U-Line Echelon BI-2115 Manuale utente

eatures Beneﬁts

8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: 414-354-0300 • Fax: 414-354-7905

www.u-line.com

ICE MAKER

MODEL BI2115

Capacity: Daily ice production up to 25 lbs/25 lbs storage

Defrost Type: Manual Defrost

Colors: Stainless Steel, Black, White

Feature Benefit

No drain required • Easy and inexpensive to install

• Only requires a 1/4" outside diameter water line

Conserves on water Uses under 3 gallons of water to produce 22 lbs of ice

Optional 3/4" full overlay door

panel

• Provides a fully integrated appearance with surrounding

décor while maintaining zero door clearance

• Easy to install

• Black and white models only

• Must order kit number U-OL2115

Standard door will accept a 1/4"

panel

• Ability to match surrounding décor and cabinets

• Black and white models only

Built-in or freestanding • Provides custom look

• No additional clearance around sides, top or rear of unit

for ventilation. Do not obstruct front grille.

Stainless steel model • Offers a full wrap stainless door and cabinet, along with a

curved, sculpted stainless door handle and a stainless-like

grille

• Must order right- or left-hand hinged

Self-closing door • Engages when the door is open 8-10"

• Ensures a positive door seal and prevents door bounce-

back

Field-reversible doors • Flexible installation options

• Black and white models only

Integrated handle • Sleek designer look that does not add depth to the

cabinet when built-in

• Black and white models only

Vinyl-clad cabinet • Textured, rich look. More resistant to scratching, peeling

or flaking

• Cabinet extends to the floor

• Black and white models only

Leveling legs More precise undercounter fit - durable - factory-installed

Contemporary grille design Integrates seamlessly with surrounding cabinetry

Outdoor use The stainless steel model is deemed suitable by UL for

outdoor use.

imensions Speciﬁcations

8900 North 55th Street • Milwaukee, Wisconsin 53223

Phone: 414-354-0300 • Fax: 414-354-7905 • www.u-line.com

Ice Maker Model BI2115

Specifications Capacities

(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.

Optional in 220/230 voltage, 50/60 Hz.

On 220/230 volt models, amps are decreased by approximately 50 percent.

Stainless steel models must be ordered right- or left-hand hinged.

Stainless steel models: Allow 2-1/2" clearance on hinge side for 90° door opening when installed against a wall.

Please visit www.U-Line.com for Installation Guide.

All specifications subject to change without notice.

*WATER INLET VALVE

INCHES (CENTIMETERS)

26-1/8

(66.4)

23-25/32

(60.4)

21-7/16

(54.5)

23-25/32

(60.4)

21-7/16

(54.5)

3-3/8

(8.6)

34-1/8

(86.7)

FULL

RETRACT

HEIGHT

35-1/8

(89.2)

FULL

EXTEND

HEIGHT

14-15/16

(37.8)

BI2115 BI2115 (Stainless Steel)

*WATER

VALVE

*POWER

CORD

3-3/8

(8.6)

1-3/4

(4.4)

1-5/8

(4.1)

1-15/16

(4.9)

*ON BACK OF UNIT

Shipping Weight:

Black and White Models

Stainless Steel Models

98 lbs (44 kg)

111 lbs (50 kg)

(1) Running Amps 2.5

(1) Maximum Start-up Amps 18.0

Refrigerator volume N/A

Freezer volume N/A

Approximate daily ice production Up to 25 lbs

Ice storage 25 lbs
