Parent’s Guide

91-003512-001 US

INTRODUCTION

Thank you for purchasing the Kidi Secrets Sele JournalTM. Protect

your thoughts and dreams without the worry of prying eyes with this

interactive journal that unlocks only when it recognizes your face. Make

a photo journal, write diary entries or record messages and keep them

safe. You can also take seles, photos and videos, listen to songs, play

games, care for a pet, edit photos and videos, and more. Connect to

a PC or use a microSD card to transfer les such as songs or photos.

6 Category Buttons

Swap Button

(Camera/Video

Button)

Microphone

Reset Button

Rear Camera

Battery Compartment (Open)

microSD Card

Slot

Previous /

Rewind Button

Play / Pause

Button

Volume Buttons

Next / Fast

Forward Button

Star Button

(Toggle Button)

Red Dot Button

(Shutter Button)

Clock Button

Unlock Button

OK Button

Help

Button

Speaker

Function

Button

4 Arrow

Buttons

Symbol

Button

Emoticon

Button

Save

Button

QWERTY

Keyboard

Shift

Button

Backspace

Button

Audio JackUSB PortFront CameraEscape Button

30-042767 底壳 30-042767 底壳

30-042767 底壳

39-00069539-000694

硅胶

USB Earbuds

30-042768 电池门

#1636 Engraving 凹光面

30-042767 底壳 30-042767 底壳

30-042767 底壳

39-00069539-000694

硅胶

USB Earbuds

30-042768 电池门

#1636 Engraving 凹光面

PRODUCT SPECIFICATIONS

Display 2.4” TFT color LCD

Photo Resolution 320 x 240

Video Resolution 320 x 240 pixel

Video Length Limit per

File

30 minutes when using a microSD card.

The video length limit is 1.5 minutes per

le when using Video Editor.

Focus Range 1.5 feet - ∞

Internal Memory 128MB built-in memory (Shared with

program data; actual memory available

for user storage will be less)

File Format Photos: Standard Baseline JPEG

Videos: AVI (Motion JPEG)

Songs and Voice Memos: MP3

Memory Card Format

and Capacity

microSD / microSDHC card (not included)

with capacity from 1GB-32GB are

recommended

Connectivity USB 2.0 cable (not included) for computer

connection

Batteries 4 AA (AM-3/LR6) alkaline batteries

Operating Temperature 32-104°F (0-40°C)

STORAGE CAPACITY FOR REFERENCE

Memory size Photos in

320 x 240

Video in 320 x

240 (minutes)

MP3 in 128kbps

(minutes)

Internal Memory 1,200 3 60

Memory

card

2 GB 31,250 62.5 2,000

4 GB 62,500 125 4,000

8 GB 125,000 250 8,000

16 GB 250,000 500 16,000

32 GB 500,000 1,000 32,000

NOTE: The photo and video quantities shown above are an estimate

based on average le size. Actual quantities may vary.

The video length limit is 1.5 minutes per le when using Video Editor.

INCLUDED IN THIS PACKAGE

• One VTech® Kidi Secrets Sele JournalTM

• One parent’s guide

• One quick start guide

WARNING: All packing materials such as tape, plastic sheets,

packaging locks, removable tags, cable ties and

packaging screws are not part of this toy, and

should be discarded for your child’s safety.

NOTE: Please keep this parent's guide as it contains

important information.

ATTENTION : Pour la sécurité de votre enfant, débarrassez-vous

de tous les produits d’emballage tels que rubans

adhésifs, feuilles de plastique, attaches, étiquettes

et vis d’emballage. Ils ne font pas partie du jouet.

NOTE : Il est conseillé de conserver ce guide des parents

car il comporte des informations importantes.

Turn the packaging lock

counterclockwise several times.

Pull out and discard the packaging lock.

Unlock the packaging locks:

GETTING STARTED

BATTERY INSTALLATION

The Kidi Secrets Sele JournalTM

uses 4 AA (AM-3/LR6) size batteries.

• Make sure the diary is turned OFF.

• Locate the battery cover on the

back of the diary.

• Slide open and remove the battery cover.

• Install 4 new AA (AM-3/LR6)

batteries as illustrated. (The

use of new, alkaline batteries

is recommended for maximum

performance.)

• Replace the battery cover.

30-042767 底壳 30-042767 底壳

30-042767 底壳

39-00069539-000694

硅胶

USB Earbuds

30-042768 电池门

#1636 Engraving 凹光面

30-042767 底壳 30-042767 底壳

30-042767 底壳

39-00069539-000694

硅胶

USB Earbuds

30-042768 电池门

#1636 Engraving 凹光面

LEAVING TRY ME MODE

For security reasons, when you rst use the diary, it is set to a sample

Try Me mode. You will need to activate normal play mode to be able to

save photos and diary entries.

1) Open the battery cover. Then, nd the Reset Button located next to

the word RESET.

2) Press the Unlock Button to turn on the diary.

3) Press the Reset Button after the VTech logo screen.

