is lled with electrolyte and fastened onto the probe (in accordance with

instrucons in the operaons manual), you will noce some electrolyte bleed out from the vent hole. This is normal.

NOTE: DO NOT INSERT THE PROBE INTO THE FLOW CELL, OR GET IT WET, WITHOUT HAVING THE

VENT HOLE COVERED WITH THE ELASTIC SEAL!

The purpose of the vent hole is to protect the membrane from being exposed to internal pressure or vacuum

when the membrane cap is screwed onto or o of the probe p.

For further assistance please contact turtetough.com.au

TURTLETOUGH

IPBI08 – Probe Warning

Elasc Seal

This is the posion

the seal should be

in when the probe

is inserted into the

ow cell.

Vent Hole

This vent hole must

be exposed prior

to unscrewing the

membrane cap from

the probe p.

T T-CL2

Free Chlorine Sensor

TURTLETOUGH

The chlorine sensor is a membrane covered potenostac 3-electrode system. The measuring electrode is

membrane covered and is in the electrolyte area together with the reference electrode. This electrolyte area

contains a special electrolyte and is separated by a second membrane from the sample water.

In this measuring method chlorine diuses out of the sample water, through the membranes and causes an

electrical signal at the measuring electrode. The electrical signal at the measuring electrode is proporonal to the

chlorine concentraon and is amplied by the electronics in the sensor. The measuring signal is independent from

the temperature of the measuring water due to an integrated temperature compensator.

4.0.1 Installaon

• Please refer to Site Selecon, secon 2.1

• Ensure the probe housing is mounted vercally, to ensure correct water ow over the sensor

• Ensure the installaon is stable, secure and away from vibraon

• Ensure the sample is free from bubbles and is well mixed

4.0.2 Setup

CAUTION:

When you unscrew the lled (or unlled) membrane cap, ensure

the vent band has been removed from the vent hole, to allow

air to enter, otherwise the membrane will be destroyed by the

vacuum.

• Unscrew the membrane cap from the electrode sha.

• Place the membrane cap and the G-holder onto a clean and

non-absorpve bench.

CAUTION: Never polish this area of the probe.

T T-CL2

Free Chlorine Sensor

TURTLETOUGH

• Fill the membrane cap up to the edge with the enclosed electrolyte.

• Be careful, so that there are hardly any bubbles.

• Then replace it onto the bench.

NOTE: Read the electrolyte MSDS sheet.

• Fill up the G-holder with electrolyte.

• Be careful that there are no bubbles.

• Hold the electrode sha upright and push the electrode nger carefully

into the lled G-holder.

T T-CL2

Free Chlorine Sensor

TURTLETOUGH

• Hold the electrode sha (with the G-holder) upright and put it on the

lled membrane cap.

• Then screw the membrane cap onto the electrode sha.

• Turn it anclockwise unl the thread engages, then screw slowly the

electrode sha clockwise (by hand) onto the membrane cap.

• Excess electrolyte will escape through the vent hole in the membrane cap.

• Do not close this vent with your nger.

WARNING: Electrolyte may spurt from the vent hole.

Excess electrolyte, or electrolyte on your skin or in your eye,

should be washed o immediately with water.

The electrolyte contains potassium halide.

• Check that the membrane cap is completely screwed in up to the stop.

• There is initial resistance from the o-ring, continue past this to the

electrode body.

• Ensure the vent band is seated correctly.

• Wash o the excess electrolyte with water.

• Inial run-in is 1 hour prior to calibraon.

• Calibraon should be repeated aer 24 hours.

Roune calibraon should be weekly.

CAUTION: When you unscrew the lled

membrane cap, ensure the vent band has

been removed from the vent hole, to allow

air to enter, otherwise the membrane will be

destroyed by the vacuum.

Indice

Altri manuali Turtle Tough Accessori

Turtle Tough

Turtle Tough ULTRA Series Manuale utente

Manuali Accessori popolari di altre marche

Hillco

Hillco 2810 Manuale utente

Siemens

Siemens QSA2700D Manuale dell'operatore

Contours

Contours ZY024 Manuale utente

Saivod

Saivod VS621 Manuale utente

Virtuox

Virtuox VirtuCLEAN 2.0 Manuale utente

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuale utente

Z-Wave

Z-Wave HSD-200Z Manuale utente

turck

turck FMX-IM-2UPLI63FX Manuale utente

Decagon Devices

Decagon Devices 10HS Manuale utente

UPPAbaby

UPPAbaby Cup Holder Manuale utente

Elko

Elko SmartSensor Leakage Wireless Manuale utente

Grizzly

Grizzly H8371 Manuale utente

Panasonic

Panasonic HG-T Series Manuale utente

IFM Electronic

IFM Electronic Efector 250 Series Guida di riferimento

DigiDesign

DigiDesign 888/24 I/O Manuale utente

PROZIS

PROZIS QUAY Manuale utente

patagonia

patagonia PSI Vest Manuale utente

SFC Energy

SFC Energy EFOY GO! Manuale utente
