Valeo CUCLEE VIEW PLUS Manuale utente

VALEO CYCLEETM SYSTEM

VIEW PLUS

DISPLAY

USER

MANUAL

INDEX

English

Français

Deutsch

Nederlands

Español

Italiano

114

Please click on the language you’d like to jump to

SAFETY INSTRUCTIONS

Read all the safety and general instructions.

Failure to observe the safety instructions may result in

serious injury and/or re and/or electric shock.

Make sure to not be distracted by the display while riding to avoid

accidents. If you want to manipulate your display other than switching

the assistance level, stop riding to do so.

Save all safety warnings and instructions for future reference.

The term display is used in these instructions to describe the on-board

computer of your Valeo Cyclee™ system.

Do not use the on-board computer as a handle. Lifting the e-bike

up by the display can cause irreparable damage to the on-board

computer.

INTRODUCTION

We thank you for choosing an e-bike equipped with the Valeo Cyclee™

system.

This revolutionary system will allow you to tackle every journey with

your e-bike, whether it's a city commute, a mountain ride or a cruise

on the week-end.

It is the user's responsibility to read and comply with this manual to

ensure the proper use and function of the Valeo Cyclee™ system.

Note: The content of this user manual is subject to change without

notice. To make sure you have the nal version, visit our website

regularly at www.valeocyclee.com

Due to customization by the e-bike manufacturer the

specications of this manual may not reect all specications of

your e-bike. Please refer to your bike manufacturer if necessary.

Valeo cannot under any circumstances be held accountable for

any direct or indirect damage of any nature whatsoever, nor for

losses or costs resulting from improper use.

4 5

Remote:

1. Upshift for gearbox

2. Downshift for gearbox

3. Gearbox mode selection (Auto - Manual)

Long press: Reverse (Optional on dened

bikes)

4. Throttle (Boost & Walk assist)

Main screen elements:

1. Current speed

2. Distance

3. Gear engaged

4. Walk assist

5. Assistance mode

6. Unit selected (KM/H or MPH)

7. Battery state of charge indicator

8. Light status

9. Maintenance mode

10. Lock mode

11. Bluetooth status

TECHNICAL DATA

Model View Plus

SKU display 654200

SKU display mount 654201

Protection rating IP65

Screen size 40 x 40 mm

PRODUCT SPECIFICATIONS

Intended use

The View Plus display is designed to control and give information

about the Valeo Cyclee™ system. New functions, changes in software

may be introduced during the product life.

For some bikes the software specications may be different than

stated in this manual (default specications), please refer to your bike

manufacturer if needed.

PRODUCT FEATURES

The numbering of the components shown refers to the illustrations

associated.

Display:

1. ON/OFF (long press: anti-theft

function)

2. Lights (long press: mileage

navigation)

3. Assistance level selection

4. Display holder

5. USB-C port (for phone

recharge 5V & 2A max. and

diagnostic tool connexion)

Note: the display is equipped with a luminosity sensor. When the

surroundings light drops, the screen backlight will be activated

automatically.

6 7

possibility to crank.

When lock mode is activated the display screen is only showing the

lock icon. To activate the bike you need to enter the pin code previously

selected on the Valeo Cyclee™ Mobile app or unlock directly through

the app.

To read more about the lock mode please refer to the Valeo

Cyclee™ mobile app user manual.

ASSISTANCE LEVEL

The drive is activated as soon as you step on the pedals (except in

assistance level “Off”). The motor output depends on the assistance

level selected.

As soon as you stop pedaling when in normal operation, or as soon as

you have reached the speed limit of your e-bike, the assistance from

the e-bike motor is switched off.

The motor is automatically reactivated as soon as you start pedaling

again and the speed is below the speed limit of your e-bike.

OPERATING INSTRUCTIONS

The power of the View Plus display is supplied by the Valeo e-bike

system battery.

Please read the battery, charger and the Valeo Cyclee™

mobile app user manual before using the View Plus display.

Switching the system On

To switch the e-bike system On you may briey press the On/Off button

on the display. If your Valeo Cyclee™ System is in lock mode you may

need to enter a pin code or unlock the e-bike via the Valeo Cyclee™

mobile app. Please refer to the lock mode section below.

