Umbrella Mesh Network Umbra Legacy Manuale utente

To arm enre system—both interior and perimeter

• Close all windows and doors (the status screen will say “OF” - if any numbers are

shown, those sensors will need to be closed)

• Using App—Press the Padlock/Home Icon on your App and select “Away Arm” from

the menu

• Using Keyfob—Press the Locked Padlock on your keyfob

• Using Keypad—Press and hold the “AWAY” Padlock for 2 seconds

• On Umbra Legacy Panel—Press and hold the “AWAY” Padlock for 2 seconds

• The system will display “ON” and begin exit countdown

• Exit premises before the delay expires

To disarm system when you return

• When you enter through the door, the keypad will emit the entry delay tone

• Using App—Press the Padlock/Home icon on your App and select “Disarm” from the

• Using Proximity Card—Present your proximity tag to the reader area of the panel

• Using Keyfob—Press the Unlock Padlock on your keyfob

• Using Keypad—Enter your 4 –digit user code followed by the “DISARM” Unlock icon,

or present your user proximity tag within the entry delay. (If the keypad is baery on-

ly—press and hold the * key for 2 seconds to acvate proximity reader)

• If you make an error, press the “*” key and try again.

• The system will display “OF” when disarmed

To arm perimeter of building and sll move freely inside

• Close all windows and doors (the status screen will say “OF” - if any numbers are

shown, those sensors will need to be closed)

• Using App—Press the Padlock/Home Icon on your App and select “Home Arm” from

the menu

• Using Keyfob—Press the Home Icon on your keyfob

• Using Keypad—Press and hold the “HOME” Icon for 2 seconds

• On Umbra Legacy Panel—Press and hold the “HOME” icon for 2 seconds

Umbra Legacy

User Quick guide - Brought to you by Umbrella Mesh Network

Umbrella Mesh Network, LLC

510 W. Amador Ave., Las Cruces, NM 88005

(855) 602-5276 Ben@umbrellameshnetwork.com

Know your alarm:

Umbra Legacy Panel

Keypad (Hold * to acvate Prox)

Keyfob

Prox tag

(Disarm)

Power

Arm

Alarm

WiFi

App

Away Stay Enroll WiFi SOS

Arm Away

Disarm

Arm Stay

SOS

Arm Away

Disarm

Arm Stay

SOS

Arm Away

Arm Stay

& Disarm

Umbra Legacy

User Quick guide - Brought to you by Umbrella Mesh Network

Umbrella Mesh Network, LLC

510 W. Amador Ave., Las Cruces, NM 88005

(855) 602-5276 Ben@umbrellameshnetwork.com

Umbra Legacy

User Quick guide - Brought to you by Umbrella Mesh Network

Umbrella Mesh Network, LLC

510 W. Amador Ave., Las Cruces, NM 88005

(855) 602-5276 Ben@umbrellameshnetwork.com

Know your alarm: Zone List

Circle Applicable

Zone # Descripon Arm Home Arm Away Type

1Yes / No Yes / No Wireless

2Yes / No Yes / No Wireless

3Yes / No Yes / No Wireless

4Yes / No Yes / No Wireless

5Yes / No Yes / No Wireless

6Yes / No Yes / No Wireless

7Yes / No Yes / No Wireless

8Yes / No Yes / No Wireless

9Yes / No Yes / No Wireless

10 Yes / No Yes / No Wireless

11 Yes / No Yes / No Wireless

12 Yes / No Yes / No Wireless

13 Yes / No Yes / No Wireless

14 Yes / No Yes / No Wireless

15 Yes / No Yes / No Wireless

16 Yes / No Yes / No Wireless

17 Yes / No Yes / No Wireless

18 Yes / No Yes / No Wireless

19 Yes / No Yes / No Wireless

20 Yes / No Yes / No Wireless

21 Yes / No Yes / No Wireless

22 Yes / No Yes / No Wireless

23 Yes / No Yes / No Wireless

24 Yes / No Yes / No Wireless

25 Yes / No Yes / No Wireless

26 Yes / No Yes / No Wireless

27 Yes / No Yes / No Wireless

28 Yes / No Yes / No Wireless

29 Yes / No Yes / No Wired/Wireless

30 Yes / No Yes / No Wired/Wireless

31 Yes / No Yes / No Wired/Wireless

32 Yes / No Yes / No Wired/Wireless
