Broadband modem
laptop w/ Windows
VPN client
USR8200
USR8800 Hard Drive
Broadband modem
HQ
TE LE WO RKER
BRANCH OFFICE
USR8200
10/100 Mbps connections
FireWire or USB 2.0 connection
Secure VPN connections
USB Printer
IC Approved
Approuvé par IC
usr8200
specifications & standards
usr8200 firewall/vpn/nas
Fir ewa l l Spe cif ic ations
• Stateful Packet Inspection (SPI) firewall
• Application Level Gateways (ALGs)
• DMZ host support
• Web filtering powered by SurfControl
• Secure access control
• Supports 253 users with no additional
licenses
• Transparent mode support
• DoS, DDoS protection
• Custom web blocking
V PN Speci fic ations
• VPN Server – PPTP and IPSec
• VPN Client – PPTP and IPSec
• Supports 253 IPSec VPN sessions
• 3DES/DES encryption methods
• VPN Client pass through support
IP Su pp or t
• IP (RFC 791)
• TCP client and server (RFC 793)
• UDP client and server (RFC 768)
• ICMP (RFC 792)
• ARP (RFC 826)
• RARP (RFC 903)
• Default IP address for LAN interface
G en er a l
• Linux operating system
• Intel® IXP422 network processor
• Built-in file server support for external
storage devices
• Integrated FTP server capability
• Integrated USB print server†
• IEEE 802.3 10BASE-T Ethernet
• Supports Universal Plug and Play
(Windows Me, XP, Server 2003)
• IEEE 802.u 100BASE-TX Fast Ethernet
repeater
• IEEE 802.3x.1 Flow Control
• DHCP server (LAN) and client (WAN)
• Network Address Translation
• Static and Dynamic IP addressing
• PPP over Ethernet (PPPoE) support
• Remote access configuration
Por t Con figu r at ion
• One RJ-45 10/100 Mbps auto-sensing
and auto-switching Ethernet WAN port
• Four RJ-45 10/100 Mbps auto-sensing
and auto-switching Ethernet LAN ports
• Two USB 2.0 ports (powered)
• One IEEE 1394 (FireWire) port (pow-
ered)
Memory C a pacit y
• 16 MB Flash
• 64 MB RAM
Oper ating System C ompat ibilit y
• Any OS (Windows, Linux, etc.) with
Ethernet and TCP/IP supported
Mi n i m u m Sys t e m R equir e m e n ts
• Any computer with RJ-45 10/100 Mbps
Ethernet LAN connection
• HTML configuration is supported by
any computer that supports TCP/IP or
HTML browser
• 100BASE-TX mode supports Category 5
STP or UTP Ethernet cable
• 10BASE-T mode supports Category 3, 4
and 5 STP or UTP Ethernet cable
• Windows 95/98/Me/NT 3.5.1/NT
4.0/2000/XP/Server 2003, Macintosh
System 7 and later, Linux (any version),
Sun Solaris, HP/UX or IBM OS/2 oper-
ating system
R egul ator y /Age nc y A pprova l s
• FCC approved (Part 15 Class B)
• IC approved (ICES-003)
• CE approved
• UL/CUL listed
Pac k ag e Con t e n ts
• USR8200 Firewall/VPN/NAS
• One Ethernet cable
• Power adapter
• Quick Installation Guide
• Documentation CD-ROM
Produc t Di m e nsions / We ight
Dimensions
• Length 5.5 in. (13.97 cm)
• Width 9.2 in. (23.36 cm)
• Height 6.75 in. (17.14 cm)
Weight
• 1.08 lb (0.49 kg)
Wa r r a n t y
• Two-year limited manufacturer warranty
from date of purchase. For details, see
www.usr.com
Mode l Nu m be r
8200
www.usr.com
† Print Server functionality works with any USB printer that supports a print
layout language (i.e. PostScript, PCL, etc.)
Copyright© 2005 U.S. Robotics Corporation. All rights reserved. U.S.
Robotics and the U.S. Robotics logo are registered trademarks of U.S.
Robotics Corporation. Other product names are for identification purposes
only and may be trademarks of their respective companies. Product specifi-
cations subject to change without notice. 03-25-05