You can also turn the e-bike system On by pressing the On/Off button

of the battery.

Switching the system Off

To switch Off the e-bike system press the On/Off button, the display

and the whole system is switched off.

A short press on the On/Off button will simply turn the system Off,

when a long press will turn the system Off and put it in lock mode.

If no energy is drawn from the e-bike system for some time and the

e-bike is not moving the system will shut off on its own.

Always switch the system/battery Off before removing or

installing the battery onto the e-bike.

Lock mode

The lock mode is the anti-theft function of your Valeo Cyclee™ system.

Before using the lock mode for the rst time you need to enable

this function in your Valeo Cyclee™ mobile app.

When in lock mode the electrical assistance is automatically shut-off

and the integrated gearbox switches in neutral position without any

8 9

The assistance modes follow this sequence:

Note: in assistance mode “Predict” the assistance is set by the

system according to the rider cadence and power output. In this

mode the gearbox is always set to automatic by the smart e-bike

system. Manual shifting is not possible in Predict mode.

Assistance level Description

Off Assistance deactivated

Eco Battery saver mode

Predict Smart adaptive mode

Turbo Maximum assistance mode

Assistance modes

You can select the level of assistance you need from the e-bike

motor by selecting the correct assistance mode on the display. The

assistance level can be changed at any time, even while riding.

The following assistance levels are available on your Valeo e-bike

system:

To select the desired assistance level press the assistance level button

on the display.

Assistance level button

OFF

No assistance from motor.

ECO

Low assistance to save battery.

TURBO

Maximum assistance level.

PREDICT

Smart adaptive mode .

Assistance Mode

Sequence

10 11

The mode selected is visible in the bottom right corner of your display

screen.

To change between gearbox modes press the

gearbox mode button on your deported remote

(1). A long press will put the system in reverse

mode on equipped bikes.

Gearbox in manual mode

In manual mode the rider has control over the gear shifting. The gear

selected is shown in the bottom right corner of the display screen as

a number “N/7”.

The motor output depends on the force applied on the pedals by

the rider and the assistance mode selected, up to 130 Nm in Turbo or

Predict mode.

VALEO CYCLEE™

GEAR SELECTION

Gearbox modes

Your Valeo Cyclee™ e-bike system is equipped with a gearbox

integrated in the mid drive unit. The gearbox can be operated manually

by the rider or automatically by the Valeo Cyclee™ e-bike system.

Note: some e-bikes can be equipped with a reverse mode.

Generally on cargo bikes this mode will help you to back up and

manoeuver with heavy payloads. The reverse mode is not present

on other e-bikes.

Eco

Predict

Turbo

Max. Torque 130 N.m

Max. Torque 80 N.m

Assistance output torque [N.m]

Note: Default level setting, Max torque and assistance factor may vary depending on the setting chosen by each bike brand.

Rider Torque [N.m]

12 13

SWITCH LIGHTS ON/OFF

On bikes equipped with lighting powered by the e-bike battery,

the front and rear lights can be controlled from the display

unit by pressing briey the “lights” button.

When the lights are on, the light icon is showing on the display screen.

Pressing again the button will switch off the lights and the icon will

disappear from the display screen.

SPEED AND DISTANCE

The display unit allows the rider to see essential information about the

e-bike and the trip according to the unit selected (km or miles). Main

functions are:

To change the gear in manual mode press the “+” or “-” buttons on the

deported remote.

“+” to Upshift

“-” to Downshift

The gear-shifting should be used in the same way as with a normal

bicycle. By selecting the correct gear, you can increase your speed

and range while applying the same amount of force on the pedals.

Note: When the selected gear is ashing on the display, the

system indicates that it is not possible to shift the gear. Briey

stop pedaling to let the gear engage and resume pedaling. Please

refer to your bike shop if this error occurs frequently.

Gearbox in automatic mode

In automatic mode, the e-bike smart system is selecting the best gear

available for you according to your pedaling cadence and the terrain

prole.

In automatic mode ”A” is showing in the bottom right corner of the

display screen.

Note: in assistance mode “Predict” the gearbox is always set to

automatic by the smart e-bike system.

