Vax LiFE2-in-1 Scheda tecnica

LiFE2-in-1

CORDLESS 2-IN-1 VACUUM

FOR QUICK CLEAN UPS

LET’S GET STARTED.

H85-LF-B14

Let’s talk safety

Basic

safety

precautions

Don’ts

Do’s

This vacuum cleaner is intended for household use only and

NOT for commercial or industrial use.

•

It is a battery-operated appliance, the battery being charged

outside the appliance.

•

Only use the vacuum cleaner indoors and keep the area you’re

cleaning well lit.

•

Keep ngers, hair and loose clothing from moving parts and

openings whilst using the vacuum cleaner.

•

Don’t charge the Cordless upright outdoors, or leave the charger

connected to the mains when not in use.

•

Don’t use this vacuum cleaner if it has been dropped, damaged,

immersed in water or left outdoors.

•

Don’t handle the charger plug or use the vacuum cleaner with

wet hands.

•

Don’t run over the charger cord or use the vacuum cleaner if the

charger cord or plug is damaged. Please contact our Customer

Care Line on: 0330 026 8455 (Mon-Fri 8:30am to 6:30pm,

Sat 9:00am to 5:00pm).

•

Don’t vacuum up hard or sharp objects such a glass, nails, screws,

coins, etc.

•

Always make sure the lter and dirt container are tted correctly

before using your vacuum cleaner.

•

Always turn o and unplug the vacuum cleaner from the charger

before carrying out any maintenance.

•

Turn o all controls on the vacuum cleaner before disconnecting

or connecting the charger.

•

Take extra care when cleaning on the stairs.

•

Always protect the charger cord from heated surfaces or near

open ames.

•

This vacuum cleaner can be used by children aged from 8 years and above

and persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or instruction

concerning use of the vacuum cleaner in a safe way and understand the

hazards involved. Children should not play with the vacuum cleaner. Cleaning

and user maintenance should not be made by children without supervision.

•

Only Vax recommend charger, tools and accessories should be used with this

vacuum cleaner.

•

Don’t use the charger cord as a handle, pull the charger cord around corners

or sharp edges or close a door over the charger cord. Don’t unplug charger

by pulling on the charger cord.

•

Don’t attempt to remove blockages with sharp objects as this may cause

damage to your vacuum cleaner.

•

Don’t use the vacuum cleaner with incorrect voltage as this may result in

damage or injury to the user. The correct voltage is listed on the ratings label.

•

Don’t vacuum up hot coals, cigarette butts, matches or smoking hot burning

items or use in an area where there may be harmful uids (chlorine, bleach,

and ammonia drain cleaner).

•

Use only CE approved 13amp extension cords, non-approved extension cords

may overheat. Care should be taken to arrange the extension cord as it can be

a trip hazard.

•

Always carry the vacuum cleaner by the handle.

•

Store your vacuum cleaner in a cool, dry area.

Please keep instructions for further use.

Thank you for buying this LiFE 2-in-1.

Taking care of your carpets and hard oors

The LiFE 2-in-1 is designed to make vacuuming carpets and hard oors regularly, as eective

and ecient as possible and this user guide will help you get the most out of your machine.

Maintaining your carpets and hard oors will ensure they keep their appearance for longer

and Vax will help you take good care of them.

Taking care of your LiFE 2-in-1

Also inside this guide are instructions on maintaining your new machine, so that it’s always ready

when you are to tackle your carpets and hard oors.

Let us know what you think @VaxUK

Taking care of you

We’re here if you need us. Instead of taking me back

to the shop, simply visit:

vax.co.uk/support or call:

(UK) 0330 026 8455 (ROI) 1-800 928 308

Monday-Friday 8:30am to 6:30pm, Saturday 9:00am to 5:00pm

Calls are charged at the UK local rate. Please make a note of the serial number and model number

of the product before calling.

Alternatively, you can write to us at:

Vax Ltd., Plot 302, Stonebridge Cross Business Park, Hampton Lovett, Droitwich, WR9 0LW, UK

This user guide can be found online at: vax.co.uk/support

Contents

LiFE 2-in-1

Let’s talk safety

Getting to know your machine

Getting started

Using your machine

Taking care of your machine

Let’s talk technical

Accessories

What to do if it goes wrong

Getting in touch

Included with

your machine

2-in-1 tool

Charger

Docking station

2-in-1 tool connector

Getting to know your machine Getting started

Name LiFE 2-in-1

Battery voltage 14.4V

Run time 20 minutes

Charge time 5 hours

Weight 2.7kg

Dust bin capacity 0.5l

Technical Specication

Subject to technical change without notice.

Pre-motor lter (Type 132)

1-1-135931-00

2-in-1 tool (Type 3)

1-1-135932-00

Accessories & Consumables

* Selected models only.

To purchase consumables and accessories, please visit vax.co.uk

Suction control button

On/O switch

Handheld release button

Handheld On/O button

Dirt container

release button

Floorhead release button

Floorhead

Machine charging ports

2-in-1 tool holder

Charging point

Getting to know your machine Getting started

Assembling your 2-in-1 vacuum cleaner

Line up oorhead with

main body, push rmly

into place.

Line up handle with main

body and lower into place.

Insert screw into back of the

handle and tighten with a

cross head screwdriver until

handle is secured into place.

PLEASE READ ‘LET’S TALK SAFETY’ AT THE BEGINNING BEFORE USE

Charging your 2-in-1 vacuum cleaner

Plug the charger into the

back of the docking station

and plug into mains.

Slide the vacuum onto the

docking station. The LED

indicator will initially turn green,

then illuminate red to indicate

that it is in place and charging.

Once fully charged (5 hours)

the LED indicator on the On/

O button will illuminate

green and turn o to power

saving mode.

NOTE: Charging will be required before rst use. Initial charge requires 10 hours.

When the vacuum needs recharging the

LED light on the On/O button will ash

red and the machine will cut out.

Using your machine Using your machine

Unplug the charger from

the mains and remove

the vacuum from the

docking station.

Place foot on the oorhead and

pull the handle backwards to

recline the machine.

Press the ON button on

the handle to turn the

machine on.

NOTE: Do not use brushbar on hard oors as it may cause damage.

Operating as an upright vacuum cleaner

To select between high

and low suction press the

suction controller button.

TIP

The brushbar will

not rotate when the

vacuum cleaner is in

the upright position.

Using your machine

Press the handheld release

button. Lift to remove the

handheld from the main body.

To operate press the On/

O button to switch the

handheld on.

Press the On/O button to switch the

handheld o. Pull to remove accessory

from nozzle. Line up and return handheld

to main body.

Operating as a handheld vacuum cleaner

For a more detailed clean, push to attach the 2-in-1 tool

connector into the handheld and line up the 2-in-1 with

the nozzle on the connector and push rmly into place.

Always take extra care

when cleaning stairs.

Always switch the

handheld o before

connecting or

disconnecting the

accessories and before

returning the handheld to

the main body.

CAUTION

Taking care of your machine

Press the handheld release

button. Lift to remove the

handheld from the main body.

Emptying the dirt container

Press the dirt container release

button to remove the dirt container.

Squeeze tabs to remove lter

and frame.

Hold dirt container over a bin

allowing dirt/debris to fall out.

CAUTION: Always switch o the vacuum cleaner before carrying out any maintenance or troubleshooting.

TIP

Don’t over ll the dirt

container. Replace the

lters every 6-9 months.
