A2B Metro Service Manual
TM
clean mobility technology
A2B Metro Service Manual
A2B Metro Service Manual
Ultra Motor USA
45 Broadway Street
San Francisco, CA 94111
Tel: (415) 693-3110
Fax: (415) 693-3121
www.ultramotor.com
Copyright © 2009 by Ultra Motor USA, Inc
First Edition
August, 2009
All rights reserved. No part of this publication may be repro-
duced or transmitted in any form or by any means without the
prior permission of Ultra Motor USA, Inc.
Although every precaution has been taken to assure this publi-
cation is complete and accurate, Ultra Motor USA assumes no
liability for errors or omissions. All information contained in this
publication is based on the latest information available at the
time of publication and is subject to change without notice.
TABLE OF CONTENTS
Chapter One: General Information 1-1
Terms
Lubricants
Threadlock
Special Tools
Specifications
Chapter Two: Steering and Front Suspension 2-1
Handlebar Replacement
Throttle
Handlebar Stem
Front Fender
Front Fork
Chapter Three: Brakes 3-1
Brake Lever
Brake Cable Inner Wire
Brake Caliper
Brake Pad Replacement
Brake Disc
Chapter Four: Shifter and Derailleur 4-1
Shifter
Shifter Cable Inner Wire
Derailleur
Chapter Five: Chain and Crankset 5-1
Chain
Crank Arm
Chainring
Pedal
Bottom-Bracket Cartridge
Chapter Six: Rear Suspension 6-1
Shock Absorber
Rear Wheel
Rear Fender
Swingarm
Chapter Seven: Electrical 7-1
Connector Identification
Battery Cap
Battery
Key Switch
Charger Port
Electrical Troubleshooting
Electrical Schematic
1-1
enough to penetrate tight places, they
should be durable so they can withstand
exposure to the elements, and they must
resist the accumulation of dirt.
Suitable oils include Alsop, Bullshot,
Campagnolo, Finish Line, Lube Wax, Phil
Wood Tenacous Oil, Pedros, Superlube,
and Triflow.
Motor oil, WD40, 3-in-1 Oil, sewing machine
oil, gun oil, and other common oils are not
suitable and should not be used.
In general, applying oil from a drip appli-
cator is superior to using aerosols. Aerosols
promote over-lubrication, which leads to
excessive accumulation of dirt. Apply oil
sparingly. Apply enough oil to do the job,
but not so much that it starts to drip from
the component. After applying any oil,
wipe off the excess.
THREADLOCK
A threadlocking compound should be
used on most fasteners on the A2B Metro.
Threadlocking compound prevents loos-
ening caused by vibration and helps seal
out moisture.
Loctite 242 (blue) or its equivalent is rec-
ommended for threadlocking applica-
tions. Loctite 242 is a medium-strength
threadlocking compound that permits dis-
assembly with common hand tools.
Before applying Loctite to threads, clean
oil, grease, and other residue from the
thread surfaces. Apply a small amount of
Loctite. Excess compound could work its
way down the threads and bond parts
together. Table 5 (this chapter) provides
torque specifications and Loctite recom-
mendations for particular fasteners.
TERMS
Left and Right
The terms left and right in this manual
refer to the rider’s point of view when
seated on the A2B Metro and facing for-
ward. The right side of the A2B Metro is the
chain side. The left side is the brake side.
NOTE, CAUTION and WARNING
The terms NOTE, CAUTION and WARNING
have specific meanings in this manual. A
NOTE provides additional information to
make a procedure easier or clearer.
A CAUTION emphasizes precautions that
must be taken to avoid damage to tools or
the A2B Metro. Disregarding a CAUTION
could lead to mechanical damage.
A WARNING emphasizes a situation where
negligence could lead to injury or death.
Take WARNINGS seriously. Failure to heed a
WARNING could result in serious personal
injury or death.
LUBRICANTS
Grease
In general, use a lithium-based grease
where grease is called for in this manual.
Always use grease made specifically for a
bicycle, such as grease from Bullshot,
Campagnolo, and Shimano.
Oil
Always use oils made specifically for
bicycle use. Bicycle oils need to be thin
Chapter One
GENERAL INFORMATION
Chapter One
1-2
SPECIAL TOOLS
The following special tools are needed when servicing the A2B Metro.
Tool Part number
Hex wrench set: 4mm, 5mm, 6mm Park AWS-1
Hex wrench set Park AWS-11C
Hex wrench set: 2mm, 5mm, 3mm Park AWS-3
Fourth-hand cable stretcher Park BT-2
Chain checker Park CC-2C
Chain breaker (screw type) Park CT-3
Crank wrench Park CCW-14R
Cable and housing cutter Park CN-4C
Gearclean brush Park GSC-1
32mm & 36mm head wrench Park HCW-15
Pedal wrench Park PW-3
Spoke wrench (black) Park SW-0
Spoke wrench (red) Park SW-2
Tire lever set Park TL-1C
Freewheel tool Part Tool FR-1
Bottom-bracket-cartridge tool Park Tool BBT-2
SPECIFICATIONS
Table 1: Mechanical Specifications
Component Specification
Headset VP-A50AC
Stack height 10.3 mm (0.41 in.)
Dimensions 1 1/8 x 44 x 30
Front fork Spinner
Type FK-001
Handlebar Kalloy AL-021
Rise 9°
Width 670 mm (26.38 in.)
Handlebar stem MJ Cycle ST-001
Seatpost Kalloy SP-600
Tires Kenda K1032 20 in. x 3.0 in.
Rims Alex DX 32
Rim runout (with or without tire)
Axial runout 1 mm (0.039 in.)
Radial runout 1 mm (0.039 in.)
Spokes
Front 14 gauge
Rear 13 gauge
Bottom bracket (B/B) Chin Haur CH-52
Freewheel Long Yi LY1107, 7-speed, 11/28t
Chainring Hsiang An HA-804G, 170 mm, 46T
Chain KMC Z50 ½ x 3/32 x 158L
1-3
GENERAL INFORMATION
Chapter One
1-4
Table 2: Gear Ratios
Chainring Freewheel Gear Inches Ratio
46 11 83.6 6.3
46 13 70.8 5.3
46 15 61.3 4.6
46 18 51.1 3.8
46 21 43.8 3.3
46 24 38.3 2.9
46 28 32.9 2.5
Table 3: Electrical Specifications
Component Specification
Battery 36-volt
Type Lithium ion
Capacity 11.4 amp-hrs (422 watt-hrs)
Charger High Power, HP8204C(10s)
Input 115/230 VAC, 60/50 Hz, 1.5/0.9 A
Output 42VDC/2A
Table 4: Performance Specifications*
Item Specification
Top speed 20 mph (per regulation)
Range (flat terrain, no wind) 20 miles
*180-pound rider with tires inflated to 60 psi.
