Vauxhall 2013 Combo Manuale utente

COMBO

©Copyright by Vauxhall Motors Ltd., England.

Reproduction or translation, in whole or in parts, is not

permitted without prior written consent from Vauxhall Motors

Ltd.

All rights as understood under the copyright laws are explicitly

reserved by Vauxhall Motors Ltd.

All information, illustrations and specifications contained in this

manual are based on the latest production information

available at the time of publication.

The right is reserved to make changes at any time without

notice.

Edition: June 2006.

TS 1649-A-07

COMBO

Operation, Safety and Maintenance

Owner’s Manual

VAUXHALL Combo

Owner’s Manual

Data specific to your vehicle

Please enter your vehicle’s data here to keep it easily accessible.

This information is available under the section "Technical data" as well as on the vehicle identification plate and in the Service Booklet.

Fuel

Designation

Engine oil

Grade

Viscosity

Tyre pressure

Tyre size Comfort pressure with full load

Summer tyres Front Rear Front Rear

Winter tyres Front Rear Front Rear

Weights

Permissible Gross Vehicle Weight

– ECkerbweight

=Loading

Your Combo

Developed in accordance with the latest findings of vehicle research, it offers technical sophistication and exceptional comfort.

Your vehicle represents an intelligent synthesis of advanced technology, outstanding safety, environmental compatibility and

economy in operation.

It now lies with you to drive your vehicle safely and to see it performs perfectly.

This Owner’s Manual provides you with all the necessary information to that end.

Make sure your passengers are aware of the possible risk of accident and injury which may result from improper use of the vehicle.

The Owner’s Manual should always be kept in the vehicle: ready to hand in the glove compartment.

Make use of the Owner’s Manual:

zIts "In brief" section will give you an initial overview.

zThe table of contents at the beginning of this owner’s manual

and within the individual chapters will show you where everything is.

zIts index will help you find what you want.

zIt will familiarise you with the sophisticated technology.

zIt will increase your pleasure in your vehicle.

zIt will help you to handle your vehicle expertly.

The Owner’s Manual is designed to be clearly laid-out and easily understood.

This symbol signifies:

6Continue reading on next page.

3The asterisk signifies: equipment not fitted to all vehicles

(model variants, engine options, models specific to one country, optional equipment, Genuine Vauxhall Parts and Accessories).

Yellow arrows in the illustrations serve as points of reference or indicate some action to be performed.

Black arrows in the illustrations indicate a reaction or a second action to be performed.

Thank you for choosing a Vauxhall. We wish you many hours of pleasurable driving.

Your Vauxhall Team

9Warning

Text marked 9Warning provides information on risk of accident or injury. Disregard of the

instructions may lead to injuries or endanger life.

Inform your passengers accordingly.

Contents

Commitment to customer

satisfaction:

Our aim: to keep you happy with your

vehicle. All Vauxhall Authorised Repairers

offer first class service at competitive

prices. Experienced, factory-trained

technicians work according to factory

instructions. Your Authorised Repairer can

supply you with GENUINE VAUXHALL-

APPROVED PARTS, which have undergone

stringent quality and precision checks, and

of course useful and attractive

VAUXHALL-APPROVED ACCESSORIES.

Our name is your guarantee!

For details of the

Vauxhall Authorised Repairer Network

please ring this number; 01582 - 427200

In brief ........................................................ 2

Instruments ............................................. 24

Keys, doors, bonnet ............................... 44

Seats, Interior .......................................... 63

Safety systems ........................................ 75

Lighting ................................................... 93

Windows .................................................. 98

Climate control ..................................... 101

Easytronic ............................................. 111

Driving hints .......................................... 117

Saving fuel,

protecting the environment ............. 119

Fuel consumption,

fuel, refuelling ................................... 121

Catalytic converter, exhaust gases .... 124

Brakes .................................................... 128

Wheels, tyres ......................................... 132

Roof racks,

caravan and trailer towing .............. 138

Self-help ................................................ 143

If you have a problem .......................... 178

Maintenance, Service Plan ................... 180

Vehicle care .......................................... 191

Technical data ..................................... 196

Index ...................................................... 212

2 In brief

In brief

Key numbers,

Code numbers

Remove key number from keys.

The key number is specified in the vehicle

documents and in the Car Pass 3.

Alloy wheels 3, towing equipment 3:

make a note of the key identifier codes.

Electronic immobiliser, Infotainment

system 3: the code numbers are specified

in the Car Pass.

Do not keep the Car Pass in the vehicle.

For key with retractable blade 3, press the

button to extend.

6Further information – see pages 44, 45,

vehicle recommissioning – see page 190.

To unlock the vehicle and open

the doors:

With key in lock,

turn key towards front of

vehicle or press button qon the

remote control 3,

pull door handle and open door or

sliding door 3.

Unlocking the door from inside:

pull up on lock button.

6 Sliding door 3 – see page 54,

door locks, child safety locks 3–

see pages 46, 54

electronic immobiliser – see page 45,

radio frequency remote control 3 –

see page 47,

central locking system 3 – see page 51,

Vauxhall alarm system 3– see page 58.

3In brief

To unlock and open tailgate 3:

Turn key to horizontal position

or press button q on the remote

control 3,

press button and open tailgate

upwards

When using the remote control, the tailgate

is only unlocked if the key slot in the button

is in the horizontal position.

If the key slot is in the vertical position, the

tailgate is always locked.

6 Radio frequency remote control 3 –

see page 47,

central locking system 3 – see page 51,

Vauxhall alarm system 3 – see page 58,

tailgate 3 – see page 55.

To unlock and open rear doors 3:

Turn key to vertical position

or press button q on the remote

control 3,

pull handle and open rear door.

To open the left rear door, pivot

the handle on the inside

When using the remote control, the rear

doors are only unlocked if the key slot in the

lock is in the vertical position.

If the key slot is in the horizontal position,

the rear doors are always locked.

6 Radio frequency remote control 3 –

see page 47,

central locking system 3 – see page 51,

Vauxhall alarm system 3 – see page 58,

rear doors 3 – see page 56.

To adjust front seat 3:

Pull handle,

slide seat,

release handle,

allow seat to audibly latch into

position

Never adjust the seat whilst driving. It could

move in an uncontrolled manner when the

handle has been pulled.

6Seat position – see page 63.

9Warning

Important: Do not sit nearer than 10

inches (25 cm) from the steering wheel, to

permit safe airbag deployment.

4 In brief

To adjust front seat backrests:

Turn handwheel

Move seat backrest to suit seating position.

Do not lean on seat backrest whilst

adjusting it.

6Seat position – see page 63.

To adjust front seat height 3:

Pull lever at side

Lift lever and relieve some weight from seat

to raise it or press down on seat with body

weight to lower it.

Never adjust the driver’s seat whilst driving.

It could move in an uncontrolled manner

when the lever has been pulled.

6Seat position – see page 63.

To fold front seat backrest 3:

Raise lever

To enter and leave the rear seat area, tilt

front seat back forwards.

6Seat position – see page 63.

5In brief

To adjust height 3of front and

outboard rear head restraints:

Tilt forward to release,

hold and adjust height,

release

6Head restraint position – see page 63,

further information, removal –

see page 64,

centre rear head restraint 3 – see page 64.

To adjust interior mirror:

Swivel mirror housing

Swivel lever on underside of mirror housing

to reduce dazzle at night.