4) The screen will display the message, "Normal Mode." The cover will

then open and you can begin using the diary.

5) Once the cover is closed and the Unlock Button has been pressed,

you will be asked to setup the facial recognition function.

Top 5 Actions on the Kidi Secrets

Selfie Journal™

1) Creating a Diary Entry

Step 1: With the diary open, press the Diary

Button

Step 2: Use the Arrow Buttons to navigate

to the correct date for your entry and press the OK

Button .

Step 3: Use the Arrow Buttons and the OK Button to select a Mood,

Weather, and Special Icon.

Step 4: Type your diary entry. Use the Function Button to add voice

memos or photos or to change the diary's background.

Step 5: Press the Save Button to save your diary entry.

2) Take Photos and Videos

Step 1: Press the Swap Button to switch into

camera mode. Press the button again to switch to

video, if necessary.

Step 2: Use the Star Button to change

between front and rear cameras and among

shooting options.

Step 3: Press the Red Dot Button to take a photo or video.

3) Play Music

Step 1: Press any of the music controls

to bring up the Music Player.

Step 2: Use the Arrow Buttons and the OK

Button to select a song.

Step 3: Use the Star Button to change play options (shufe, repeat,

replay playlist, default).

4) Play a Game with Your Pet

Step 1: Press the My Pet Friend Button to

switch into Pet Mode. If you have already selected

a pet, that pet will appear. If you have not selected

a pet, choose among the pet options and give your

pet a name.

Step 2: Show the pet your face using the camera so it knows

you're playing.

Step 3: Press the Function Button to bring up options to play with

your pet.

Step 4: Select the Pet Care option, then select the Game Time option to

bring up this pet's game.

Step 5: If you want to play a different pet's game, you will need to select

the Pet Reset option and choose the other pet as your pet.

5) Edit Photos and Videos

Step 1: Press the Photo Fun Button to

switch modes.

Step 2: For photos, you may edit an existing photo

or take a new photo to edit. Select Photo Editor

and follow the instructions.

Step 3: For videos, you may only add lters to new videos. Select Video

Editor and select an effect to add to a video.

Step 4: Once you have selected an effect, press the Red Dot Button

to begin recording.

BATTERY NOTICE

• Use new alkaline batteries for maximum performance.

• Use only batteries of the same or equivalent type as recommended.

• Do not mix different types of batteries: alkaline, standard (carbon-

zinc) or rechargeable, or new and used batteries.

• Do not use damaged batteries.

• Insert batteries with the correct polarity.

• Do not short-circuit the battery terminals.

• Remove exhausted batteries from the toy.

• Remove batteries during long periods of non-use.

• Do not dispose of batteries in re.

• Do not charge non-rechargeable batteries.

• Remove rechargeable batteries from the toy before charging (if

removable).

• Rechargeable batteries are only to be charged under adult supervision.

MEMORY CARD INSTALLATION

• The diary is compatible with microSD/microSDHC memory cards up

to 32 GB.

• Make sure the diary is turned OFF.

• Locate the memory card slot inside

the battery compartment.

• Insert the memory card (not

included).

• Once the memory card is detected,

it will be used as the default memory source of the diary.

• Push the card once to eject.

PRODUCT LAYOUT AND BUTTONS

1. Unlock Button

Press this button to unlock the diary using the Face Unlock function.

Look into the screen and follow the instructions. Keep about 12 inches

between your face and the camera to ensure your face is fully shown in

the circle. You can now set up Face Unlock and use facial recognition to

unlock the diary. You can turn the Face Unlock function off by entering

My Tools and selecting the Face Unlock option and setting this to OFF.

With the Face Unlock function turned ON, you will need to show your

face to unlock the diary. With it turned OFF and Numeric Password

turned ON, pressing the Unlock Button will open the cover so you can

enter your Numeric Password to access the diary. With Face Unlock

and Numeric Password turned OFF, pressing the Unlock Button

will open the cover and turn on the diary without any security code or

recognition.

Note: To turn the diary off, close the cover or press the Unlock Button

during the password entry or facial recognition process.

2. Reset Button

For security reasons, when you rst use the

diary, it is set to a sample Try Me mode. You will

need to activate normal play mode to activate full

functionality. Press the Unlock Button and then

press the Reset Button (located in the battery

compartment) until the screen reads, "Normal

Mode." You can also press this button to reset

both the facial recognition and numeric password. First, press the

Unlock Button and then press the Reset Button. The message, “Face

unlock and number password cleared," will be displayed on the screen.

The diary will then turn on. The next time you turn the diary on, you will

be asked to set the facial recognition and numeric password again.

NOTE: A small tool, such as a paperclip, may be required to press the

Reset Button.

3. Red Dot Button (Shutter Button)

Press to enter Camera Mode. Press it again to take a photo or a video.

You can view photos and videos you have taken in the Gallery.

4. Swap Button (Camera/Video Button)

Press to swap between Photo and Video Mode.

5. 3 Music Buttons

Press any of these buttons to enter Music Mode.

