Uniden EXA2245 Manuale utente

EXA2245 2/8/2 7:11 PM Page i

www.uniden.com

EXA2245 2/8/2 7:11 PM Page ii

Contents

Welcome/Features

Quick Reference Guide 4

Controls and Functions 5

Getting Started

Read this First 7

Checking the Package Contents 8

Setting up the Phone 9

Mounting the Base Unit on a Wall 14

Basics

Making and Receiving Calls 16

Terminology 16

Adjusting the Handset Ringer and

Earpiece Volume 17

Redial 17

Tone Dialing Switch-over 17

Traveling Out-of-Range 18

Selecting a Different Channel 18

Page 18

Memory Dialing

Storing Phone Numbers in Memory 19

Making Calls with Memory Dialing 19

One-Touch RocketDial 20

Chain Dialing 20

Erasing a Stored Number from Memory 20

The Integrated Answering Device

The Integrated Answering Device 21

Features 21

Turning the Answering System On/Off 22

Setting Up Your Answering System 22

Using Your Answering System 30

Additional Information

Changing the Digital Security Code 36

Note on Power Sources 37

Maintenance 37

Troubleshooting 38

General Information 40

Precautions & Warranty 41

I.C. Notice 43

Index 44

Remote Operation Card & Memory Location Memo

EXA2245 2/8/2 7:11 PM Page 1

[ 2 ]

Welcome Congratulations on your purchase of the Uniden EXA2245 cordless telephone and

answering system. This phone is designed and engineered to exacting standards for

reliability, long life, and outstanding performance.

Note: Some illustrations in this manual may differ from the actual unit for

explanation purpose.

Features •2.4 GHz Extended Range Technology

•Integrated Telephone Answering Device (ITAD)

•Voice Prompted Guidance through ITAD Setup Menu

•10 Number Memory Dialing

• RocketDial

•24 Digit Redial

•Flash and Pause

•Pulse/Tone Dialing

•Page/Find Handset

•7 Hour Talk Time/14 Day Standby Time

•Handset Earpiece Volume and Ringer Control

•Hearing Aid Compatible

•20 Channel Autoscan

As an ENERGY STAR®Partner, Uniden has determined that this product or

product models meets the ENERGY STAR®guidelines for energy efficiency.

ENERGY STAR®is a U.S. registered mark.

EXA2245 2/8/2 7:11 PM Page 2

[ 3 ]

The EXA2245 features include AutoTalkTM and AutoStandbyTM. AutoTalk allows you to answer a call by

just removing the handset from the base so you don't have to waste time pushing buttons. AutoStandby

allows you to hang up by simply returning the handset to the base.

The UltraClear PlusTM true compander circuitry virtually eliminates background noise. This innovative

technology, together with 20 different channels, provides you with the best possible reception during

all your conversations.

To protect you against misbilled calls which might result from your phone being activated by other

equipment, the EXA2245 has Random CodeTM digital security which automatically selects one of over

262,000 digital security codes for the handset and base. Also, the AutoSecureTM feature electronically

locks your phone when the handset is in the base.

RocketDialTM is a one touch speed dial key that automatically dials your most important or frequently

called number. The number dialed, is a preset number stored by the user.

Be sure to visit our web site: www.uniden.com

Uniden®is a registered trademark of Uniden America Corporation.

AutoTalk, AutoStandby, UltraClear Plus, Random Code, AutoSecure, and RocketDial are trademarks of Uniden America Corporation.

EXA2245 2/8/2 7:11 PM Page 3

[ 4 ] QUICK REFERENCE GUIDE

QUICK REFERENCE GUIDE

Step 1 Charging the Battery

TO INSTALL THE HANDSET BATTERY

Step 2 Connecting Step 3

Setting Up the Answering System

CONNECT TO A PHONE LINE

When the handset battery pack is fully charged,

after 15-20 hours of charging, plug the telephone

cord into the base unit and then into a telephone

wall jack.

