Vax H85-D-B14 Istruzioni per l'installazione

POWERFUL 2-IN-1 CORDLESS

VACUUM WITH HANDHELD

H85-D-B14

H85-D-B18

DynamoCordless

LET’S GET STARTED.

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

This vacuum cleaner is intended for household use only

and NOT for commercial or industrial use.

• Only use the vacuum cleaner indoors and keep the area you’re

cleaning well lit.

• Keep ngers, hair and loose clothing from moving parts and

openings whilst using the vacuum cleaner.

• This vacuum cleaner can be used by children aged from 8

years and above and persons with reduced physical, sensory

• Don’t charge the Cordless upright outdoors or leave the charger

connected to the mains when not in use.

• Don’t use this vacuum cleaner if it has been dropped, damaged,

immersed in water or left outdoors.

• Don’t handle the charger plug or use the vacuum cleaner

with wet hands.

• Don’t run over the charger cord or use the vacuum cleaner if the

charger cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm,

Sat 9:00am to 5:00pm).

• Always make sure the lter and dirt container are tted correctly

before using your vacuum cleaner.

• Always turn o and unplug the vacuum cleaner from the charger

before carrying out any maintenance.

• Turn o all controls on the vacuum cleaner before disconnecting

or connecting the charger.

• Take extra care when cleaning on the stairs.

• Always protect the charger cord from heated surfaces or near

open ames.

• If charging the vacuum cleaner through an extension cord

use only CE approved 13amp extension cords, non-approved

extension cords may overheat. Care should be taken to arrange

the extension cord as it can be a trip hazard.

or mental capabilities or lack of experience and knowledge if they have been

given supervision or instruction concerning use of the vacuum cleaner in

a safe way and understand the hazards involved. Children should not play

with the vacuum cleaner. Cleaning and user maintenance should not be made

by children without supervision.

• Only Vax recommended charger, tools and accessories should be used with

this vacuum cleaner.

• The vacuum cleaner should not be used to absorb or vacuum up liquids.

• Don’t use the charger cord as a handle, pull the charger cord around corners

or sharp edges or close a door over the charger cord. Don’t unplug charger

by pulling on the charger cord.

• Don’t attempt to remove blockages with sharp objects as this may cause

damage to your vacuum cleaner.

• Don’t use the charger with incorrect voltage as this may result in damage

or injury to the user. The correct voltage is listed on the ratings label.

• Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

• Always carry the vacuum cleaner/handheld by the correct carry handle.

• Store your vacuum cleaner in a cool, dry area.

• Before any user maintenance is undertaken, refer to the appropriate section

in the user guide to understand necessary precautions required.

• Always use the charger supplied with the vacuum cleaner.

• Always remove the plug from the vacuum cleaner before cleaning

or maintaining the vacuum cleaner.

PLEASE KEEP INSTRUCTIONS FOR FURTHER USE AND USE ONLY

AS INSTRUCTED IN THIS GUIDE.

Thank you for buying this Dynamo Cordless

Taking care of your carpets and hard oors

The Dynamo Cordless is designed to make vacuuming carpets and hard oors regularly,

as eective and ecient as possible and this user guide will help you get the most out

of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer.

You’ve chosen the carpets and hard oors for your home for a reason and Vax will help you

take good care of them.

Taking care of your Dynamo Cordless

Also inside this guide are instructions on maintaining your new machine, so that it’s always

ready when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich,

Worcestershire, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Contents

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Accessories

What to do if it goes wrong

Getting in touch

Dynamo Cordless

Included with

your machine

Charger

2-in-1 Crevice Tool

/Dusting Brush

Wall Clip

Getting to know your machine

Name Dynamo Cordless 14.4V

Model No H85-D-B14

Voltage Please refer to product rating label

Wattage Please refer to product rating label

Charge Time 5 hours Run Time 25mins

Weight 3kg

Bin Capacity 0.4l

Name Dynamo Cordless 18V

Model No H85-D-B18

Voltage Please refer to product rating label

Wattage Please refer to product rating label

Charge Time 5 hours Run Time 35mins

Weight 3kg

Bin Capacity 0.4l

Technical Specication

Subject to technical change without notice. *To purchase consumables and accessories, please visit vax.co.uk

On/O and suction

control switch

2-in-1 crevice tool/dusting

brush holder

Handle recline button

Handheld release button

LED Power/charge lights

Handheld On/O button

Dirt container

release button

Floorhead

LED oorhead

lights

Machine charging port

Floorhead release button

Line up the oorhead with

the main body and push

rmly into place.

Fix the wall clip to your wall using the screw and wall plug provided. During storage

and charging, secure your vacuum cleaner handle into the wall clip.

Lift the handle in a hinge

like manner and secure

onto the main body.

Assembling your 2-in-1 vacuum cleaner

Getting started

*To purchase consumables and accessories, please visit vax.co.uk

PLEASE READ ‘LET’S TALK SAFETY’ BEFORE USE

Before you begin

CAUTION:Always switch o the vacuum cleaner before connecting or disconnecting the handheld/attachments or removing

and emptying the dirt container.

