UMAX Technologies VisionBook N15R Pro Manuale utente

N15R Pro

EN·CZ·SK·PL·HU

USER MANUAL

ENGLISH

N15R Pro

| EN | 4 |

× OVERVIEW

1. webcamera

2. LCD screen

3. speakers

4. slot for M.2 SATA SSD 2280

6. caps lock indicator

7. num lock indicator

8. microphone

13 3

10. touchpad

11. charging indicator

12. charging port (12V 2A)

13. USB 3.0

14. miniHDMI video output

15. microSD card slot

16. USB 3.0

17. 3.5mm audio jack

(headphones+microphone)

567 98

| EN | 4 |

| EN | 5 |

× TURNING ON

Press and hold the for a couple of seconds to turn on

your computer. Charge your computer before ﬁrst use.

× CHARGING

To charge your computer, connect the provided charger (12V 2A)

to the charging port. Do not use other than the provided charger to

charge your computer.

You can see the charging status by looking at the charging

indicator.

Red light - charging in progress

No light - charging ﬁnished

× OTHER INDICATORS

Solid light - computer is turned on

Blinking light - computer is in sleep mode

Caps Lock indicator

Solid light - Caps Lock is turned on

Num Lock indicator

Solid light - numeric keyboard is enabled

| EN | 6 |

× GET STARTED WITH TIPS IN WINDOWS

Find surprising things you can do in Windows with the Tips app –

it’s included in Windows 10. To ﬁnd the app, choose Start > Tips on

your device. Then type Windows in the search box or select Browse

all tips to see tips on other things.

× KEYBOARD SHORTCUTS IN WINDOWS

Launches Start menu

Launches Action Center+

Shows Desktop

+Launches File Explorer

+Launches Settings

+Launches Connect panel

| EN | 6 |

| EN | 7 |

+Zooms out your screen if Magniﬁer is open

Shows context menu

+Launches the Magniﬁer and zooms in your screen

+Opens the context menu of the Start button

+Opens Ease of Access Center

+Launches Run

+Launches Project panel

+Launches Search

+Minimazes all applications

+Locks your computer

| EN | 8 |

× KEYBOARD SHORTCUTS WITH FN KEY

+Enables and disables the touchpad

+Puts the laptop into Sleep mode

+Turns and on the screen

+Turns the speaker on or

+Turns the speaker volume down

+Turns the speaker volume up

+Decreases display brightness

+Increases display brightness

+Turns Airplane mode

+Skip to previous track or rewind

+Play or pause

| EN | 8 |

| EN | 9 |

× NUMERIC KEYBOARD

+Skip to next track or fast forward

+Toggles the display mode

+Function Insert

Enables and disables numeric keyboard

num lk ON: key 1

num lk OFF: function End

num lk ON: key 2

num lk OFF: function Down Arrow

num lk ON: key 3

num lk OFF: function Page Down

num lk ON: key 4

num lk OFF: function Left Arrow

num lk ON: key 6

num lk OFF: function Right Arrow

num lk ON: key 7

num lk OFF: function Home

| EN | 10 |

× TOUCHPAD GESTURES IN WINDOWS 10

Slide Horizontally Slide Vertically

Slide Diagonally

Tap & Double Tap

Tap an app to select it.

Double tap an app to launch it.

Drag and Drop

Double tap an item then slide the same

To drop the item to its new location lift

your ﬁnger.

num lk ON: key 8

num lk OFF: function Up Arrow

num lk ON: key 9

num lk OFF: function Page Up

num lk ON: key .

num lk OFF: function Delete

| EN | 10 |
