Vapify.us Fogbank Manuale utente
v1.3
2
Copyright
© 2013 Vapify LLC. All rights reserved.
Disclaimer
Information in this manual is protected y copyright laws and is the property of Vapify.us™ and Vapify
LLC. Changes to the specifications and features in this manual may e made y Vapify LLC without prior
notice. No part of this manual may e reproduced, copied, translated, transmitted, or pu lished in any
form or y any means without Vapify.us™ or Vapify LLC’s prior written permission.
This product is intended for use y persons 18 or older, and not y children, women who are pregnant or
reast feeding, or persons with, or at risk of heart disease, high lood pressure, dia etes, or taking
medicine for depression or asthma. If you have a demonstrated allergy or sensitivity to nicotine or any
com ination of inhalants, consult your physician efore using this product. This product is sold purely for
recreational purposes - it is not a smoking cessation product and has not een tested as such. You must
e over the legal age in your state to uy or use this product.
Nicotine products are addictive.
Keep out of reach of children and pets.
If a person, pet or child drinks e-liquid, call a poison control center immediately.
• In order to assist in use of this product and prevent accidental damage or injury, carefully read the
entire User Guide efore use.
• For product related information, check our we site at http://www.vapify.us
3
FOGBANK™ Vapor Tank Kit
Bo Contents
Fog ank™ advanced attery
Vapor Tank Head and Tip
USB Charge Ca le
Support Collar
Spare tip
3 replacement cartomizers
2 E-Liquid
Polymer Carrying Case
* The ox contents a ove are for reference only and the actual items shall depend on the product
package you o tain.
4
FOGBANK™ CE5 Kit
Bo Contents
Fog ank™ advanced attery
CE5 Head and Tip
USB Charge Ca le
3 replacement coils
2 E-Liquid
Polymer Carrying Case
* The ox contents a ove are for reference only and the actual items shall depend on the product
package you o tain.
5
FOGBANK™ Advanced Battery
The FOGBANK™ is constructed of a polished stainless steel ody and features:
650 mAh protected attery
soft activation utton
Information display window
pass-through charging port ( ottom)
Battery safety circuits
Orange, green and lue LEDs to indicate the current mode or function
Charging
When you first open your FOGBANK™, you should charge the attery. Unscrew the ezel from the
ottom of the attery, then screw the attery into the included USB charger. You can plug the USB ca le
into any standard USB port or charge adapter. The transparent indicator ring and utton will glow red
while charging. When the utton and indicator ring glow green, the attery is charged!
To turn off or on the attery, or to prevent accidental activation, simply click the utton three times. The
display window will show “off”, and the utton will link orange several times. To turn on, simply click the
utton three more times.
The display window indicates attery level and current puff count. To reset the puff count, ensure the
attery is not connected to a CE5 or tank reservoir, then while the attery is on, hold the activate utton
for 25 seconds. The puff indicator will reset to zero. The puff counter will not increment until the activate
utton is held for more than 3 seconds.
6
The FOGBANK™ is protected y a attery safety circuit. If the activate utton is pushed for longer than
10 seconds while the attery is connected to the CE5 or Vapor Tank, or the attery detects a inconsistent
resistance, it will shut down and the transparent ring will link lue 8 times. This is often an indication of a
failing cartomizer, coil, or that it is time for a cleaning.
Occasionally a cartomizer or CE5 tank will leak liquid into the top of the attery contact. This can occur
due to large changes in air pressure, like when riding on an airplane or when a cartomizer or coil is
eginning to fail. The liquid should e promptly wiped out with a dry paper towel or q-tip to prevent
damage to your FOGBANK™ device.
Though the FOGBANK™ devices are constructed with the utmost quality and care, they are precision
devices so they can e stressed or damaged. Store the unit in the included carrying case when placing it
in a purse, ag or pocket to prevent lateral stress and possi le damage to the unit.
Always keep the battery dry. Never submerge or get any part of the battery wet. Damage or injury
may occur. When cleaning the vapor tank or CE5 unit, always disconnect the battery first, then
thoroughly dry the head and follow filling instruction before use.
7
FOGBANK™ CE5
The CE5 reservoir is made up of 4 components:
The tip
The reservoir ody
The lower ody
And the coil assem ly
To egin using your CE5, simply unscrew the tip from the ody, hold the unit at a 45 degree angle and fill
with e-liquid to the fill-line (1.6ml), while eing careful not to put liquid down the center air hole. Now
you’re ready to go!
8
The coil assem ly must e replaced after a period of extended use. A coil assem ly typically lasts from
a out a week to a month, depending on the frequency of use and the type of e liquid used. The CE5 will
need to e disassem led in order to replace the coil assem ly.
Before proceeding, remove the CE5 from the attery.
All of the components are threaded together. Disassem le the unit y unscrewing the tip and clear tank
from the knurled ase. Rinse out the tank with tap water then pat dry.
The coil can now e removed and replaced y unscrewing it from the lower ody.
While assem ling and disassem ling the CE5 unit, e sure to inspect the components and o-rings for any
damage. A damaged unit can result in leakage or premature failure. Replace the CE5 unit if any ody
components are damaged or worn.
To re-assem le, gently screw the components together. When attaching the clear ody to the ase, give
the reservoir ody a spin while inserting the ase to ensure the wicking material does not get caught in
the ottom threads.
For additional trou leshooting information and FAQ please refer to the trou leshooting section in this
manual or visit our we site at http://www.vapify.us.
9
FOGBANK™ Vapor Tank
[NOTE: Never activate a dry cartomizer. It will burn out in seconds.]
The Vapor Tank is made up of 4 components:
The tip
Vapor Tank Body
The cartomizer
Sta ilizing collar
The vapor tank design provides maximum vapor and airflow and is the go-to choice for advanced e-cig
users. For users that wish to use a more convenient design, please check out the FOGBANK™ CE5.
10
To egin using your vapor tank, first remove the tip y gently pulling and twisting, then pull the cartomizer
from the ottom of the tank to fully remove it. You can thread the cartomizer into the attery to aid in
removal. Use caution not to activate the unit.
Attempting to use a cartomizer when it is dry will result in damage or failure of the cartomizer coil. Make
sure to keep it wet with e-liquid!
A vapor tank cartomizer is made up of a stainless steel arrel with a ring of wicking material inside. At the
center of the wicking material is a coil. At the very center of the cartomizer is an air path. It is important
to keep the air-path clear.
The cartomizer must e pre-loaded to prevent damage, or urning of the wicking material. Take the
cartomizer in one hand and a ottle of e-liquid in the other with a clean paper towel near y. Hold the
cartomizer at a 45 degree angle and carefully drip e-liquid down the inside lip of the arrel to reach the
wicking material. A out 4 drops is good to start. We are attempting to wet the wicking material without
getting liquid in the air-path.