Gearbox in reverse mode

The reverse mode allows the rider to back up and manoeuver the bike

easily even with heavy payload. Once in reverse mode, the rider can

activate it by pushing gently the throttle of the deported remote.

The reverse mode isn’t present on all systems and is usually reserved

to cargo bikes.

In reverse mode “R” is shown in the bottom right corner of the display

screen.

14 15

BATTERY STATE OF CHARGE

& CHARGING MODE

Before charging your e-bike for the rst time please read the

battery and charger user guide.

State of charge

The state of charge of the battery is directly visible on the display

screen when it is switched On. The state of charge is indicated by the

battery icon on the top right corner of the screen. The battery icon

is composed of 5 blocks, each block representing 20% of the total

battery capacity.

The e-bike battery is fully charged (between

80-100%)

The e-bike battery is charged between 0%

and 20%

The e-bike battery state of charge is close

to 0%, the motor assistance has been

progressively reduced to ensure the shifting

ability and lighting.

Speed e-bike current speed, measured from

the motor and speed sensor on the rear

wheel

Trip distance Daily distance, the trip distance can be

reseted by a long press on the light

button and the assistance level

button , simultaneously.

e-bike range Autonomy left with the current state of

charge of the battery and depending on

the selected assistance mode

Total distance / ODO Total distance covered with the e-bike

The unit KM/h or MPH can be adjusted by changing this setting in your

Valeo Cyclee™ mobile app.

16 17

To activate the boost mode, hold down the throttle when riding. The

throttle acts as an On/Off switch and as soon as you release the

throttle the boost mode will stop.

MAINTENANCE

Maintenance mode

When maintenance is needed on your Valeo e-bike system the display

screen shows the wrench icon. The associated maintenance code is

displayed at the bottom of the screen.

The wrench may be blinking in case of a minor issue or if maintenance

is required.

When a critical error occurs the wrench icon will be xed and

associated with an error code. When this happens, stop riding your

e-bike immediately and visit your authorized Valeo Cyclee™ dealer.

Charging mode

When the e-bike battery is charged while on the bike, the display

screen only indicates the battery icon showing an approximate state

of charge and the exact value at the bottom of the screen.

WALK ASSIST AND BOOST MODE

Walk assist

The walk assist mode is helping you to push the e-bike when walking

on its side. The walk assist mode is moving the bike forward up to 6

km/h or 3.7 mph.

You can activate the walk assist by holding down the throttle of the

deported remote. When releasing the throttle the walk assist stops

automatically.

Note: In reverse mode, pushing the throttle will move the bike

backwards.

In walk assist or reverse mode the pedals may turn at the same

time. Make sure there is enough space between yourself and the

e-bike.

Boost mode

When riding on the bike, you can use the boost mode to accelerate or

climb a slope for a brief period of time.

18 19

Indice

Lingue:

Altri manuali Valeo Accessori per biciclette

Valeo

Valeo cyclee Go 7 Motor Manuale utente

Manuali Accessori per biciclette popolari di altre marche

Sigma

Sigma BC 16.16 Manuale utente

Playcore

Playcore Dero Setbacks Manuale utente

VDO Cyclecomputing

VDO Cyclecomputing x3dw Manuale utente

Cateye

Cateye RAPID X2 Manuale utente

buratti meccanica

buratti meccanica Clorofilla Trail Manuale utente

Shimano

Shimano SG-8R20 Istruzioni operative

BOB

BOB YAK Manuale utente

APLIC

APLIC 303303/20190717TW012 Manuale utente

SRAM

SRAM AXS BlipBox Manuale utente

Garmin

Garmin EDGE 500 Manuale utente

Shimano

Shimano FD-RX810 Manuale utente

Cateye

Cateye V2C - Manuale di istruzioni

KMART

KMART 43115907 Manuale utente

SIGMA SPORT

SIGMA SPORT Buster 2000 Manuale utente

NVO Components

NVO Components STEM Manuale utente

DAXYS

DAXYS BP188 Manuale utente

XLC

XLC BV-W17 Manuale utente

Deda Elementi

Deda Elementi SUPERBOX Manuale utente
