OPERATOR MANUAL
FIRST EDITION
10/2022
RT12 Rotary Trimmer
To avoid damaging the trimmer, never immerse it in water or other liquids.
Do not use abrasive cleaners on the trimmer.
Dust the trimmer with a soft cloth, using extreme caution when cleaning near the
blade.
Care and Maintenance
1. Push in on the red tabs towards each
other on each end of the guide rail.
Remove the red tabs. (You may need a
athead screwdriver for this step)
2. Carefully remove the cutter set by lifting
the guide rail and sliding off the cutting
blade head.
3. Carefully slide the new cutting blade
head onto the guide rail. Lower the
cutter set back onto the base. Be sure
to set the blade on the outside of the
cutting shield.
4. Push the red mounting tabs back into
place to secure the guide rail.
Replacing the Cutting Blade Head
TM
Safety Precautions
Before using the trimmer, please read and follow these instructions, and keep them
handy for future reference.
1. Read all instructions before operating.
2. This product is not intended for use by children. Keep product out of reach of
children and pets.
3. This trimmer is designed to cut only paper. Do not use it to cut other objects.
4. Keep hands and loose items, i.e. jewelry, clothing, neckties, etc. away from the
blade to avoid personal injury and/or damage to the trimmer.
5. Do not attempt to dislodge jammed debris with a pointed object, as personal
injury or damage to the trimmer may occur.
6. Always use the trimmer on a at, level, sturdy surface.
7. Do not hang or wall-mount the trimmer.
8. This product is intended for indoor use only.
To avoid damage to the trimmer:
Remove paper clips and staples from items before trimming.
Never lubricate the cutting blade.
Do not expose the trimmer to water or other liquids.
To avoid personal injury:
Never use the trimmer without the clamp bar or blade guard in place.
Never carry the trimmer by the cutter guide rail or cutting head
Parts Identification
Cutting Head
Measuring Grid
Clamping bar
Paper guide
Cutter Guide Rail
1. Insert paper under the clamping bar.
2. Adjust the paper to the proper position
for cutting.
3. Slide the rotary blade head forward or
backward to cut through the paper. The
blade cuts in both directions.
Note: Do Not push down on the rotary
blade head.
Operation
Specifications
Paper Length Up to 12.5” (318mm)
Paper Stack Height Up to 5/128” (1mm)
Sheet Capacity Up to 10 sheets 20# (75gsm)
Blade Type Rotary
Back Gauge Scale Inch/mm
Paper Clamp Yes/Auto
Table Size 12.8” W x 8.25” D (325 x 210mm)
Dimensions 17.25” W x 9.5” D x 2.625” H (438 x 241 x 67mm)
Weight 2.8 lbs (1.27kg)
Base Steel
United RT12