Play Button: Press to play or pause the selected song.

Next / Fast Forward Button: Press to advance to the next song. Hold

this button to fast forward the song.

Previous / Rewind Button: Press to go back to the previous song. Hold

this button to rewind the song.

6. Star Button (Toggle Button)

Press to select different functions in Camera, Video and Music Modes.

Once a function is chosen, release the Star Button and wait for

1 second. The diary will then enter the selected function.

Mode Function

Camera • Rear-facing camera

• Front-facing camera

• 5-second countdown with rear-facing camera

• 5-second countdown with front-facing camera

• Take 5 photos continuously with rear-facing camera

• Take 5 photos continuously with front-facing camera

Video • Rear-facing camera

• Front-facing camera

Music

Player

• Shuffle: Play the songs in the playlist randomly

• Replay: Play the entire playlist again

• Repeat: Repeat the song

• Default Mode: Play songs from the selected song to the

end of the playlist

7. Clock Button

Press to display the current date, time and day of the week. It will be

displayed for several seconds before turning off.

8. Category Buttons

Press one of the six Category Buttons to choose how you want to play:

My Diary, My Pet Friend, My Stylist, Photo Fun, My Games, My

Tools.

My Diary Photo Fun

My Pet Friend My Games

My Stylist My Tools

9. QWERTY Keyboard

Use the keyboard to enter text into your diary entries and in My Address

Book. Also use it to type in games.

10. Arrow Buttons

Press to make selections on the screen or to move in

related activities.

11. OK Button

Press to conrm your selection.

12. Backspace Button

Press to delete what you’ve typed.

13. Shift Button

Works with letter or number keys to input a capital letter or a symbol.

As with a standard keyboard, you will need to hold shift down to type

capital letters.

14. Escape Button

Press to go back to the previous screen.

15. Function Button

Displays a pop up bar with activity-specic functions (when available).

16. Help Button

Repeats the current question or instruction or gets help.

17. Emoticon Button

Adds icons in your diary entries and in My Address Book.

Indice

Altri manuali V-tech Giocattolo

V-tech

V-tech First Responder Smart Rescue Set Manuale utente

V-tech

V-tech Kidizoom Lightning McQueen Digital Camera Manuale utente

V-tech

V-tech MobiGo Game Storage Manuale utente

V-tech

V-tech InnoTab Software - Mickey Mouse Clubhouse Manuale utente

V-tech

V-tech Musical Rhymes Book Manuale utente

V-tech

V-tech Baby Amaze Crawlin' Cutie Doll Manuale utente

V-tech

V-tech Animal Adventures Ark Istruzioni di montaggio

V-tech

V-tech Learn & Discover Driver Manuale utente

V-tech

V-tech Toot-Toot Drivers RemoteControl Racer Manuale utente

V-tech

V-tech Pop-A-Ball Pop & Play Tower Istruzioni di montaggio

V-tech

V-tech Myla the Blush and Bloom Unicorn Istruzioni di montaggio

V-tech

V-tech Toot-Toot Friends Prince Henry Manuale utente

V-tech

V-tech V.Smile Motion: Thomas & Friends Manuale utente

V-tech

V-tech Go! Go! Smart Wheels 3-in-1 Launch & Go... Istruzioni di montaggio

V-tech

V-tech V.Smile Motion - Shrek 4 Manuale utente

V-tech

V-tech Spinning Tunes Music Player Manuale utente

V-tech

V-tech V.Smile Motion: Kung Fu Panda Manuale utente

V-tech

V-tech Launch & Chase Police Tower Manuale utente

V-tech

V-tech 2-in-1 Toddle & Talk Turtle Manuale utente

V-tech

V-tech V.Smile Motion-Ni Hao Kai Lan-Happy Chinese New... Manuale utente

V-tech

V-tech Move & Zoom Racer Manuale utente

V-tech

V-tech Touch Tablet Advanced Manuale utente

V-tech

V-tech Go! Go! Smart Friends Enchanted Princess... Manuale utente

V-tech

V-tech Glowing Lullabies Elephant Istruzioni di montaggio

Manuali Giocattolo popolari di altre marche

marklin

marklin 37321 Manuale utente

Canon

Canon PAPER CRAFT Manuale utente

GREAT PLANES

GREAT PLANES Pitts M-12S Manuale utente

NOCH

NOCH 14261 Manuale utente

Hausler

Hausler 450 SE V2 Manuale utente

Dynaflite

Dynaflite Daydream Manuale utente

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manuale

Kenner

Kenner Batman 63651 Manuale utente

LEGO

LEGO 8527 Manuale utente

iKarus

iKarus ECO 8 Manuale utente

Multiplex

Multiplex EasyStar II Manuale di istruzioni

Walkera

Walkera 38 Manuale di istruzioni

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manuale utente

MD MXION SWD Manuale utente

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manuale utente

marklin

marklin 39671 Manuale utente

Meccano

Meccano 15103 Manuale utente

LEGO

LEGO TECHNIC 8735 Manuale utente
