Ultrak HEB10 Manuale utente

HEB Serie

10- AND 12-INCH

CAMERA

ENCLOSURES

WITH OPTIONAL

SUNSHIELD,

HEATER AND

BLOWER KITS

AND MOUNTING

BRACKET

INSTALLATION

INSTRUCTIONS

Worldwide Support Center

1301 Waters Ridge Drive Lewisville, TX 75057

(800) 796-2288 (972) 353-6400 FAX (972) 353-6670

ISSUE 1 - November 1996

1996 BY ULTRAK

PRINTED IN KOREA

ULTRAK

1301 WATERS RIDGE DRIVE

LEWISVILLE, TX 75057

(800) 796-2288

BY ANY MEANS WITHOUT WRITTEN PERMISSION FROM ULTRAK.

THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL

RESPECTS. HOWEVER, ULTRAK CANNOT ASSUME RESPONSIBILITY FOR ANY

CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION

CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR

NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH

CHANGES.

iii

TABLE OF CONTENTS

Paragraph Title Page

SECTION 1. HEB CAMERA HOUSING SERIES INTRODUCTION

1.1 PURPOSE ....................................................................................1

1.2 FEATURES...................................................................................1

SECTION 2. HOUSING INSTALLATION INSTRUCTIONS

2.1 HEB10-BK BLOWER KIT INSTALLATION ..................................2

2.2 HEB10-HK/HEB12-HK HEATER KIT INSTALLATION.................4

2.3 HEB10-BK BLOWER KIT WITH HEB10-HK/HEB12-HK

HEATER KIT INSTALLATION ..................................................6

2.4 CAMERA MOUNTING FOR HEB SERIES HOUSINGS ..............8

2.5 HEB10-SS/HEB12-SS SUNSHIELD INSTALLATION................10

2.6 UL-WBM & UL-WB+BJ WALL BRACKET MOUNTING.............11

SECTION 3. SPECIFICATIONS

3.1 HEB HOUSING SPECIFICATIONS ...........................................12

3.2 HEB10-BK BLOWER SPECIFICATIONS ..................................13

3.3 HEB10-HK/HEB12-HK HEATER SPECIFICATIONS.................13

3.4 HEB10-SS/HEB12-SS SUNSHIELD SPECIFICATIONS ...........13

3.5 UL-WBM & UL-WB+BJ WALL MOUNT SPECIFICATIONS ......14

SECTION 1

HEB CAMERA HOUSING SERIES INTRODUCTION

1.1 PURPOSE

The HEB10 and HEB12 camera housing series are stylishly and

functionally designed enclosures for 1/3” and 1/2” cameras with

fixed focal length or standard zoom lenses. This manual

describes how to assemble the housing and its optional

components, affix the camera, and mount the assembly to a

suitable surface.

1.2 FEATURES

The HEB10 and HEB12 camera housing series feature:

•Contemporary design

•Die-cast and extruded aluminum construction

•Adjustable mounting track

•Hinged/removable body for easy servicing

•Compression cable fittings

•Optional heater kit, blower kit and snap-on sunshield

components

•Indoor/outdoor applications

•Epoxy powder coating for corrosion resistance

•Dustproof, IP65 weatherproofing

•Low Cost

•Preassembled models:

1. HEB10 & HEB12.................. housing

2. HEB10-01 & HEB12-01 .......housing with sunshield

3. HEB10-02 & HEB12-02 .......housing with sunshield

and heater kit

4. HEB10-03 & HEB12-03 .......housing with sunshield,

heater kit and blower kit

SECTION 2

HOUSING INSTALLATION INSTRUCTIONS

2.1 HEB10-BK BLOWER KIT INSTALLATION (without heater)

This section contains comprehensive instructions for installing

the blower kit into the HEB10, HEB10-01, HEB12 and HEB12-01

camera housing. The HEB10-BK is compatible in both the

HEB10 and HEB12 series. If you are also installing the heater,

please skip to page 5 for comprehensive instructions. The blower

kit is available in a preassembled package with a housing, heater

kit, and sunshield under model HEB10-03 or HEB12-03.

1. If applicable, slide the sunshield off the main housing unit.

2. Remove the two Phillips panhead screws located midway up

the rear of the housing. Retain the screws and their black

rubber gaskets, which were left in the holes on the rear of the

housing. (See Figure 1)

3. By sliding the housing shell away from the rear portion of the

unit, separate the housing into two sections. Be careful not to

disconnect the end of the ground cable that is attached to the

housing shell. (See Figure 1)

4. Locate the following parts that are taped to or enclosed in the

housing: two black plastic elevation plates, a nylon washer,

and three hexagonal screws of varying lengths for camera

mounting. Set these parts aside for later use.

5. Remove the standard silver camera mounting plate by

unscrewing the two flathead screws located at the rear.