Your phone is set for tone dialing. If your local

network requires pulse dialing, please see

“Choosing the dial mode”on page 13.

1Remove the cover.

TURN THE ANSWERING SYSTEM ON

TO RECORD A PERSONAL GREETING

Press and hold greeting

until you hear “Record

greeting”and a

confirmation tone.

2Record your personal greeting. (Position

yourself as near to the base as possible and

speak clearly.)

3When finished press greeting again or

play/stop.

1Plug the AC adapter cord into the base unit

and then into a 120V AC outlet.

2Place the handset on the base.

2Connect the battery

pack connector with the

correct polarity.

3Replace the cover.

TO PLUG INTO AC POWER

Note: You must charge the battery continuously for

15 - 20 hours before using the phone.

Press ans on/off.

A pre-recorded greeting will

play and your system is ready

to accept calls.

set/ringer menu

ans on/off find hs volume

greeting memo

skip/ffrepeat/rew

delete play/

stop

status

set/ringer menu

ans on/off find hs volume

greeting memo

skip/ffrepeat/rew

delete play/

stop

status

EXA2245 2/8/2 7:11 PM Page 4

[ 5 ]CONTROLS AND FUNCTIONS

Controls and Functions

1. Handset antenna

2. Handset earpiece

3. Talk/batt low LED

4. Flash key

5. Talk key

6. */tone key

7. Redial/pause (p) key

8. Handset microphone and

ringer speaker

9. Memory ( ) key

10. RocketDial key

11. End key

12. Volume ( ) key

13. Channel key

14. Handset charging contacts

15. Handset battery compartment

EXA2245 2/8/2 7:12 PM Page 5

CONTROLS AND FUNCTIONS[ 6 ]

16 17

set/ringer menu

ans on/off find hs volume

greeting memo

skip/ffrepeat/rew

delete play/

stop

status

mic

16. Telephone line jack

17. DC IN 9V jack

18. Handset retainer clip

19. Delete key

20. Repeat/rewind (rew) key

21. Menu key

22. Set/ringer key

23. Answer (ans) on/off key

24. Find handset (hs) key

25. Base charging contacts

26. Base speaker

27. Status LED

28. Message counter display

29. Play/stop key

30. Skip/fast forward (ff) key

31. Greeting key

32. Memo key

33. Speaker volume keys

34. Microphone

35. Base antenna

EXA2245 2/8/2 7:12 PM Page 6

GETTING STARTED [ 7 ]

GETTING STARTED

About the digital security code

This cordless telephone uses a

digital security code to

prevent unauthorized access

to your base unit. This

security code prevents other

cordless handsets from making

calls through your base unit.

A random security code will be

assigned automatically

between your base unit and

handset when you charge the

battery pack for the first time.

If you want to change the

security code, see page 36.

Read this First

Step 1 (page 8)

Unpack the telephone and accessories.

Step 2 (page 9)

Next, choose the best location

to set up the base unit.

Step 3 (page 10 to 13)

Then, insert the battery pack into the

handset. Connect the base unit. You must

charge the battery pack for 15-20 hours

before plugging into a telephone line

and using the phone.

This cordless telephone must be set up before use. Follow these steps:

Step 4 (page 22 to 29)

Finally, set up your answering system.

EXA2245 2/8/2 7:12 PM Page 7

[ 8 ]

Checking the Package Contents

Uniden Parts Department at (800) 554-3988

Hours: M-F 7:00 a.m. to 5:00 p.m. CST. We can also be

reached on the web at www.uniden.com.

Make sure you have received the following items in the package. If any of these

items are missing or damaged, contact the Uniden Parts Department.

GETTING STARTED

•Base unit

•Handset

•AC adapter

•Rechargeable battery

•Telephone cord

•This Owner’s Manual

•Other Printed Material

EXA2245 2/8/2 7:12 PM Page 8