CAUTION:Ensure the battery is removed from the vacuum cleaner before it is scrapped. The vacuum cleaner must be

disconnected from the supply mains when removing the battery. The battery must be recycled or disposed of in an

environmentally sound manner.

IMPORTANT:The vacuum cleaner is equipped with a thermal cut-out. If for any reason the vacuum cleaner does overheat the

thermostat will automatically turn the vacuum cleaner o. If this happens, switch the vacuum cleaner o. Remove and empty the

dirt container also check the vacuum cleaner for blockages. Allow the vacuum cleaner to cool for approximately 1 hour (if you have

cleaned the lter please wait 24 hours for the lter to fully dry before putting back into the machine). For best cleaning results,

lters require cleaning at least every 3 to 6 months. If the vacuum cleaner is blocked, switch o before removing the blockage.

CAUTION:This vacuum cleaner has a constantly rotating brushbar. Never leave the vacuum cleaner in one spot for an extended

period of time as this may damage the oor surface.

Store the 2-in-1 tool on

board the vacuum cleaner

by pushing the tool rmly

into the tool holder located

on the handle.

NOTE: To fold the handle for storage, push in the handle recline button and fold handle all the way back.

Getting started

Charging your 2-in-1 vacuum cleaner

NOTE: Initial charge is 5 hours, charging will be required before rst use. The vacuum can be charged with the handheld either

attached to or detached from the main body.

Plug the charger into the side of the handheld

and plug into mains.

Once fully charged

the LED indicator lights

on the handheld will

illuminate green.

When the vacuum needs

recharging the LED lights

on the handheld will

illuminate red and the

machine will cut out.

Make sure the handle

is secured onto the main.

body and use the handle

to carry as a upright

vacuum cleaner.

Use the handle to carry as a handheld vacuum cleaner.

Carrying your 2-in-1 vacuum cleaner

Using your machine

As an upright vacuum cleaner

Unplug the charger from

the mains and from the

side of the handheld.

Place foot on the oorhead

and pull the handle

backwards to recline.

CAUTION: The brushbar will constantly rotate. Never leave the vacuum cleaner in one spot for an extended period of time

as this may damage the oor surface. Vax cannot be held responsible for damage to the oor surface if this recommendation

is not followed.

Slide the On/O suction

control switch forward

once for low suction.

The LED lights on the

oorhead will illuminate.

The LED lights on the

handheld will illuminate

green, indicating the power

is on and the brushbar

will spin.

Slide the On/O suction

control switch forward

again for high suction.

Slide the On/O suction

control switch all the way

back to switch the power

and LED lights O.

As a handheld vacuum cleaner

Press the handheld

release button.

Lift to remove the

handheld from the

main body.

Slide the On/O suction

control forward to switch

the handheld on. The LED

lights will illuminate green

indicating the power is on.

Using your machine

Taking care of your machine

Using the 2-in-1 tool

1Crevice tool

2Dusting brush

For a more detailed clean, line up the 2-in-1 tool the with

the nozzle on the handheld and push rmly into place.

Before returning the

handheld to the main body,

slide the On/O suction

control backwards, to

switch the handheld o.

Pull to remove 2-in-1 tool

from the handheld nozzle.

Emptying the dirt container

Press the handheld

release button.

Lift to remove the

handheld from the

main body.

CAUTION: Always switch o the vacuum cleaner before carrying out any maintenance or troubleshooting.

Lift the lter by the

lter frame out from

the dirt container.

Hold the dirt container

over a bin allowing

dirt/debris to fall out.

Press the dirt container

release button.

Pull to separate the

dirt container from

the handheld.

1 2

CAUTION: Always turn o the vacuum cleaner if anything becomes trapped whilst using the tool.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Vax Aspirapolvere

Vax

Vax Workman VCC-05 Manuale utente

Vax

Vax Rapide V-028PX Manuale utente

Vax

Vax Rapide Spring Fresh V-021T Manuale utente

Vax

Vax Air3 Pet Plus VRS114 Istruzioni per l'installazione

Vax

Vax Washvax V-020 Series Istruzioni per l'installazione

Vax

Vax Mach Air U90-MA Manuale utente

Vax

Vax C90-CX SERIES Manuale utente

Vax

Vax DynamoPower U84-DY-Pe Manuale utente

Vax

Vax VRS9C Powermax Manuale utente

Vax

Vax Mach Air SERIES Manuale utente

Vax

Vax Everyday Turbo V-041HS Manuale utente

Vax

Vax Performance C91-PF Series Manuale utente

Vax

Vax V-2000S Manuale utente

Vax

Vax HF86-FM-T Manuale utente

Vax

Vax Power Plus 6 Manuale utente

Vax

Vax V-075E Manuale utente

Vax

Vax Silentium VBGS1800 Manuale utente

Vax

Vax Rapide Supreme V-023 Manuale utente

Vax

Vax C90-EB-B-C Manuale utente

Vax

Vax Rapide Spring V-021 Manuale utente

Vax

Vax MachAir UCA1GEV1 Manuale utente

Vax

Vax Swift V-055 Scheda informativa del prodotto

Vax

Vax Integra Manuale utente

Vax

Vax PowerCompact U85-PC-Be Istruzioni per l'installazione

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