Retain the screws. (See Figure 1)

FIGURE 1

6. Remove the rear of the housing from the base by unscrewing

the two Phillips panhead screws. (See Figure 1)

7. Use these screws to replace the rear with the blower unit,

being careful not to damage the wiring to the attached circuit

board. (See Figure 2)

8. Reattach the standard silver camera mounting plate to the

shelf extending from the rear of the housing. Align the holes

and secure using the two flathead screws mentioned in step

5. (See Figure 2)

9. Next, mount the blower circuit board on the camera mounting

plate. To do this, first place the two plastic spacers on the

two holes near the rear of the plate. Set the blower circuit

board on top of the spacers, aligning the holes and keeping

the wiring on the same side. Insert the small Phillips panhead

screws and secure the assembly. (See Figure 2)

10. Connect the

external power

supply (not

included) to the

circuit board. The

recommended

power supply is 24

Vac, 50 VA. (See

Figure 3)

11. To mount your camera, consult the section Camera

Mounting for HEB Series Housings on page 7. Begin with

step 5. Then see UL-WB+BJ & UL-WBM Wall Bracket

Mounting on page 10.

FIGURE 2

FIGURE 3

2.2 HEB10-HK/HEB12-HK HEATER KIT INSTALLATION

(without blower)

This section contains instructions for installing the heater kit for

the HEB10, HEB10-01, HEB12 and HEB12-01 camera housings.

If you are also installing the blower unit, please skip to page 5 for

comprehensive instructions.

While this heater kit is sold as an add-on component for the

HEB10, HEB10-01, HEB12 and HEB12-01, it is also available in

a preassembled package. The HEB10-02 and HEB12-02 are 10-

and 12-inch camera housings respectively with an installed

sunshield and heater. The HEB10-03 and HEB12-03 add a

blower kit to this package.

1. If applicable, remove the sunshield by sliding it off the main

housing unit.

2. Loosen the two Phillips panhead screws located midway up

the rear of the housing. Leave the screws intact in the rear

portion of the housing. (See Figure 4)

3. By sliding the housing shell away from the rear portion of the

unit, separate the housing into two sections. Be careful not to

disconnect the end of the ground cable that is attached to the

housing shell. (See Figure 4)

4. Locate the following parts that are taped to or enclosed in the

housing: two black plastic elevation plates, a nylon washer,

and three hexagonal screws of varying lengths for camera

mounting. Set these parts aside for later use.

FIGURE 4

5. Remove the standard silver mounting plate by unscrewing

the two flathead screws located at the rear. Then replace

this unit with the optional mounting plate with built-in heater.

Make sure that the heater plate is secured to the shelf that

extends from the rear of the housing unit. (See Figures 4 &

6. Connect the external

power supply (not

included) to the circuit

board. The

recommended power

supply is 24 Vac, 50 VA.

(See Figure 6)

7. To mount your camera,

consult the section

Camera Mounting for

HEB Series Housings on

page 8. Begin with step

5. Then see UL-WB+BJ

& UL-WBM Wall Bracket

Mounting on page 10.

FIGURE 5

FIGURE 6

2.3 HEB10-BK BLOWER KIT WITH HEB10-HK/HEB12-HK

HEATER KIT INSTALLATION

This section contains instructions for installing the heater kit and

blower kit for HEB10, HEB10-01, HEB12 and HEB12-01 camera

housings. While these kits are sold as add-on components, they

are also available in a preassembled package. The HEB10-03

and HEB12-03 are 10- and 12-inch camera housings respectively

with an installed sunshield, heater and blower.

1. If applicable, remove the sunshield by sliding it off of the

main housing unit.

2. Remove the two Phillips panhead screws located midway up

the rear of the housing. Retain the screws and their black

rubber gaskets, which were left in the holes on the rear of the

housing. (See Figure 7)

3. By sliding the housing shell away from the rear portion of the

unit, separate the housing into two sections. Be careful not to

disconnect the end of the ground cable that is attached to the

housing shell. (See Figure 7)

4. Locate the following parts that are taped to or enclosed in the

housing: two black plastic elevation plates, a nylon washer,

and three hexagonal screws of varying lengths for camera

mounting. Set these parts aside for later use.

5. Remove the standard silver camera mounting plate by

unscrewing the two flathead screws located at the rear.

Retain the screws. (See Figure 7)

6. Remove the rear of the housing from the base by unscrewing

the two Phillips panhead screws. (See Figure 7)

FIGURE 7

7. Use these screws to

replace the rear with

the blower unit,

being careful not to

damage the wiring

to the attached

circuit board. (See

Figure 8)

8. Attach the mounting plate with heater unit to the shelf

extending from the rear of the housing. Align the holes and

secure using the Phillips panhead screws mentioned in step

5. (See Figure 8)

9. Using a small screwdriver, disconnect the wiring to the N and

L1 ports on the heater circuit board. (See Figure 8)

10. Next, replace the heater circuit board with the circuit board

that is wired to the blower. To do this, locate the two Phillips

panhead screws on the heater circuit board. Unscrew them

and remove the board from the mounting plate. With the two

plastic spacers already over the small holes on the mounting

plate, set the blower circuit board on top of the spacers,

keeping the wiring on the same side. Align the holes in the

board with the spacers and insert the small Phillips panhead

screws. Secure the assembly. (See Figure 8)

11. Connect the heater

wiring harness to the

blower circuit board

as shown. Then

connect the external

power supply (not

included) to the

circuit board. The

recommended power

supply is 24 Vac, 50

VA. (See Figure 9)

12. To mount your camera, consult the next section, Camera

Mounting for HEB Series Housings on page 8. Begin with

step 5. Then see UL-WBM & UL-WB+BJWall Bracket

Mounting on page 10.

FIGURE 8

FIGURE 9

Questo manuale è adatto per i seguenti modelli

Indice

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Vicon

Vicon V662-D-1 Istruzioni operative

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente
