SERVICE
3
TECHNICAL DATA
Voltage/frequency: 230 V ~ 50 Hz (Phase-Neutral-Earth)
Heat pump output: (with SC10GHH compressor / with BSD122 DT compressor) 1,4 kW / 1,7 kW
Heat pump input: (with SC10GHH compressor / with BSD122 DT compressor) 395 W / 600 W
High supplementary heating: 2,0 kW / 230 V
Fuse protection: > 13 A
Thermostat for supplementary heating: Bei 65 °C, Controlled via the display
Protection: IP20
Water temperature: Adjustable - max. 62 °C
Refrigerant: R 134 a (CH2FCF3)
Amount of refrigerant: 0,990 Kg or see name plate
Leak tested:
Air temperature: -10 °C to +35 °C
Air flow: 200 to 300 m3/h
Stock temperature: -20 °C bis +60 °C
External pressure in ventilation system without affecting the performance: 80 Pa (Fan speed 1)
Boiler – VT3130 / VT3130 ECO / VT2130: 270 l, Enamelled
Boiler – VT3131 / VT3131 ECO / VT2131: 258 l, Enamelled
Boiler – VT3132 / VT3132 ECO / VT2132: 242 l, Enamelled
Anode: 5/4” RT
Pressure tested: 13 bar / 1.3 MPa
Working pressure: 10 bar / 1 MPa
Max. boiler temperature: 65 °C
Weight without packaging – VT3130 / VT3131 / VT3132: 145 Kg / 168 Kg / 190 Kg
Weight without packaging – VT3130 ECO / VT3131 ECO / VT3132 ECO: 134 Kg / 157 Kg / 179 Kg
Weight without packaging – VT2130 / VT2131 / VT2132: 152 Kg / 175 Kg / 197 Kg
Weight (full load) – VT3130 / VT3131 / VT3132: 396 Kg / 411 Kg / 417 Kg
Weight (full load) – VT3130 ECO / VT3131 ECO / VT3132 ECO: 384 Kg / 399 Kg / 405 Kg
Weight (full load) – VT2130 / VT2131 / VT2132: 406 Kg / 421 Kg / 427 Kg
Water connections: Cold water: 1” RT
Hot water: 1” RT
Condensation water: 1/2” RT
Heat exchanger: 1” RT
Cirkulation: 3/4” RT
Heat exchanger, heat surface VT3131 / VT3131 ECO / VT2131: 1.00 m2 (5.90 l)
Heat exchanger, heat surface VT3231 / VT3231 ECO / VT2231: Lower 1.5m2 (9.57L) +
upper 0.6m2 (3..83 L)
Idle consumption - at 7 °C outside air and 55 °C hot water temperature: 27 W / 24 hours*
Idle consumption - at 20 °C ambient air and 55 °C hot water temperature: 20 W / 24 hours*
COP: 2.83*
COP: 3,61**
*According to EN16147:2011, XL-Profile, outside air 7 °C / hot water reference 55 °C
** According to EN16147:2011, XL-Profile, ambient air 20 °C / hot water reference 55 °C
